- Page 1 INSTRUCTION & OPERATIONS MANUAL: IV605BV...
- Page 3 OPEN 24 ILVE ACCESSORIES ONLINE SHOP For a wide range of Genuine ILVE accessories at the click of a button shop.ilve.com.au...
-
Page 4: Important Safety Instructions
Important safety instructions When using electrical appliance basic safety precautions should be followed, including the following: warning: to reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: 1.Read all instructions before using the appliance. 2.Use this appliance only for its intended use as described in this manual. - Page 5 a.When heating food in plastic or paper container, keep an eye on the oven due to the possibility of ignition. b.Remove wire twist-ties from paper or plastic bags before placing bag in oven. c.If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
- Page 6 15.Utensils should be checked to ensure that they are suitable for use in microwave oven. 16.Warning: it is hazardous for anyone other than a trained person to carry out any service or repair operation which involves the removal of any cover which gives protection against exposure to microwave energy.
- Page 7 damaged and the warranty would be avoid . 22.The accessible surface may be hot during operation. 23.The microwave oven shall not be placed in a cabinet. 24.The door or the outer surface may get hot when the appliance is operating. 25.The temperature of accessible surfaces may be high when the appliance is operating.
- Page 8 appliance by no other than a specialist because under these circumstances the cover have to be removed which assures protection against microwave radiation. This applies to changing the power cord or the lighting as well. Send the appliance in these cases to our service central. 35.The microwave oven is intended for defrosting, cooking and steaming of food only.
-
Page 9: Specifications
SPECIFICATIONS Power consumption: 220-240V~50Hz,1 Output: 900W Grill Heater: 1 00W Operating Frequency: 2,450MHz Outside Dimensions: 592mm(L) X 380mm(W) X 390mm(H) Oven Cavity Dimensions: 330mm(L) X 330mm(W) X 230mm(H) Oven Capacity: 25 litres Uncrated Weight: Approx. 16.5kg BEFORE YOU CALL FOR SERVICE 1. -
Page 10: Installation
INSTALLATION 1. Make sure all the packing materials are removed from 3. This Microwave Oven weighs 1 7.6 kg and must be the inside of the door. placed on a horizontal surface strong enough to support this weight. 2. Inspect the oven after unpacking for any visual 4. -
Page 11: Safety Instructions For General Use
IMPORTANT SAFETY INSTRUCTIONS -WARNING: When the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated; (Only for the model with grill function) -WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person;... -
Page 12: Feature Diagram
6. Do not insert any object into the openings on the outer removed from the oven, please remember that case. the food/liquid inside will be releasing the same 7. Do not at any time remove parts from the oven such as amount of steam and/or spitting when the lid is the feet, coupling, screws, etc. -
Page 13: Display Window
(1) Display Window (2)Time setting+/- Defrost Grill Combi 3 M.Low (3) Fuction Knob Combi 2 Combi 1 M.High High Disinfect Keep Warm (4) Pausa/Cancel (5) Start/Reset Auto Menu/ Pause/ Start Clock Cancel (6) Auto Menu/Clock (7) open keypress OPEN... - Page 14 Only with a single of a button,you can start simple cooking, it is very convenient and quick to heat a glass of water etc. Example:To heat a glass of milk a) Put a glass of milk onto the glass turntable,and close the door. b) Press the button "Start", the microwave oven will work on P-H1 power for 30 seconds.
- Page 15 Unit:g Menu Weight Rice Vegetable Coffee Popcorn Patato Pizza Bread Chicken Fish Beef Meat Touching (A-01) (A-02) (A-10) (A-07) (A-08) (A-09) (A-11) (A-03) (A-04) (A-05) (A-06) Times 1cup 2cup 3cup 1000 1000 1200 1200 1400 1400 1100 1300 1000 1500 5.
-
Page 16: Care Of Your Microwave Oven
9 Child-Safety-Lock Under oven standby situation,to active the child safty lock,Press “Pause/Cancel” button for 3 seconds,then press “Pause/Cancel” button for 3 seconds again,it will unlock this function. 10 Clock The oven can be used as a clock Example: To input current time 16:30 a)Press “Auto menu/Clock”... - Page 18 FR AM E 20/25/31L BUILT-IN MICROWAVE OVEN INSTALLATION MANUAL COMPONENTS bolt screwcover 1PCS 3 bolt 3 5mm 1PCS TRIM KIT SPECIFICATIONS Cavity dimensions FRAME dimensions Width 566-580mm Width 592mm Height 365-380mm Height 390mm Depth 550mm Depth 20mm MICROWAVE OVEN CABINETRY MICROWAVE LOCATION Cabinet measurement Requirements (illustrated above): 1.
- Page 19 FRAME INSTALLATION STEPS 1. Put the microwave oven into the cabinet keeping the microwave oven upright and check the distance from the two sides is the same. Then fix the bolt (Component 1) on the top of microwave oven and screw it into the cabinet. 2.
-
Page 21: Warranty
(including deterioration of parts and accessories and glass breakage); (b) use for purpose for which the ILVE product was not WARRANTY REGISTRATION sold or designed; Your ongoing satisfaction with your ILVE product is (c) use or installation which is not in accordance with important to us. - Page 22 Act or other statute. Service is delivered through a network of Service (d) The liability of ILVE to you for a breach of any Agents. If the Appliance is located outside our normal Service Area of our agents you, t he...
- Page 23 LUXURY KITCHEN APPLIANCES 1/42 Cavendish Rd Coorparoo, QLD 10/55 Howe St Osborne Park, WA 48-50 Moore St Leichhardt, NSW NATIONAL SERVICE CENTRE Our high quality appliances are designed and manufactured to give you many years of cooking pleasure. Should you have any questions or issues with your appliance please email our national service centre customercare@eurolinx.com.au or phone us on 1300 85 64 11.
