- Page 1 TVP-B/TVP-P Price Computing Scales V1.08...
-
Page 2: Table Of Contents
TVP-B/TVP-P Price Computing Scales Operation Manual Contents 1. INTRODUCTION---------------------------------------------------------------------------------------- - 1 - 2. KEY DESCRIPTION------------------------------------------------------------------------------------- 1 - 3. DISPLAY SYMBOLS----------------------------------------------------------------------------------- - 1 - 4. GENERAL INSTRUCTION--------------------------------------------------------------------------- - 2 - 5. BASIC OPERATION------------------------------------------------------------------------------------- - 2 - 5. 1 Power ON/OFF---------------------------------------------------------------------------------- - 2 - 5. -
Page 3: Introduction
TVP-B/TVP-P Price Computing Scales Operation Manual 1. INTRODUCTION TVP-B, TVP-P series of economic price computing scales are very compact, reliable, high accuracy and much stable. It use LCD display with white LED back light, with the different back light operation. -
Page 4: General Instruction
TVP-B/TVP-P Price Computing Scales Operation Manual Save Indicator SAVE Battery charging indicator CHARGE Accumulation indicator Check out indicator Pre-tare indicator 4. GENERAL INSTRUCTION 1．When battery goes low, the BATT symbol indicator will be show on automatically. It is the time to charge the battery with the AC power. If scale goes on being used without proper charging, the display window will show “BAT LO”... -
Page 5: Tare
TVP-B/TVP-P Price Computing Scales Operation Manual 5. 3 Tare Put container on the platter,once the weight reading is stable, press the TARE key, the TARE indicator will be on and the container’s weight will be deducted. When it is time to clear the TARE, take off the container, and press TARE key again. -
Page 6: Accumulative Operation
TVP-B/TVP-P Price Computing Scales Operation Manual Confirm the platter is empty,the current accumulator values is reset to zero, and the weight reading is stable.only when weight more than 20d 6. 2 Accumulative operation Put the weighing item on platter，wait for the weight reading to be stable, press the M+ key，the window will show total x，this is current total value. -
Page 7: Automatic Unit Price Clear
TVP-B/TVP-P Price Computing Scales Operation Manual Display Description Backlight will be turned on, when start to bLSEt ModE AUto use or when weight is not in zero. Backlight will be turned always on bLSEt ModE on Backlight function will be turned off bLSEt ModE oFF 8.2 Automatic unit price clear Scale can set automatic unit price clear, when return to zero, scale will clear the unit price... -
Page 8: Dimensions (Inch/Mm)
TVP-B/TVP-P Price Computing Scales Operation Manual 10. DIMENSIONS (inch/mm) 11. ERROR MESSAGE Error Message Description Solution Zero setting range exceeded due to Zero setting error switching on. Err 4 Make sure platform empty. Make sure platform empty and check the A/D value out of range pan is installed proper. -
Page 9: Selecting The Printer
Press M+ key to send data to DLP-50 label printer LP50 13. RS232 OUTPUT The TVP-B& TVP-P Series of scales can be ordered with a standard RS-232 output. It can be connected to DEP-50 receipt printer & DLP-50 label printer 13.1 Print Format 13.2 Diagram: Serial interface... -
Page 10: Parameter
TVP-B/TVP-P Price Computing Scales Operation Manual 14. PARAMETER PARAMETER SETTING Enter into the Menu Turn on the scale. Press and hold key during the self test. Display will show “Pn” briefly PIN is activated. Press the PIN number to get into the parameter menu. - Page 11 TVP-B/TVP-P Price Computing Scales Operation Manual 8 data bits, no verify, 1 stop bit 7 data bits, Even verify, 1 stop bit 7 data bits, Odd verify, 1 stop bit To set change function on F12 change CHAN To set change function off Press key to choose "lb", “...
