- Page 1 Technical Manual | 808A/B/CH V2.0 Technical Manual The 808 Series Industrial LED Remote Display...
-
Page 2: Table Of Contents
TROUBLESHOOTING ..........................26 Controller Board ............................26 Error Codes ..............................27 Display Messages ............................27 Push Buttons ..............................27 Diagnostic Lights ............................28 Advance Diagnostic ............................28 Protocol Example ............................29 Multiple Display ........................... 29 Anyload Weigh & Measure Inc. @ www.anyload.com... - Page 3 Thank you for choosing Anyload 808A/B/CH industrial remote display. This 808A/B/CH technical manual provides installation, setup, operation, and configuration information for the 808A/B/CH industrial remote display. This manual is intended to be used by trained service technicians and installers. It is recommended to go through the manual in details before installing, operating or configuring the instrument.
-
Page 4: Introduction
Technical Manual | 808A/B/CH V2.0 INTRODUCTION EATURES Designed and developed by Anyload Weigh & Measure Inc. in Canada. Six digits LED industrial remote display, with option of RED/GREEN. • High intensity, wide viewing angle, double row discrete LEDs. • Standard seven segments with capability to display alphanumerical characters. -
Page 5: Technical Specifications
12.5 kg (23 lb) main unit and 1.5 kg (3 lb) mounting kits, approximately 808BH 6.5 kg (12 lb) main unit, approximately 808CH Industry Approvals UL / cUL approved class II power supply, CB CE Anyload Weigh & Measure Inc. @ www.anyload.com | INTRODUCTION... -
Page 6: Installation
AFETY RECAUTIONS Please practice safety before conducting any installation, maintenance, or procedure on device. The 808A/B/CH remote displays are pre-wired AC devices with multi sense voltage. It is necessary to practice safety checks before any installation or maintenance. Do not operate this device unless all instructions in this manual have been read. -
Page 7: Main Enclosure
Technical Manual | 808A/B/CH V2.0 NCLOSURE The main enclosures of the 808A/B/CH are hinged design metal enclosure protected by two toggle latches on the sides for easy service. The enclosure is a weather proof mild steel powder coated with both standard pole mount and wall mount brackets included in the package. All internal parts are installed on a folding metal plate mounted inside of the enclosure. - Page 8 Technical Manual | 808A/B/CH V2.0 • T 808BH WITH UILT IN RAFFIC IGHT ODEL INSTALLATION | Anyload Weigh & Measure Inc. @ www.anyload.com...
- Page 9 Technical Manual | 808A/B/CH V2.0 • T 808CH C OMPACT ODEL Anyload Weigh & Measure Inc. @ www.anyload.com | INSTALLATION...
-
Page 10: Opening Enclosure
To open the cover, unlatch the two toggle latches on both sides of the enclosure and flip down the hinged front cover. To access the electronic components, loosen two retention screws on each sides of the electronic plate of the 808AH remote display. INSTALLATION | Anyload Weigh & Measure Inc. @ www.anyload.com... -
Page 11: Wall Mounting
OUNTING The 808A/BH remote displays may be mounted on the poles by standard pole mount kit provided in the package. The pole mount kit includes two ear mount pieces connected to the main enclosure by six Philips screws, and a pole mount. Have the pole mount fixed on the pole first, then install the enclosure with the ear mount pieces attached on it. -
Page 12: Wiring
Availability of the options is subject to confirmation by manufacturer and may vary by firmware version Refer to the configuration section for instructions on how to configure the functions of remote display Refer to the installation section for instructions on how to access the wiring terminals WIRING | Anyload Weigh & Measure Inc. @ www.anyload.com... -
Page 13: Electrical Power Wiring
OWER IRING The 808A/B/CH remote displays are pre-wired AC devices with regional power cable cord installed via strain reliefs. The proper grounding is provided as default. The standard 808A/B/CH remote displays do not have any ON / OFF power switch. Therefore, before any installations, make sure all power sources are disconnected. -
Page 14: Serial Communication Wiring
OMMUNICATION IRING The 808A/B/CH remote displays provide industry standard serial communication ports with installation via screw terminals. The ports are automatically detected and adjusted upon start up. There are three communication ports available as RS-232, RS-422, RS-485, and 20mA current loop in both active and passive mode. -
Page 15: Multiple Display Wiring
Depending on the application and distances, one of the following methods can be used for multiple remote displays in a multi-drop mode. Up to ten 808A/B/CH remote displays can be wired in multi scale mode. Echo out ports functionality is disabled as default and can be activated in setup menu. -
Page 16: Switch And Relay Wiring
The switch and relay functions are disabled as default Refer to the configuration section for instructions to how to configure inputs and outputs Refer to the installation section for instructions to how to access to the wiring terminals WIRING | Anyload Weigh & Measure Inc. @ www.anyload.com... -
Page 17: Configuration
CONFIGURATION UNCTION ETUP The function setup menu is consisted of different function blocks used to set different configuration values of 808A/B/CH remote displays. There are five function blocks currently available for configuration showed in the table below. Block Menu Description... -
Page 18: Membrane Keypad
EMBRANE EYPAD The setup menu is used to configure main operating functions of the 808A/B/CH remote display. A four keys membrane keypad, located at bottom of the enclosure, is used to enter into, exit from, and navigate through setup menu functions. - Page 19 A SAVED XITING ETUP message will be displayed and then it will reset. To exit without saving, press and hold TEST button. & Long Press Anyload Weigh & Measure Inc. @ www.anyload.com | CONFIGURATION...
