FORNO A MICROONDE COMBI 45
Installazione - Uso - Manutenzione
MICROWAVE COMBI OVENS 45
Installation - Use - Maintenance
FOUR A MICRO-ONDES COMBI 45
Installation - Emploi - Entretien
MIKROWELLENOFEN
Installation - Gebrauch - Wartung
HORNO DE MICROONDAS
Instalación - Uso - Mantenimiento
FORNO MICROONDAS COMBI 45
Instalação - Uso - Manutenção
COMBI
COMBI 45
COMBI 45
IT
GB
FR
DE
ES
PT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ILCM45X and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ILVE ILCM45X

Summary of Contents for ILVE ILCM45X

  • Page 1 FORNO A MICROONDE COMBI 45 COMBI Installazione - Uso - Manutenzione MICROWAVE COMBI OVENS 45 Installation - Use - Maintenance FOUR A MICRO-ONDES COMBI 45 Installation - Emploi - Entretien MIKROWELLENOFEN COMBI 45 Installation - Gebrauch - Wartung HORNO DE MICROONDAS COMBI 45 Instalación - Uso - Mantenimiento FORNO MICROONDAS COMBI 45...
  • Page 2 Italiano English FR Français Deutsch Español Português...
  • Page 3 Dear Customer, We would like to thank you and congratulate you on your choice. This new product has been carefully designed and built using top quality materials, and meticulously tested to ensure that it meets all your culinary requirements. Please read and observe these simple instructions, which will enable you to achieve excellent results from the very first time you use it.

  • Page 4: Warnings For Microwave Ovens

    THIS PRODUCT IS DESIGNED FOR DOMESTIC USE. THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE DERIVING FROM INCORRECT INSTALLATION OR IMPROPER, ERRONEOUS OR UNSUITABLE USE. THE APPLIANCE MUST NOT BE USED BY PEOPLE (INCLUDING CHILDREN) WITH PHYSICAL, SENSORIAL OR MENTAL IMPAIRMENTS, OR BY PEOPLE WITHOUT THE NECESSARY EXPERIENCE OR KNOWLEDGE, UNLESS THEY ARE SUPERVISED OR INSTRUCTED IN THE USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
  • Page 5 Danger of injury! Pots and pans Porcelain and ceramic crockery can have small holes in the handles and cover. There can be cavities hidden behind these holes. If water gets into these cavities, the crockery could break. Do not use crockery that is unsuitable for microwave ovens. Danger of burns! The heat of the food can heat the dish.

  • Page 6: Causes Of Damage

    Danger of burns! Foods with skin or peel Never cook eggs in the shell. Never heat hard-boiled eggs because they could explode even after the microwave is turned off. This also goes for molluscs and crustaceans. In the case of fried eggs, first pierce the yolk. In the case of foods with a hard peel or skin like apples, tomatoes, potatoes or sausage, the peel or skin could explode.

  • Page 7: First Use

    IMPORTANT The oven’s identification plate is even accessible when the appliance is installed. This identification plate, which is visible when you open the door, shows all the information you will need when requesting replacement parts for the appliance. FIRST USE The oven should be thoroughly cleaned with soap and water and carefully rinsed.

  • Page 8: Respect For The Environment

    Important: As a safety precaution, before cleaning the oven, always disconnect the plug from the outlet or remove the appliance’s power cord. In addition, avoid using acid or alkaline substances such as lemon, vinegar, salt, tomatoes, etc.). Avoid using products containing chlorine, acids or abrasives, especially for cleaning the painted walls.
  • Page 9 MICROWAVE OVEN M45 Command Overview STANDARD COOKING FUNCTION: from 1 to 5; TEMPERATURE SETTING, COOKING TIME: 19 and 20; ON/OFF + KEY (CHILD LOCK): 27; FUNCTIONS WITH MICROWAVES: from 6 to 12; FUNCTIONS for RECIPES: 11 a 12; POWER AND MENU SCROLL FUNCTIONS: 13 and 14; TIMER FUNCTIONS: 24;...
  • Page 10 INTRODUCTION TO THE OVEN Dear Customer, your new oven is controlled by an electronic board that constantly monitors its operation to improve its performance. The touch controls are state-of-the-art, precise and reliable. The interface is elegant, orderly and discrete, more intuitive than ever! A few buttons, many functions and no combination or sequence is difficult to enter, so you can concentrate on following the recipe and the oven is ready in two clicks! Installation and hook-up...
  • Page 11 Setting the clock The oven will signal that it is connected to the power mains with a double beep. To set the system time, press the “TIMER FUNCTIONS” button for at least 3 seconds Each command activated is confirmed by a beep. Set the clock with the + and - buttons: during setting the separator dots flash, the time has been set when the dots remain steady on.

  • Page 12: Turning On The Oven

    - Setting the “minute-counter” timer function See the appropriate section on page 48. TURNING ON THE OVEN Turn the oven on by pressing the symbol shown in figure. to activate the oven functions, always press except for the light and timer functions, which are independent The command activates all the icons by lighting up their backgrounds.

