TIS VLC-6CH-5A Installation Manual

INSTALLATION MANUAL
TIS POWER RELAY
6 Channels 5 Amps
Model: VLC-6CH-5A
Output
Output switching current
TIS Bus``
Operation
Functions
Dimensions
Housing
BARCODE (UPC-A)
6 58921 79819 5
This product is a power relay switch with
electromagnet for lights' turn ON/OFF or motors'
Open/Close function. It enables smart control over
lights, sprinklers, gates, shutters and curtains, fan
speed, valves, etc. and is ideal for residential and
industrial applications.
P R O D U C T S P E C I F I C AT I O N S
Number of channels
Nominal voltage
Nominal current per channel
Low current
Lighting incandescent lamp
Motors / Air condition
LED and CFL lamp
Max switching current
Max Continues current
Number of devices on 1 line
Bus voltage
Current consumption (Normal)
Current consumption (operation)
Protection
Programming button/LED
1-6 buttons
By TIS bus
Programming
Lighting control ON/OFF
Motor setting
Fan speed control
Width × Length × Height
Materials
Casing color
Button color
IP rating
PRODUCT INFORMATION
6
0 – 230 V AC 50/60 Hz
5 A
4 A
3 A
1 A
5A
4A
Max. 64
12-32 V DC
<20 mA / 24 V DC
<100 mA / 24 V DC
Reverse polarity protection
For assignment of the physical address
Manual ON/OFF & programming
TIS protocol messages & commands
Manual & via software
6 separately controllable channels
Can set 3 groups of curtains (open/close)
Can set 2 groups of fans (low, med, high)
76mm × 73mm × 90mm
Fireproof ABS
Black
Silver
IP 20
