Item #
Model #
1000 000 000
HD19304
USE AND CARE GUIDE
BAINBRIDGE LOUNGE CHAIR
Questions, problems, missing parts? Before returning to the store,
call Hampton Bay Customer Service
8:00 a.m. - 7:00 p.m., EST, Monday - Friday
9:00 a.m. - 6:00 p.m., EST, Saturday
1-855-HD-HAMPTON
HAMPTONBAY.COM
THANK YOU
We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this lounge chair. We strive
to continually create quality products designed to enhance your home. Visit us online to see our full line of products available
for your home improvement needs. Thank you for choosing Hampton Bay!
Advertisement
Table of Contents
Related Manuals for HAMPTON BAY HD19304
Summary of Contents for HAMPTON BAY HD19304
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in Hampton Bay through the purchase of this lounge chair. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available...
-
Page 2: Table Of Contents
Table of Contents Table of Contents................2 Care Instructions..............2 Safety Information.................2 Pre-Assembly..............3-4 Planning Assembly............3 Warranty..................2 Hardware Included............3 2 Year Frame Limited Warranty..........2 Package Contents............4 What Is Covered................2 Assembly................5-9 What Is Not Covered..............2 Important Safety Instructions SAVE THESE INSTRUCTIONS WARNING: FUELS USED IN LIQUEFIED PROPANE GAS APPLIANCES, AND THE PRODUCTS OF COMBUSTION OF SUCH FUELS, CAN EXPOSE YOU TO CHEMICALS INCLUDING BENZENE, WHICH IS KNOWN TO THE STATE OF CALIFORNIA TO CAUSE CANCER AND CAUSE BIRTH DEFECTS OR OTHER REPRODUCTIVEHARM. -
Page 3: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Assemble this product on a blanket, towel or other soft, non-abrasive surface to avoid scratching the finish. HARDWARE INCLUDED NOTE: Hardware not shown to actual size. _____BB _____ CC _____AA _____ DD _____ EE Part Description Quantity Bolt (M6 x 30 mm) Bolt (M6 x 45 mm) Bolt (M6 x 75 mm) -
Page 4: Package Contents
Pre-Assembly (continued) PACKAGE CONTENTS _______A _______B _______C _______D _______E Part Description Quantity Chair Back Left Arm Right Arm Chair Seat Chair Base HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance. -
Page 5: Assembly
Assembly Attaching the chair seat to the left arm Using bolts (BB) with metal washers (DD) through the holes on the inner side of the chair seat (D) to the predrilled holes on the left arm (B). Do not tighten copletely until assembly is completed. Part Description Quantity... - Page 6 Assembly (continued) Attaching the right arm to the chair seat Place the right arm (C) on the ground, the holes should face the sky, attach the left arm and seat combination (B&D) to the right arm (C) by using bolts (BB) with metal washers (DD) through the holes on the inner side of the chair seat (D) to the predrilled holes on the the right arm (C).
- Page 7 Assembly (continued) Attaching the chair back to the seat and arms combination Pleace the chair back (A) on the ground, attach the seat and arms combination (B,C&D) to the chair back (A) . For the arm top area using bolts (CC) and metal washers (DD) from the side of the top, throught the holes on arms to the pre-drilled holes on the top side of chair back.
- Page 8 Assembly (continued) Attaching the chair base to the seat, arms and back combination Turn the assembled seat, arms and back combination (D, B, C & A) upside down on the ground, attaching the chair base (E) by using bolts (BB) with metal washers (DD) from bottom side through the holes on the chair base (E) into the arms (B&C). Using the provided allen wrench (EE) tighten all the bolts.
- Page 9 Assembly (continued) Completing the assembly With help of another person, carefully turn the assembled chair into upright position. Your chair is now ready for use, so relax & enjoy! HAMPTONBAY.COM Please contact 1-855-HD-HAMPTON for further assistance.
- Page 10 Questions, problems, missing parts? Before returning to the store, call Hampton Bay Customer Service 8:00 a.m. - 7:00 p.m., EST, Monday-Friday 9:00 a.m. - 6:00 p.m., EST, Saturday 1-855-HD-HAMPTON HAMPTONBAY.COM Retain this manual for future use.
