- Page 1 USER INSTRUCTIONS OptiCell SMART air pressure mattress mattress series N, R and T...
-
Page 2: Introduction
Thank you for choosing OptiCell. We aim to ensure you are satis ed with your mattress in terms of both performance and durability. We therefore kindly ask you to spend a few minutes reading through these user instructions to ensure you can take the best possible care of your mattress. If you have any questions that are not answered in these user instructions, please contact us at Järven Health Care. -
Page 3: Table Of Contents
CONTENTS Introduction .............................2 Table of contents ..........................3 Safety information........................4 General information about OptiCell SMART ..............5 Commissioning ..........................5 OptiTex cover ..........................6 Expected useful life ........................6 Fire Safety ............................6 Intended use ...........................7 Features OptiCell SMART ......................8 Before using it ..........................9 Handling............................10 Air hose connection ........................11 Hand test ............................11 Overview –... -
Page 4: Safety Information
SAFETY DIRECTIVES Please read the following information before using the air mattress. • The product should only be used in accordance with these user instructions. • This product must not be combined, assembled or repaired with any parts, accessories or spare parts other than those described in these user instructions or other documentation from Järven Health Care. -
Page 5: General Information About Opticell Smart
GENERAL INFORMATION ABOUT OPTICELL SMART The OptiCell SMART has been designed as an aid in the prevention and treatment of pressure sore care up to and including bedsore category 4 depending on the mattres. Mattresses are available in a choice of models, please see summary under Intended use on page 7. -
Page 6: Optitex Cover
® THE OPTITEX COVER OptiTex® is a bi-stretch hygiene layer whose structure boosts the pressure relieving properties of the mattress. The OptiTex™ cover has an integrated, waterproof cable holder that reduces the risk of any spread of bacteria, keeps the cable out of the way, and also protects the air hoses. The top and bottom sides of the cover are made of PU material. -
Page 7: Intended Use
INTENDED USE The OptiCell SMART is an alternating and pressure relieving air mattress system that has been designed as an aid for the prevention and treatment of pressure sores up to and including bedsore category 4. OptiCell SMART - mattress configuration The combination of pump and mattress gives the system a unique set of functions. -
Page 8: Features Opticell Smart
FEATURES, OPTICELL SMART OptiCell SMART air mattress systems are designed to enable individual cells to be disconnected simply while a patient is lying on the mattress. The mattresses have three di erent types of cells with di erent functions. • Main cells - Continuously in ated air cells used primarily under the head. •... -
Page 9: Before Using It
BEFORE USE DELIVERY AND UNPACKING OptiCell SMART mattresses are delivered rolled up in cardboard. Do not use a knife to open the packaging to avoid any risk of damaging the product. First check that the product is not damaged. In the event of transport damage, see page 17. An OptiCell SMART air mattress system contains •... -
Page 10: Handling
HANDLING The mattress can be in ated and used immediately on delivery. It takes around 15 minutes to in ate the mattress and this should be done without a patient lying on the mattress. AUTOMATIC SETTING When you start the pump, it is set to automatically adjust the air pressure to the weight, height, location, movement and position of the user in the bed. -
Page 11: Air Hose Connection
AIR HOSE CONNECTION Connect the air hoses to the pump To connect or disconnect the air hoses to/from the pump and to remove the protective cover on the air connector, press in the clips on both sides of the connector. This releases the catches that hold the connector in place. -
Page 12: Overview - 4 Nx (Pump Oc55)
OVERVIEW - PUMP OC55 In ating the mattress normally takes about 15 minutes. The light will come on when the mattress is ready to use. Dynamic mode, select this to set the pump to dynamic (alternating) mode. Static mode, select this to set the pump to static mode. Care setting, this mode provides maximal static pressure to ease care situations. -
Page 13: Speci Cations
SPECIFICATIONS PUMP OC55 SPECIFICATIONS Size 28.0 x 11.0 x 20.5 cm Weight Pressure area 20 ~ 70 mm Hg Cycle time 10, 15, 20 or 30 minutes SYSTEM SPECIFICATIONS Classi cation Class II; IPXO, No AP/APG; Type BF** Applicable part Mattress Voltage AC 220-240 - 50 Hz 1A, 17W... -
Page 14: Maintenance - Inspection And Troubleshooting
CARE – INSPECTION AND TROUBLESHOOTING INSPECTION OF YOUR PRESSURE AIR MATTRESS An inspection plan ought to be established for the mattress to ensure your pressure air mattress stays in good condition and lasts as long as possible. If you would like help with this, please contact us at Järven Health Care. -
Page 15: Maintenance - Cleaning
MAINTENANCE – CLEANING CLEANING THE PUMP Use a damp cloth and gentle cleaning agent to clean the pump, pump housing and electric cable. CLEANING THE COVER The top and bottom of the cover are made of PU material. If necessary, the whole cover (both the top and bottom surfaces) can be wiped clean with a disinfectant agent. -
Page 16: Hand Test
HAND TEST Check that the mattress is working with a simple hand test. Checking the mattress is providing the correct therapeutic treatment is done via a simple hand test. This test should be done every time a mattress is used to enable any problems with the air pressure in the mattress to be detected. -
Page 17: Recycling
RECYCING All materials in OptiCell air mattress systems, except for certain parts in the pump, are suitable for energy recovery via combustion at waste to energy power stations. The product is PVC free. PUMP A used OptiCell® pump must not be dismantled, but sent to a recycling station instead. Sort as Electronic Waste. -
Page 18: Other Information
OTHER INFORMATION PRODUCT LIABILITY Product liability refers to the manufacturer's, importer's or seller's statutory liability for any damage caused by the product. The Product Liability Act (EU Directive 85/374 / EEC, Swedish Act SFS 1992: 18) establishes the manufacturer's, importer's or seller's statutory liability for damages for any damage caused by the product. -
Page 19: Key To Symbols
KEY TO SYMBOLS Product code Serial number Batch number The product is a medical Date of manufacture Name of manufacturer device product = 0-xxx kg This product is CE Read user instructions Bedsore category the Max user weight. marked according to before use mattress is suitable MDR 2017/745... -
Page 20: Accessories
ACCESSORIES, OPTICELL PRODUCT CODES. NAME FOR MODEL 12 960704 003 TPU Cell non ventilating OC 4 NX / 4 PRO 90 cm 12 960704 004 TPU Cell non ventilating OC 4 NX / 4 PRO 105 cm 12 960704 005 TPU Cell non ventilating OC 4 NX / 4 PRO 120 cm 12 960603 003... - Page 24 OptiCell SMART User Instructions. All trademarks are the property of their respective owners. Järven AB reserves the right to update these user instructions if necessary and / or to correct any typographical or factual errors. Additional copies can be ordered from Järven Health Care. Copying for internal use is permitted OptiCell AB, Bromsvägen 3 Phone:...
