INSTRUCTION MANUAL
FOR USE, DRIVING AND SAFETY
Read this documentation before using your Eloflex
to make sure that you use it in a manner that is safe, and which does not harm you,
your environment or your power wheelchair.
Eloflex
H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H and is the answer not in the manual?

Questions and answers

Related Manuals for Eloflex H

Summary of Contents for Eloflex H

  • Page 1 INSTRUCTION MANUAL FOR USE, DRIVING AND SAFETY Read this documentation before using your Eloflex to make sure that you use it in a manner that is safe, and which does not harm you, your environment or your power wheelchair. Eloflex...

  • Page 2: Table Of Contents

    Thanks and good luck! Thank you for choosing an Eloflex as your power wheelchair. It means a lot to us because our vision is to make people’s everyday life a little easier and to give people with disabilities a greater freedom. We hope you experience both with the help of your Eloflex.

  • Page 3: Intended Use

    An Eloflex can have a much longer life if you take • If there is a need to leave the home to get out or to visit...

  • Page 4: Folding

    Folding Fold up Stand the folded chair upright and unfold the footrest. Image 1. Grip the handle at the back of the backrest and pull backward. Simultaneously, hold onto the seat cushion with one hand. Image 2. Close the locking latch. Image 3. Extend the tipping guards by pressing the button and then swinging out the tipping guard.
  • Page 5 Folding Collapse Lower the armrests. Image 1. Fold in the tipping guards by pressing the button and then swinging them inward. Image 2. Open the locking latch. Image 3. Grip the handle at the back of the backrest and push forward. Simultaneously, hold onto the seat cushion with one hand.

  • Page 6: Install The Joystick

    Install the joystick Step 1 Mount the joystick in the tube under the armrest and tighten the screw in the desired position. Step 2 Assemble the cable connectors and gently rotate until the pins enter the holes and the grooves in the two connectors engage.

  • Page 7: Charging Instructions

    Charging instructions This is how you charge Start by turning off your Eloflex (all lights on the joystick should be off). Connect the charger to the socket on the front of the joystick. Make sure that the IMPORTANT! contacts’ position matches each other.

  • Page 8: Adjust The Armrests

    Adjust the armrests For optimal seating comfort, you can adjust the height of the armrests. 1. First release the lock by lifting the lock lever. 2. Then raise or lower the armrests to the desired height. 3. Lower the locking lever. TIP! It’s also possible to completely remove the...

  • Page 9: Driving Handle

    Driving Handle The driving handle is used for manually pushing the chair. The driving handle can be folded up when not in use. Anti-tip device You can fold in the tipping guards when folding the chair and during transport. Press the button Fold in the tipping guard.

  • Page 10: Adjustment Of Lumbar Support

    Adjustment of Lumbar Support Model H is equipped with a convenient lumbar support for optimal seating comfort. To adjust the lumbar support, follow these steps: Lift the front of the backrest. Loosen or tighten the lumbar support using the Velcro fastener to your desired level of support.

  • Page 11: Adjust The Locking Mechanism

    Eloflex follows the recommendation bottom. Note that Eloflex is not tested of IATA. as a car seat. We therefore always recommend that the user moves...

  • Page 12: Joystick

    When the batteries are fully Power on and off: Press to reduce the chair’s charged, all bars are white. Press to turn your Eloflex on maximum speed. As the batteries run down, and off. the lines go out in turn.

  • Page 13: Navigate The Menus

    Navigate the menus Change settings You can change the chair's settings such as language, horn volume and measurement units. 1. To enter the settings, press the right multifunction button. A list of multiple choice options will then open. 2. In the multi-choice list, scroll up and down with the speed buttons.

  • Page 14: Driving

    • Always place your feet in the middle of the footrest while driving • Always use anti-tippers when traveling with Eloflex • Driving downhill should always be done at a lower Risk of injury if you collide with other objects in narrow speed passages.
  • Page 15 Eloflex is tested and approved for obstacles up to a maximum Move forward by moving the joystick slowly forward. of 6 cm.

  • Page 16: Safety

    SAFETY General safety instructions There is a risk of personal injury if the power wheelchair • Observe the maximum permissible load (see is used for purposes other than those described in this chapter ”Technical data” at the back of this document.
  • Page 17 Eloflex is tested and approved for gradient with a maximum of 9 degrees. Always have someone with you who Keep your Eloflex out of the reach of children when not in use. can help you. The chair should be stored indoors in frost-free, dry and ventilated areas.

  • Page 18: Technical Specifications

    If you want direct contact with us, you written permission of Eloflex. Eloflex is reserved for any will find contact information on our website, www.eloflex.eu.
