- Page 1 KERN & Sohn GmbH Ziegelei 1 Phone: +49-[0]7433- 9933-0 D-72336 Balingen Fax: +49-[0]7433-9933-149 E-Mail: info@kern-sohn.com Internet: www.kern-sohn.com Installation Instructions Platform KERN KFP Type TKFP-V30-A Version 1.2 2023-06 TKFP-V30-A-IA-e-2312...
-
Page 2: Table Of Contents
KERN KFP Platform Version 1.2 2023-06 Installation Instructions Contents General hints ....................3 Technical data ....................3 Technical data of the weighing cell ..................4 Basic Information (General) ................5 Documentation ......................... 5 Proper use ..........................5 Improper Use ..........................5 Warranty ............................ -
Page 3: General Hints
These installation instructions contain all data necessary for placing and commissioning the following platforms: KERN TKFP 15V30M-A KERN TKFP 30V30SM-A, TKFP 30V30M-A KERN TKFP 60V30M-A, TKFP 60V30LM-A, TKFP 60V30XLM-A KERN TKFP 150V30SM-A, TKFP 150V30M-A, TKFP 150V30LM-A KERN TKFP 300V30M-A 2 Technical data Item no./ Type... -
Page 4: Technical Data Of The Weighing Cell
2.1 Technical data of the weighing cell Sensitivity 2 mV/V 430 Ω Input resistance (all TKFP models*) 380 Ω *excepted TKFP 150V30SM-A TKFP 150V30M-A 350 Ω * excepted TKFP 60V30XLM-A TKFP 150V30LM-A TKFP 300V30M-A 351 Ω Output resistance (all TKFP models) 350 Ω... -
Page 5: Basic Information (General)
• The weighing system unit may only be operated in accordance with the described default settings. Other areas of use must be released by KERN in writing. 3.4 Warranty Warranty claims shall be voided in case: •... -
Page 6: Basic Safety Precautions
In KERN's accredited DKD calibration laboratory test weights and weighing systems may be calibrated (return to the national standard) fast and at moderate cost. -
Page 7: Unpacking, Installation And Commissioning
6 Unpacking, Installation and Commissioning 6.1 Installation Site, Location of Use The platforms are designed in a way that reliable weighing results are achieved in common conditions of use. You will work accurately and fast if you select the right location for your weighing system. -
Page 8: Unpacking, Scope Of Delivery
6.2 Unpacking, Scope of delivery Remove the underconstruction and the weighing plate from the package, remove packaging material and place the devices at the planned workplace. Check if all parts of the scope of delivery are present and free of damage. Scope of delivery: •... -
Page 9: Transport Securing
• Please consult the Technical Data whether your balance is equipped with a transport securing, chap. 2. • There are different types of transport securings in KERN balances. Please see the indications explained in this chapter. • Never remove other screws than these for the transport securing as otherwise the balance could be damaged. - Page 10 Variant 1: Note on transport securing • 1 x hexagon screw on the upper side Type of transport securing with nut • 1 x threaded pin with inner hexagon on the lower side with nut 1. Remove the weighing plate. 2.
- Page 11 7. Remove the hexagon screw on the upper side. Variant 2: Note on transport securing • 4 x cylinder head screw with inner Type of transport securing hexagon on the upper side 1. Remove the weighing plate. 2. Remove the transport securings. TKFP-V30-A-IA-e-2312...
-
Page 12: Levelling
Put the connecting cable to the display unit in a manner that it is protected against damage. Connect the platform to the display unit according to the following table. Output load cell Connection of platform KERN KFP EXC+ (5V) see labelling of load cell EXC- (0) -
Page 13: Operation Limits
B = with side load C = with one-side load Avoid falling load, shock loads and impacts from the side! Observe the following operation limits: Item no./ Type TKFP 15V30M-A 22 kg 15 kg 7 kg TKFP 30V30SM-A 45 kg... -
Page 14: Servicing, Maintenance, Disposal
Keep IP protection. 9.2 Servicing, maintenance The appliance may only be opened by trained service technicians who are authorized by KERN. Ensure that the weighing system is regularly calibrated, see chap. 3.5 Testing instruments monitoring. 9.3 Disposal ... -
Page 15: Instant Help For Troubleshooting
10 Instant help for troubleshooting In case of an error in the program process, briefly turn off the balance and disconnect from power supply. The weighing process must then be restarted from the beginning. Help: Fault Possible cause • Draught/air movement The displayed weight is permanently changing •... -
Page 16: Preload, Deadload And Overload Settings
Item no./ Type **= already applied protection (kg) protection (kg) load cell E (kg) the load cell E (kg) preload TKFP 15V30M-A TKFP 30V30SM-A TKFP 30V30M-A TKFP 60V30M-A TKFP 60V30LM-A TKFP 60V30XLM-A TKFP 150V30SM-A TKFP 150V30M-A TKFP 150V30LM-A TKFP 300V30M-A... - Page 17 (mm) class sizes range return interval ( °C) ( °C) TKFP 15V30M-A 300 x 240 x 110 B6N 20KG TC8009 rev.0 15000 4000 4000 TKFP 30V30SM-A 300 x 240 x 110 B6N 50KG D09-10.10 9000...
-
Page 18: Enclosure
12 Enclosure TKFP-V30-A-IA-e-2312... - Page 19 2022.3.10 Tim Zhao 104-(max.121) Transport protection screw 76° M8-6G Ø27 1° No tolerance (by GB/T14486-97) TKFP 15V30M-A & TKFP 30V30SM-A with feet Size range Tolerance TKFP 6V40M-A & TKFP 15V40M-A with feet Zhao Yingjie 130805200010 130805200059 Ø20 Tim Zhao PB3024-KERN-B6N&BM6G...