-
Page 20: F1 Display Setting
Filter Display 0.50 0.5 sec It can be used based on sensitivity of the indicator. 0.75 0.75 sec It can be used combined with blank on motion function. 1.00 1 sec CONFIGURATION | Anyload Weigh & Measure Inc. @ www.anyload.com... -
Page 21: F2 Utility Setting
The display will show OVER if weight is out of the set range. 999999 999999 Use short and long press keys to change value and digit respectively. If set to 000000, the Over Range function is off. Anyload Weigh & Measure Inc. @ www.anyload.com | CONFIGURATION... -
Page 22: F3 Protocol Setting
It determines over / under load conditions. Over Load It searches O in string. It searches C in string. It searches E in string. If set None, over cap is off. CONFIGURATION | Anyload Weigh & Measure Inc. @ www.anyload.com... -
Page 23: F4 Communication Setting
Set to passive mode if the indicator supplies current as default. Active Mode Set to active mode if the indicator is in passive mode. To use this function refer to indicator user manual for proper setting. Anyload Weigh & Measure Inc. @ www.anyload.com | CONFIGURATION... -
Page 24: F5 Auxiliary Setting
It shows predefined messages on display if SW2 is not disabled. Switch 2 Refer to the wiring chapter and switch section of the manual. Message Default messages are as follows: OPEN STOP HALT QUIT CONFIGURATION | Anyload Weigh & Measure Inc. @ www.anyload.com... -
Page 25: Utilities
ULTIPLE ISPLAY Depending on the application up to ten 808A/B/CH remote displays can be configured in multi display mode. The echo out ports functionality is disabled as default and can be activated in setup menu. The table below shows the configuration and setup of remote displays in multi display mode. -
Page 26: Traffic Light
If set to 0, both SW1 and SW2 are disabled as default. F5.0 The RED / GREEN is controlled by software Switch Function GREEN / RED RED / GREEN Solid F5.2 Traffic Light Function UTILITIES | Anyload Weigh & Measure Inc. @ www.anyload.com... - Page 27 BLINKING R Set traffic light in blinking RED BLINKING G Set traffic light in blinking GREEN FLASHING ON Flashes weight display every seconds FLASHING OFF Undo flashing display to solid weight Anyload Weigh & Measure Inc. @ www.anyload.com | UTILITIES...
-
Page 28: Troubleshooting
Technical Manual | 808A/B/CH V2.0 TROUBLESHOOTING The 808A/B/CH remote displays have comprehensive tools for troubleshooting, including diagnostic lights, onboard push buttons, error codes, message codes, and advance diagnostics inside setup menu. In cases where the display is not detected, shifted, or displaced, diagnostic tools can be used to identify the problems. -
Page 29: Error Codes
Shows version number LOCK LOCK Loads protocol and baud from stored values Locks to latest successful configuration Avoids unnecessary delays at start up Locks if learn is successful at start up Anyload Weigh & Measure Inc. @ www.anyload.com | TROUBLESHOOTING... -
Page 30: Diagnostic Lights
Displays software version Version F9.7 XX-XX None Displays model number Model F9.8 Reserved None Protocol Alternative setup reset F9.9 Abort Reset Initialize Resets all setup values to default, except string settings TROUBLESHOOTING | Anyload Weigh & Measure Inc. @ www.anyload.com... -
Page 31: Protocol Example
ROTOCOL XAMPLE The standard string format to be received by 808A/B/CH includes start of the text character, weight numeric values, unit character, status character, and end of the text character. An example of string protocol for single remote display application connected to an indicator is illustrated below. - Page 32 #4 <CR>, it sets the address to 4. @ ENTER<CR>, display ENTER on display 4 @ ( <CR>, display flashing ENTER on display 4 @ ) <CR>, ENTER on display 4 TROUBLESHOOTING | Anyload Weigh & Measure Inc. @ www.anyload.com...
- Page 33 Type B .... GR, NT, lb, kg......DEVELOPED IN CANADA 808AH651-02RCC..Type I .... GR, NT, kg, t......808AH651-02RF..Type F ..GR, NT, kg, t......9.0 www.anyload.com © 2019 ANYLOAD V3 dimensions and specifications subject to change without notice...
- Page 34 Technical Manual | 808A/B/CH V2.0 Please Contact our Authorized Dealer for Technical Assistance: Anyload Weigh & Measure Inc. North America Toll Free: 1.855.ANYLOAD (269.5623) Email: info@anyload.com www.anyload.com...
