We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this decorative drawer. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
USE AND CARE GUIDE
23.5 IN. X 5 IN.
DECORATIVE DRAWER
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
9 a.m. - 4 p.m. (Central Time), Monday-Friday
1 (855) 439-4663
HAMPTONBAY.COM
Or email us: customer.solutions@yahoo.com
Thank you for choosing Hampton Bay!
THANK YOU
MODEL#
HD-SDUS-122
SKU#
1001810418
OMSID
206954987
(WHITE)
OMSID
207186335
(MOCHA)
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY HD-SDUS-122
Summary of Contents for HAMPTON BAY HD-SDUS-122
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this decorative drawer. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Table of Contents ............2 Hardware Included ..............3 Safety Information ............2 Package Contents ..............4 Warranty ................. 2 Installation ..............5 One Year Limited Warranty ............2 Care and Cleaning ............8 Pre-installation .............. 3 Planning Installation ..............3 Tools Required .................3 Safety Information Please carefully read all precautions and instructions in this manual before you begin. -
Page 3: Pre-Installation
Pre-installation PLANNING INSTALLATION Compare all parts in the packaging with the Hardware Included and Package Contents sections in this manual. If any part appears missing or damaged, do not assemble this product. Contact the Customer Service Team. This product has materials that contain finished and unfinished (raw wood) edges. During assembly, make sure to note in each diagram which way the finished edges are facing. -
Page 4: Package Contents
Pre-installation (continued) PACKAGE CONTENTS Part Description Quantity t f e o t t... -
Page 5: Installation
Installation Attaching left and right side Attaching the bottom panel panels to the back panel Place all of the panels with the channel side at the bottom Slide the bottom panel (E) into the channels on the side and facing inward so the large holes are at the front of the panels (B and C) until it slides firmly into the back panel panel. - Page 6 Installation (continued) Attaching the cam posts Attaching the front panel Screw four cam posts (DD) into the holes on the back of the Place the front panel (A) with cam posts (DD) onto the front panel (A). assembly. Secure the front panel (A) in place by inserting four cam locks (EE) into the holes as shown, and turning the cam locks (EE) 1/4 turn clockwise to lock into place.
- Page 7 Installation (continued) Attaching the handle Separating the drawer glides Attach the handle (CC) to the assembly using two screws NOTE: Do not wipe lubricant from glides. (BB), as shown. Extend the drawer glides (FF) completely. Locate the small, black release tab on the back of the shorter part of the drawer glides (FF).
-
Page 8: Care And Cleaning
Installation (continued) Attaching the drawer glides Finished product Align the holes in the small side of the drawer glide (FF) with the holes at the bottom of the drawer assembly. Attach the drawer glide (FF) using the glide screws (GG). Repeat for the other side of the drawer assembly. - Page 9 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 9 a.m. - 4 p.m. (Central Time), Monday-Friday 1 (855) 439-4663 HAMPTONBAY.COM Or email us: customer.solutions@yahoo.com Retain this manual for future use.
