VHF DIGITAL TRANSCEIVER
NX-720H(G)/720H
SERVICE MANUAL
REVISED
Modular jack
(E58-0535-05)
GENERAL ....................................................2
SYSTEM SET-UP .........................................4
REALIGNMENT ...........................................4
INSTALLATION ............................................7
DISASSEMBLY FOR REPAIR .....................9
CIRCUIT DESCRIPTION ...........................11
COMPONENTS DESCRIPTION ................17
PARTS LIST ...............................................19
EXPLODED VIEW ......................................29
PACKING ...................................................30
TROUBLE SHOOTING ..............................31
ADJUSTMENT ...........................................35
This product complies with the RoHS directive for the European market.
Key top
(K29-9479-01)
CONTENTS
TERMINAL FUNCTION .............................56
DISPLAY UNIT (X54-3830-10) ...............60
TX-RX UNIT (X57-8230-1X)....................62
INTERCONNECTION DIAGRAM ...............66
SCHEMATIC DIAGRAM ............................67
BLOCK DIAGRAM .....................................78
LEVEL DIAGRAM ......................................81
KRA-40 ...................................................82
SPECIFICATIONS .................. BACK COVER
© 2012-12 PRINTED IN JA PAN
B53-7032-10 ( Y )
Panel assy
Badge
(A62-1200-03)
(B43-1675-04)
This product uses Lead Free solder.
