Exitronix EMX Series Installation Instructions

EMX Series

Installation Instructions

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

When using electrical equipment, basic safety precautions should always be followed including the following:

• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.

• Installation and servicing of this equipment should be performed by qualified service personnel only.

• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations

if applicable.

• Do not mount near gas or electrical heaters.

• Do not use outdoors.

• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering

by unauthorized personnel.

• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.

• Any modification or use of non-original components will void the warranty and product liability.

• Do not use this equipment for other than intended use.

• Allow battery to charge for 24 hours before first use.

• For use with metal enclosed wiring systems.

XXXXXXXX REV 1 - 07/23

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!

Technical Support

■ (623) 580-8943 ■ technicalsupport@barronltg.com

800-533-3948 www.barronltg.com

Table of Contents

Do you have a question about the EMX Series and is the answer not in the manual?

Page 1 EMX Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only.
Page 2 EMX Series Installation Instructions Wall Mount Installation Fig. 1 1. Remove side screw using screwdriver and open front cover. (Fig. 1) 2. Determine appropriate mounting holes that will be used, and knock out cable entry hole on the backplate of the housing.
Page 3 EMX Series Installation Instructions Operation The battery in this unit may not be fully charged. After electricity is connected to the unit for at least 24 hours, then normal operation of this unit should take effect. To check, press the “TEST” button. The EXIT sign should stay illuminated by battery backup and the LED indicator will be turned off.
Page 4 EMX Series Installation Instructions Networking Operations for “-G3” Models Model with "-G3" suffix is our world winning design equipped with "wireless testing and reporting" features. Unit that has "-G3" suffix in its model number is capable of joining Guardian emergency lighting management system. It will be part of a large testing system to be tested and report result wirelessly.
