22 ½"
Thank you for choosing Grain Wood Furniture, it is an honor to be in your home!
If you have any questions, feedback, or need replacement parts please contact us at:
grainwoodfurniture.com/help or
Loft Collection
Nightstand
REV - 10/2022
Assembly Instructions
support@grainwoodfurniture.com
17"
Made in Brazil
1-person assembly
Model #
Finish
CLF0403
Brushed White
Brushed Grey
CLF0440
Weathered
CLF0468
Acacia
CLF0489
PH #2
Pine
page 1/12
Advertisement
Related Manuals for GrainWood Loft CLF0403
Summary of Contents for GrainWood Loft CLF0403
- Page 1 Assembly Instructions 17" 1-person assembly 22 ½" PH #2 Model # Finish CLF0403 Brushed White Brushed Grey CLF0440 Weathered Pine CLF0468 Acacia CLF0489 Thank you for choosing Grain Wood Furniture, it is an honor to be in your home! If you have any questions, feedback, or need replacement parts please contact us at: grainwoodfurniture.com/help or support@grainwoodfurniture.com Loft Collection...
- Page 2 PLEASE READ BELOW BEFORE BEGINNING ASSEMBLY Enlist help from a friend or family member as most items require two Ÿ people for proper assembly. Choose a spacious, open area near where the piece will be located once Ÿ assembled. It is easier to move parts than to relocate the furniture after it is fully assembled.
-
Page 3: Hardware List
HARDWARE LIST ATTENTION 20 + 2 4,0x30 Before starting assembly please verify the hardware set is complete. 3,5x14 2 + 1 For missing hardware please contact us at M4x25 grainwoodfurniture.com/help 8 + 1 WARNING: 6,0x10 CHOKING HAZARD Small parts, not for children. 26 + 2 To be assembled by an adult. - Page 4 Part # Description Qty. Right side Left side Lower crosspiece Rear crosspiece Base Drawer front Drawer right side Drawer left side Drawer bottom Drawer back Hardware page 4/12...
- Page 5 Tip : Use a hammer in case dowels are hard to install by hand. 8,0x25 page 5/12...
- Page 6 Glide wheels should be positioned towards the front and bottom of the side panel. 6,0x10 RIGHT Side page 6/12...
- Page 7 Glide wheels should be positioned towards the front and bottom of the side panel. 6,0x10 LEFT Side page 7/12...
- Page 8 Attention: There are no predrilled holes for the A1 screws on part 03. 4,0x30 Attention: There are no predrilled holes for the A1 screws on part 04. 4,0x30 page 8/12...
- Page 9 Attention: There are no predrilled holes for the A1 screws on part 01. 4,0x30 page 9/12...
- Page 10 Attention: There are no predrilled holes for the A4 screws on parts 03 and 04. 3,5x14 Attention: There are no predrilled holes for the A1 screws on part 08. 4,0x30 page 10/12...
- Page 11 Flip the assembled drawer upside down to install glides. Drawer RIGHT Drawer LEFT 6,0x10 page 11/12...
- Page 12 M4x25 page 12/12...