  • Page 13: Main Functions

    MAIN FUNCTIONS Overview of the command panel Cooking functions Special functions Programming the oven Oven ON/OFF Lock oven ON/OFF Temperature/Power Lock Clock The cooking functions The provides eleven specific cooking functions! To activate a function, just touch the corresponding symbol Each function has a temperature setting selected on the basis of cooking tests of the recipes that are typically used, which can be easily changed based on your own experience.
  • Page 14 Oven functions The oven light is always on during operation in microwave mode and, to save energy, is managed by the system in the other modes. In this type of cooking, a fan located in the rear part circulates warm air inside the oven, distributing it uniformly.
  • Page 15 Simple cooking commands Thanks to state-of-the-art controls, only two touches are required to set a cooking mode: turn on the oven and select the most suitable function for the dish you are about to cook… you choose it and you touch it! The control suggests a temperature for each function, which you can change at any time, but if you consider it suitable, you don’t need to do anything else, the oven will start by itself in just a few seconds! Setting the temperature...

  • Page 16: Programming The Oven

    Use this characteristic to keep foods warm or to complete their cooking gently! COven light control The oven light control is active in all cooking functions and is independent of them, i.e., it can be turned on or off depending on the need, whenever you want! The oven light is normally kept on during heating and, then, for three after the temperature setting is reached.
  • Page 17 Timer programming: cooking time Touch the timer symbol once and the relative symbol will light up. Plus, the clock display will replace the current time: The separator dots flash to indicate that you can program the cooking time. Once the cooking time is entered, the display will flash the current time again and the “cooking time”...
  • Page 18 Set the end-of-cooking time by touching the “+” and “-” symbols. Once the end-of-cooking time is entered, the display will flash the current time again and the “end-of-cooking time” symbol will be lit. The countdown starts now. When the set time has been reached, the oven will beep and the heating elements will turn off, ending cooking.
  • Page 19 Change the end-of-cooking time to what you want, in our example 13:00 The oven goes to standby mode, turning off the oven light. The control automatically turns the oven on at 11:00 (13:00-2:00) and turns it off at 13:00. The roast will be ready when you return! Programming the timer: minute-counter The minute-counter is a function of the timer that is independent from the operation of the oven, i.e., it does not...

  • Page 20: Operation With Microwaves

    OPERATION WITH MICROWAVES The microwaves are transformed into heat inside foods. The microwave oven can be used by itself or in combina- tion with other types of heating. This section contains information about the dishware and instructions for setting the microwave oven. WARNINGS FOR DISHWARE You can use heat-resistant dishware made of glass, glass ceramic, Suitable dishware...
  • Page 21 Time defrosting Turn the oven on using the button; Select the TIME DEFROSTING function Using the - + buttons, you can change the defrosting time in 5-second intervals. If you press - + for longer than 3 seconds, the time setting speeds up; When finished entering settings, select the function that is flashing, and defrosting begins with a countdown of the time on the display.
  • Page 22 countdown of the time. The beep and the words PROGRAM FINISHED REMOVE THE DISH on the display signal that the program has finished. The power of the microwave will be automatically adjusted for the best possible results. At a certain point, the oven will ask you to TURN OVER THE FOOD or, if you can’t, open and close the door of the oven to make it continue defrosting.
  • Page 23 W. On the other hand, use the - + buttons to set the cooking time in 5-second intervals. If you press - + for longer than 3 seconds, the setting speeds up; When finished entering settings, select the function that is flashing, and cooking begins with a countdown of the time on the display.
  • Page 24 The display shows the 2 options: - personal recipes; - preset recipes Choose the desired setting with the buttons; using the button, confirm the choice; the following menu appears; press the buttons to select the type of dish and the button to confirm the choice.
  • Page 25 ATTENTION: certain recipes use pre-heating, so put the dish in when the oven has reached the set temperature and the display shows “PRE-HEATING FINISHED PUT IN THE DISH” When cooking is finished the display will flash “PROGRAM FINISHED REMOVE THE DISH”...
  • Page 26 - then, after selecting the recipe to be deleted, press until the following screen appears: By default, the selection will be set to NO, but, by pressing the + and - scroll keys, select YES and confirm with - The display tells you that the recipe has been deleted...

  • Page 27: For The Installer

    FOR THE INSTALLER Install the oven in the counter The oven must be installed under a cook top, in a column, or combined with the relative food-warmer drawer. The dimensions of the space must be those shown in figure. The cabinet material must be able to withstand the heat. The oven must be centred within the walls of the cabinet and fixed with the screws and bushings that are provided.

  • Page 28: Technical Data

    TECHNICAL DATA Power supply 220-240 V~, 50Hz Maximum absorbed power 3200 W Microwave power 900 W Grill 1500 W Hot air 1500 W Microwave frequency 2450 MHz ELECTRICAL HOOK-UP Before making the electrical hook-up, make sure that: - the characteristics of the electrical system satisfy what is shown on the serial number plate applied to the front of the oven;...
  • Page 30 Cod. 2.002.60.1 - 2ed...
