- Page 1 MANUAL ENGLISH D1 Videomixer with scaler Ordercode: 101281 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
D1 Videomixer Table of contents Warning ....................................3 Safety Instructions ................................. 3 Operating Determinations ............................4 Connection with the mains............................5 Return Procedure ................................5 Claims ....................................5 Description of the device ..............................6 Front ....................................7 Back ....................................8 Installation ................................... - Page 3 D1 Videomixer PST/PGM Logo ................................31 Maintenance ..................................31 Troubleshooting ................................31 No Output ..................................31 Screen Only Displays a Part of the Image ......................31 Output Does Not Fill the Entire Screen ........................32 Black Spots Appear on the Sides of the Screen ....................32 Product Specifications ..............................32 Dimensions ..................................33...
-
Page 4: Warning
D1 Videomixer Warning Unpacking Instructions Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure that all parts are present, and have been received in good condition. Notify the dealer immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. -
Page 5: Operating Determinations
Never attempt to bypass the thermostatic switch or fuses. ● The user is responsible for correct positioning and operating of the D1 Videomixer. The manufacturer will not accept liability for damages caused by the misuse or incorrect installation of this device. -
Page 6: Connection With The Mains
D1 Videomixer Connection with the mains Connect the device to the mains with the power-plug. Always pay attention, that the right color cable is connected to the right place. International EU Cable UK Cable US Cable BROWN YELLOW/COPPER FASE BLUE... -
Page 7: Description Of The Device
D1 Videomixer Description of the device The D1 Videomixer makes video scaling and mixing more accessible and intuitive than ever before. It is equipped with the latest technologies and innovations, which makes it a fully integrated all-in-one video processor. The integrated touch screen and the large illuminated buttons make accessing the different functions an easy task. -
Page 8: Front
D1 Videomixer Front Fig. 01 01) Audio source fader Move the fader to adjust the input volume. The CUE button (15) must be lit for this fader to work. 02) Master audio fader Move the fader to set the volume for all the channels. The CUE button (15) must be lit for this fader to work. -
Page 9: Back
D1 Videomixer 12) PST output area Press the 6–9 buttons to select a preview input source. The pressed button will light up: ● If a button is continuously on: This input is currently active and cannot be edited. ● If a button is flashing: This input can be edited. -
Page 10: Installation
D1 Videomixer Installation Remove all packing materials from the D1 Videomixer. Check that all foam and plastic padding is removed. Connect all cables. Do not supply power before the whole system is set up and connected properly. Always disconnect from electric mains power supply before cleaning or servicing. -
Page 11: Menu Overview
D1 Videomixer Menu Overview Ordercode: 101281... - Page 12 D1 Videomixer Ordercode: 101281...
- Page 13 D1 Videomixer Ordercode: 101281...
-
Page 14: Main Menu Options
D1 Videomixer Main Menu Options The display is equipped with a touch screen, which means that the options can be accessed in 2 ways: ● By turning (to select/adjust the values) and pressing the menu control (to open/confirm). ● By touching the options directly on the screen. - Page 15 D1 Videomixer 1. Input 2. Output 3. Freeze 4. Black 5. Scale 6. Transition 7. DSK 8. Blend 9. Logo 10. Mask 11. Audio Input 12. Audio Output 13. Front Panel Lock 14. Settings 15. Factory Reset Ordercode: 101281...
