UHF DIGITAL TRANSCEIVER
NX-820(G)/820
SERVICE MANUAL
Modular jack
(E58-0535-05)
GENERAL ....................................................2
SYSTEM SET-UP .........................................4
REALIGNMENT ...........................................4
INSTALLATION ............................................7
DISASSEMBLY FOR REPAIR .....................9
CIRCUIT DESCRIPTION ...........................11
COMPONENTS DESCRIPTION ................17
PARTS LIST ...............................................19
EXPLODED VIEW ......................................29
TROUBLE SHOOTING ..............................30
ADJUSTMENT ...........................................34
This product complies with the
RoHS
Key top
(K29-9479-01)
CONTENTS
directive for the European market.
© 2012-11 PRINTED IN JA PAN
B53-7044-00 ( Y ) 80
Panel assy
(A62-1200-03)
TERMINAL FUNCTION .............................56
DISPLAY UNIT (X54-3830-10) ...............60
TX-RX UNIT (X57-8240-1X)....................62
INTERCONNECTION DIAGRAM ...............66
SCHEMATIC DIAGRAM ............................67
BLOCK DIAGRAM .....................................78
LEVEL DIAGRAM ......................................81
KRA-40 ..................................................82
SPECIFICATIONS ......................................83
Badge
(B43-1675-04)
This product uses Lead Free solder.
