- Page 1 INSTRUCTION MANUAL FOR USE, DRIVING AND SAFETY Read this documentation before using your Eloflex to make sure that you use it in a manner that is safe, and which does not harm you, your environment or your power wheelchair. Eloflex F...
-
Page 2: Table Of Contents
Thanks and good luck! Thank you for choosing an Eloflex as your power wheelchair. It means a lot to us because our vision is to make people’s everyday life a little easier and to give people with disabilities a greater freedom. We hope you experience both with the help of your Eloflex. -
Page 3: Intended Use
An Eloflex can have a much longer life if you take • If there is a need to leave the home to get out or to visit pla-... -
Page 4: Folding
Folding Fold up Step 1 Place the folded chair on the ground as shown on the right. Grasp the backrest and pull upwards to open the chair. Hold on with one hand on the seat cushion. Step 2 It is very Close the lock - this is very important! important that you close... -
Page 5: Install The Joystick Control
Charging instructions This is how you charge Start by turning off your Eloflex (all lights on the joystick should be off). Connect the charger to the socket on the front of the joystick. Make sure that the contacts’... -
Page 6: Lift Armrests
Lift armrests To lift the armrests up and down, first loosen the lock by turning the locking lever half a turn. Then lift the armrests. OPEN It is important that you lock the armrests when you fold them down again by turning the lock lever back half a turn. -
Page 7: Joystick
Power on and off: Press to emptied, the lights go out in speed. turn your Eloflex on and off. turn. Charge when two-thirds of the lights go out. Reduce speed: Press to reduce the chair’s maximum Speed indicator: All bars light speed. -
Page 8: Adjusting The Lock
Loosen the armrests on each side by unscrewing its two brackets. Step 2 Fit the widening sleeve between the chair and the armrest. Reinstall the armrests. You order the widening kit free of charge from Eloflex. Email your order to info@eloflex.eu... -
Page 9: Adjust The Backrest
Adjust the backrest Adjust the angle You can set the backrest slope in three different positions by pulling the locking pins inwards and then changing the position of the back. Adjust the back Fold up the trim of the back by pul- ling it. -
Page 10: Transport And Storage
• When transporting by bus or by handicap transportation, the Eloflex must be attached to the fastening points shown in the pictures at the bottom. Note that Eloflex is not tested as a car seat. We therefore always recommend that the user moves... -
Page 11: Accessories
Eloflex. With att- flight or loading the car. The bag is black and endant control, those walking behind or beside made of durable nylon fabric. -
Page 13: Driving
• Drive through narrow passages with the lowest speed and greatest attention • Always use anti-tippers when traveling with Eloflex • Driving downhill should always be done at a lower speed There is a risk that the wheelchair will tip over if the anti-tip devices are removed, damaged or mounted at a position that •... - Page 14 Read Practice Reverse • Practice makes perfect. Train • Reverse by moving the joystick to drive your Eloflex together slowly backwards. To stop, re- with an assistant by starting on lease the joystick. Remember to an open plan surface, prefera-...
- Page 15 Avoid driving sideways if pos- whether you are turning or app- sible and compensate for any roaching an obstacle. Eloflex is tested and approved side slope by leaning in the for obstacles up to a maximum opposite direction. Always drive of 6 cm.
-
Page 16: Safety
• Always use a seat belt and re-adjust it before each symbols is extra important. If the instructions trip. are not followed, there is a risk of an accident • Drive as close to the new seat as possible when or your Eloflex will be damaged. transferring to another seat. - Page 17 • Be careful when driving on • Be careful when driving up or steep slopes, as the chair is out for an edge. Eloflex is tested Always cross the railway track likely to break. Eloflex is tested and approved for edges up to a...
-
Page 18: Safety
Never be near open If your Eloflex is slow to fold up The chair should be stored fire with your Eloflex. and together, you can lubricate indoors in frost-free, dry and... -
Page 19: Technical Specifications
Technical specifications: FACTS MODEL F WEIGHT 26 kg SPEED 6,5 km/h RANGE 30 km MOTOR 2 x Brushless motors MOTOR EFFECT 2 x 250 Watt BATTERY 2 x Lithium ION 10 AH / 24 V BATTERY EFFECT 2 x 240 WH... -
Page 20: Contact
If you want direct contact with us, you written permission of Eloflex. Eloflex is reserved for any typo- will find contact information on our website, www.eloflex.eu graphical errors in this document and we reserve the right to product changes.