-
Page 16: Input
D1 Videomixer 1. Input In this menu you can set the input settings. 01) While in main menu, select and open the menu. The display will show: 02) Select one of the 4 inputs and enter its settings menu. 03) In the settings menu, select/adjust one of the following settings: ●... -
Page 17: Output Format
D1 Videomixer 2.1. Output Format In this menu you can set the output format settings. 01) Press the menu control (05) to open the menu. 02) Touch the list of screen resolutions. The display will show ‘This operation will clear saved banks.’... -
Page 18: Freeze
D1 Videomixer 3. Freeze In this menu you can set the freeze function. 01) While in main menu, select and open the menu. The display will show: 02) Select one of the 4 options: ● LIVE: Select this option to reactivate the currently frozen layers. -
Page 19: Black
D1 Videomixer 4. Black In this menu you can enable/disable blackout function. This function works for the program output and the preview output. 01) While in main menu, select and open the menu. The display will show: 02) Select ON/OFF. -
Page 20: Transition
D1 Videomixer 6. Transition In this menu you can set the desired transition effect. 01) While in main menu, select and open the menu. 02) Select one of the following transition effects: Iris box Wipe to right Wipe to bottom... -
Page 21: Dsk
D1 Videomixer 7. DSK In this menu you can set the DSK function. This function only works for the layer B. 01) While in main menu, select and open the menu. 02) Select/adjust the following settings: ● DSK: Select ON/OFF to enable/disable the DSK function. -
Page 22: Logo
D1 Videomixer 9. Logo In this menu you can set the logo. For more information about how to create a logo, see pages 29–31. 01) While in main menu, select and open the menu. 02) Select/adjust the following settings: ●... -
Page 23: Audio Input
D1 Videomixer 11. Audio Input In this menu you can set the audio input settings. 01) While in main menu, select and open the menu. The display will show: 02) Select one of the 4 audio inputs and enter its settings menu. -
Page 24: Front Panel Lock
D1 Videomixer 13. Front Panel Lock In this menu you can set the front panel lock. 01) While in main menu, select and open the menu. 02) Select ON/OFF to enable/disable the front panel lock. 03) In order to unlock the front panel, press and hold down the menu button (06) for 3 seconds. -
Page 25: Ethernet
D1 Videomixer 14.3. Ethernet In this menu you can set the Ethernet settings. 01) Select/adjust one of the 5 settings: ● DHCP: Select ON/OFF. It must be set to ON for the user to be able to set the IP address, subnet mask, gateway and state. -
Page 26: Gateway
D1 Videomixer 14.3.3. Gateway In this menu you can set the gateway. 01) The display will show: 02) Turn the menu control (05) until the current gateway lights up. 03) Press the menu control (05) to be able to edit the gateway. -
Page 27: Key Board
D1 Videomixer 14.6. Key Board In this menu you can set the keyboard settings. 01) Select/adjust one of the 2 settings: ● CUSTOM ● KEY BOARD TEST 14.6.1. Custom In this menu you can assign different functions to the MASK, PGM LOGO and PST LOGO buttons. -
Page 28: Factory Reset
03) After you have selected one of the 2 options, the display will ask you to confirm your choice. Select YES/NO. Operations Start-up 01) Make sure that the D1 Videomixer is OFF. 02) Connect the video sources to the HDMI inputs (22). 03) Turn all video sources ON. 04) Turn the D1 Videomixer ON. -
Page 29: Saving Presets
D1 Videomixer Saving Presets It is possible to save up to 20 views containing current parameters and settings. The memory is divided into 4 pages, 5 banks each. 01) Press the SAVE button located in the Preset Bank section (03). The display will show: 02) Select one of the 4 pages. -
Page 30: Creating A Custom Logo
Creating a Custom Logo It is possible to create a custom logo by means of the dedicated software. 01) Turn the D1 Videomixer off. 02) Loosen the mounting screws and remove (pull out) the indicated module: 03) Remove the microSD card from the housing and connect it to your PC. The card should be FAT32 formatted. - Page 31 16) The logo is now saved on the microSD card as LOGO_xxx.bin file, where “xxx” stands for the logo number. 17) Remove the microSD card from the PC, place it in the D1 Videomixer and replace the previously removed module.
- Page 32 03) If all of the above appears to be O.K., plug the unit in again. 04) If you are unable to determine the cause of the problem, do not open the D1 Videomixer, as this may damage the unit and the warranty will become void.
- Page 33 D1 Videomixer Output Does Not Fill the Entire Screen Resolution is incorrect. 01) Select the resolution which is larger than the screen width. Black Spots Appear on the Sides of the Screen Adjust DE deviation. 01) Go to OUTPUT -> OUTPUT SETTING and set DE ADJUST.
- Page 34 D1 Videomixer Dimensions Ordercode: 101281...
- Page 35 D1 Videomixer Ordercode: 101281...
- Page 36 ©2020 DMT...
