Timer Installation and Reset Instructions

Blue reset button
Timer cap
2 AAA
batteries
Timer base
Timer seat
Head
003
005
004
006
• What does this warranty cover?
— Any defect in materials or workmanship in the manufactured product.
• What does this warranty not cover?
— Filter cartridge and batteries after 30 days from date of purchase.
— Service trips to your home to teach you how to use the product.
— Improper installation, delivery or maintenance.
— Failure of the product if it is abused, misused, altered, used
commercially or used for other than the intended purpose.
— Use of this product where water is microbiologically unsafe or
of unknown quality, without adequate disinfection before or after
the system. Systems certified for cyst reduction may be used on disinfected
water that may contain filterable cysts.
— Damage to the product caused by accident, fire, floods or acts of God.
— Incidental or consequential damage caused by possible defects with
this appliance, its installation or repair.
• For how long after the original purchase?
— One (1) year.
Timer battery installation and change
Insert coin or screwdriver in the slot between timer
cap and base. Gently pry them open and separate time
base from cap. Install or change 2 new AAA 1.5-volt
batteries. After having the batteries in place, line up
the base and cap and snap them back together.
It is recommended to change the batteries at least
every 2 filter changes.
Do not mix old and new batteries. Do not mix
alkaline, standard (carbon-zinc) or rechargeable
(ni-cad, ni-mh, etc.) batteries.
009
999
007
LIMITED ONE-YEAR WARRANTY
Installation of timer
Hold the timer body in the center and gently push
timer to its seat at the top of the head. Or attach it in
a remote location for easy viewing.
Timer reset and application
After new batteries are installed or filter is changed,
push and hold the timer blue reset button for
approximately 5 seconds. Release the reset button after
the light flashes 5 times. The light will flash again in
90 days to remind you that it is time to change the filter.

PARTS LIST

Ref. No. Part No.
003 WHTIMER
004 HDCOVER–PLUG Protective Cover with Cover Plug
005 HDHANDLE
006 HDRING
007 HDWRNCH
008 FXHTC
FXHSC
009 HDBRKT–2
999 49-50220-3
To obtain replacement parts, call toll-free 800.626.2002 (U.S.),
800.663.6060 (Canada–English), 800.361.3869 (Canada–French).
008
• How do I make a warranty claim?
— Return to the retailer from which it was purchased, along with a copy
of the "Proof of Purchase." A new or reconditioned unit will be provided.
This warranty excludes the cost of shipping the product to your home.
EXCLUSION OF IMPLIED WARRANTIES—Your sole and
exclusive remedy is product exchange as provided in this
Limited Warranty. Any implied warranties, including the implied
warranties of merchantability or fitness for a particular purpose,
are limited to one year or the shortest period allowed by law.
This warranty is extended to the original purchaser and any succeeding owner
for products purchased for home or office use within the USA. In Alaska, the
warranty excludes the cost of shipping or service to your home or office.
Some states do not allow the exclusion or limitation of incidental or
consequential damages. This warranty gives you specific legal rights, and you
may also have other rights, which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state's
Attorney General.
Contact us at GEAppliances.com, or call toll-free at 800.952.5039 in the U.S.,
or 866.777.7627 in Canada.
