PREPARE THE PEDESTAL
2
Pull the
A
drawer out
as far as it
will go.
Remove
B
screws from
drawer slides.
Slide drawer
out of the base
and set aside.
FOR DRYERS ONLY:
Locate the 4 support pads from the parts
C
package. Each pad has 2 protrusions that
fit into the holes on top of the pedestal.
Press the rubber pads into each set of
corner holes on the top of the pedestal
as shown.
NOTE: The support pads should be installed
on the dryer only. DO NOT INSTALL THESE
PADS ON THE WASHER PEDESTAL.

Installation Instructions

2
INSTALL THE PEDESTAL
3
TO THE WASHER OR DRYER
Place the pedestal against the bottom
A
of the unit. Check to be sure the drawer
front is at the front of the washer.
Align the holes in the pedestal with
B
the holes in the bottom of the unit.
Use a Phillips screw driver to install
the 4 bolts through the pedestal and
into the unit—do not tighten.
C Slide the pedestal towards the unit, until
it is aligned front to back. Use an 8 mm
socket wrench to securely tighten the
bolts.
