INSTALLATION INSTRUCTIONS
MANROSE CLASSIC XF/XP125 CEILING/WALL
EXTRACTOR FANS
(The 'new' ball bearing designed motors provide an extended lifetime of operation)
NOTE: (i) The fan is to be installed so that the blades are 2.1m above the floor. For best results
Diagram 2B
1.
Rotary adjuster
for time delay
2.
3.
4.
5.
6.
7.
PUB7007 2212
this Extractor Fan should be fitted as high on the wall as possible, or if preferred, on
the ceiling.
(ii) Do not install the unit within a shower cubicle. Use our shower fan models no's
SF125S or SF125T.
(iii) Switch off mains supply before making electrical connections. This system should
be installed by a qualified electrician.
(iv) This fan is double insulated and does not require an earth.
(v) When installing fan through an external wall, an external wall grille must be fitted
at all times.
Cut a 140mm diameter hole in the wall. If the fan is to be fixed onto the ceiling ensure that
the hole is between the joists.
Fit 125mm ducting flush to the plaster.
Remove the cover from the fan by simply unclipping the fascia. The front cover screw and
plug are conveniently located within the fan housing as shown in diagram 1 & 2.
Hold the body of the fan against the wall or ceiling and mark the four screw holes and the
cable entry.
IMPORTANT: Ensure that the fan is square on wall the or ceiling.
Bring power cable into position, as marked. Allow an extra 230mm (9") protruding to
facilitate connection.
Fan should only be installed by fixed wiring, a flexible cord should not be used.
If an XP125 kit - Select a suitable position on the outside wall for the weatherproof cowl.
Carefully remove the cowl from its housing by levering gently at the sides with a small
screwdriver. Cut a 140mm hole ensuring first that the area is free from obstruction.
Wiring of Standard Model XF125S and XP125S (see Diagram 2A).
(For remote switch operation).
The fan can be connected to the light switch so that the fan will start when the light is switched
on. The fan should not be accessible to a person using either the shower or the bath.
NOTE: All wiring must be fixed securely and the cable to the fan should be a minimum of
1mm in section. All wiring must comply with current Regulations. This system should be
2
installed by a qualified electrician.
