MANUAL
ENGLISH
PixelTile P25 MKII
V1
Ordercode: 42277
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PixelTile P25 MKII V1 and is the answer not in the manual?

Questions and answers

Summary of Contents for DMT PixelTile P25 MKII V1

  • Page 1 MANUAL ENGLISH PixelTile P25 MKII Ordercode: 42277 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
  • Page 2: Table Of Contents

    PixelTile P25 MKII Table of contents Warning ....................................2 Safety Instructions ................................. 2 Operating Determinations ............................4 Rigging .................................... 4 Connection with the mains ............................5 Return Procedure ................................5 Claims ....................................5 Description of the device ..............................6 Frontside..................................6 Backside..................................
  • Page 3: Warning

    Save the carton and all packing materials. In the event that a fixture must be returned to the factory, it is important that the fixture be returned in the original factory box and packing. Your shipment includes: DMT PixelTile P25 MKII • Blue/White power cable (1,5m) •...
  • Page 4 • If your DMT device fails to work properly, discontinue the use immediately. Pack the unit securely (preferably in the original packing material), and return it to your DMT dealer for service.
  • Page 5: Operating Determinations

    PixelTile P25 MKII Operating Determinations • This device is not designed for permanent operation. Consistent operation breaks will ensure that the device will serve you for a long time without defects. • The minimum distance between light output and the illuminated surface must be bigger than 1 meter.
  • Page 6: Connection With The Mains

    PixelTile P25 MKII Connection with the mains Connect the device to the mains with the power-plug. Always check if the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER PHASE BLUE BLACK SILVER NEUTRAL...
  • Page 7: Description Of The Device

    PixelTile P25 MKII Description of the device Features The PixelTile P25 MKII is a LED strip fixture with great effects and high output. It supports the most popular control protocols, such as DMX, ArtNet and KlingNet. Power Supply: 100-240 VAC, 60/50Hz •...
  • Page 8: Backside

    PixelTile P25 MKII Backside Fig. 02 02) Safety eye 03) Mounting rail 04) LED display + menu buttons 05) Mounting rail 06) Blue/White power connector 100-240V OUT 07) 3-pin DMX signal connector OUT 08) RJ45 ArtNet/KlingNet signal connector 09) Mounting rail 10) Ground/earth connection 11) RJ45 ArtNet/KlingNet signal connector 12) 3-pin DMX signal connector IN...
  • Page 9: Installation

    PixelTile P25 MKII Installation Remove all packing materials from the PixelTile P25 MKII. Check if all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing. Damages caused by non-observance are not subject to warranty.
  • Page 10: Control Modes

    PixelTile P25 MKII Control Modes There are 3 modes: • Auto Mode • Master/Slave • DMX-512 (8CH and 432CH)/ArtNet/KlingNet One PixelTile (Auto Mode) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Plug the end of the electric mains power cord into a proper electric power supply socket.
  • Page 11: Multiple Pixeltiles (Dmx Control)

    PixelTile P25 MKII Multiple PixelTiles (DMX Control) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a 3-pin XLR cable to connect the PixelTiles and other devices. 04) Link the units as shown in fig.
  • Page 12: Multiple Pixeltiles (Artnet/Klingnet Control)

    PixelTile P25 MKII Multiple PixelTiles (ArtNet/KlingNet Control) 01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation. 02) Always use a safety cable (ordercode 70140 / 70141). 03) Use a CAT-5/CAT-6 cable to connect the PixelTiles and other KlingNet devices. 04) Link the units as shown in fig.
  • Page 13: Fixture Linking

    PixelTile P25 MKII Fixture Linking You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined number of channels required by all the fixtures on a serial data link determines the number of fixtures the data link can support.
  • Page 14: Control Panel

    PixelTile P25 MKII The PixelTile P25 MKII can be operated with a controller in control mode or without the controller in stand-alone mode. Control Panel A) LED display MENU button C) ENTER button D) UP button DOWN button Fig. 07 Control Mode The fixtures are individually addressed on a data-link and connected to the controller.
  • Page 15: Menu Overview

    PixelTile P25 MKII Menu Overview Main Menu Options Auto Mode DMX channels DMX address Software information Network settings Master/Slave Mode Ordercode: 42277...
  • Page 16: Auto Mode

    PixelTile P25 MKII 1. Auto Mode With this menu, you can set the built-in programs. 01) Press the UP/DOWN buttons until the display shows 02) Press the ENTER button to open the menu. 03) Press the UP/DOWN buttons to toggle between the following 2 options: Program speed Program choice , press the ENTER button to open the menu.
  • Page 17: Software Information

    PixelTile P25 MKII 4. Software Information With this menu, you can check the currently installed software version. 01) Press the UP/DOWN buttons until the display shows 02) Press the ENTER button to open the menu. 03) The display shows the current software version: 5.
  • Page 18: Dmx Channels

    PixelTile P25 MKII DMX Channels 8 channels Channel 1 – Dimmer intensity 0-255 Gradual adjustment, from dark to brightest 0-100% Channel 2 – Strobe 0-255 Strobe frequency, from low to high frequency Channel 3 – Red Dimmer must be open 0-255 Gradual adjustment Red, from 0-100% Channel 4 –...
  • Page 19: 432 Channels

    PixelTile P25 MKII Channel 8 – Program speed 0-255 Speed adjustment, from slow to fast 432 channels Channel 1 – Red LED 1 0-255 Gradual adjustment Red, from 0-100% Channel 2 – Green LED 1 0-255 Gradual adjustment Green, from 0-100% Channel 3 –...
  • Page 20: Connecting To A Network

    PixelTile P25 MKII Connecting to a Network KlingNet settings 01) Install any KlingNet-based software on your PC (Windows or Mac), for example 50180 – Arkaos LED Master. 02) Connect the power supply to the PixelTile P25 MKII. 03) Make sure that your PC has a fixed IP Address. The PixelTile P25 MKII requires no further network setting adjustments.
  • Page 21: How To Make A Data Cable

    (fig. 08). The wires should now be colored as follows: Fig. 08 Software for controlling In combination with Arkaos or DMT Software, you are able to play videos over the PixelTile P25 MKII (pixelmapping). You only have to connect all PixelTiles P25 MKII and run your software. 50180 Arkaos LED Master An all-in-one solution to run LED light shows for everyone.
  • Page 22: Maintenance

    Suspect two potential problem areas as: the power supply and the LEDs. 01) Power supply. Check that the unit is plugged into an appropriate power supply. 02) The LEDs. Return the PixelTile to your DMT dealer. 03) If both of the above appear to be O.K., plug the unit in again.
  • Page 23: No Response To Dmx

    • Return the device to your local Internal fuse blown DMT dealer. Fixtures reset The controller is not connected. • Connect controller. correctly, but all 3-pin XLR Out of the controller •...
  • Page 24: Product Specifications

    PixelTile P25 MKII Product Specifications Model: DMT PixelTile P25 MKII Input Voltage: 100-240 VAC, 60/50Hz Power consumption: 65W (full output) DMX linking: 30pcs Dimensions: 300 x 300 x 110 mm (LxWxH) Weight: 3 kg Operating and Programming: Signal pin OUT:...
  • Page 25: Dimensions

    PixelTile P25 MKII Dimensions Ordercode: 42277...
  • Page 26: Notes

    PixelTile P25 MKII Notes Ordercode: 42277...
  • Page 27 PixelTile P25 MKII Ordercode: 42277...
  • Page 28 ©2015 D.M.T.
