modway MOD-6705 Manual page 2

MOD - 6356
HARDWARE HEADBOARD
1
2
3
STEP 1
1.1 Open the zip at the Headboard (A) backing and take out all the parts.
1.2 Align pre-drilled Support Wood (B) holes over the pre-drilled headboard holes according to
your desired Headboard (A) height.
1.3 Secure each Support Wood (B) by using 2x JCBB Bolt (1) and 2x M8 Flat Washer (2).
Tighten with supplied Allen Key (3).
Repeat the same procedure to secure the other side.
Note: Hardware may loosen over time.
Periodically check that all connections are tight.
A
Customer Service 609-256-9000 www.modway.com
JCBB BOLT M8 x 60mm 4 PCS
M8 FLAT WASHER 4 PCS
M5 ALLEN KEY 1 PC
HARDWARE BED FRAME
4
5
6
7
8
9
B
JCBB BOLT M6 x 60mm
4 PCS
JCBB BOLT M6 x 35mm
4 PCS
M6 FLAT WASHER
8 PCS
M6 SPRING WASHER
4 PCS
M6 HEX NUT
4 PCS
M4 ALLEN KEY 1 PC
3
1
2
02 of 03
