Summary of Contents for Water Tech Softmax Pro SMX10
- Page 1 OWNERS MANUAL Whole House Water Softener With Triton Electronic Control Valve Activate your warranty by registering your product at watertech.com or call 469-521-1180.
-
Page 2: Do's And Don'ts
DEALER CONTACT AND PRODUCT INFORMATION Dealer Name: Dealer Phone Number: Installation Date: Model Number: Serial Number: DO’S AND DONT’S DO ALWAYS • check your state and local regulations regarding plumbing and electrical connections and placement of the system before installation. •... -
Page 3: Parts List
PARTS LIST Triton Control Valve Overflow elbow Resin tank Brine tank PRODUCT DESCRIPTION PART NUMBER Resin Tank 10" x 54" 09-03-1054BLK-XE Resin Tank 12" x 52" 09-03-1252BLK-XE Resin Tank 13" x 54" 09-03-1354BLK-XE Brine Tank Assembled 18" x 33" 09-04-1833BKNG-SIL Brine Tank Assembled 18"... -
Page 4: Set Clock
DISPLAYS & PROGRAMMING CLOCK / HOME LEFT / BACK RIGHT / NEXT SET CLOCK Press CLOCK one time. The hours will begin to flash. to adjust the hour. The hours will cycle through AM and PM. Once the hour is set correctly, press one time to set the minutes. -
Page 5: Error Message
DISPLAYS & PROGRAMMING CLOCK / HOME LEFT / BACK RIGHT / NEXT SETTING REGENERATION TIME Enter the Installer Screens by pressing and holding simultaneously for 3-5 seconds. Once the display changes, press until you reach the “Regeneration Time” display. When on the “Regeneration Time” display, use to adjust the hour. -
Page 6: Maintenance
MAINTENANCE This manual is applicable to one of the following model numbers: Pro Series: SMX10, SMX12, SMX13 With minimal care, your system is designed to serve you for many years. While constant attention to your system is not necessary, the following suggestions will ensure your system’s performance and your convenience and satisfaction. -
Page 7: Plumbing Connection
PLUMBING CONNECTION Typical plumbing installation Raw water to outside faucets water in Check local codes for minimum run between unit and water heater Conditioned water in Triton Bypass Valve Cold IMPORTANT: Brass or Plastic yoke assembly (not shown) is required to connect piping to the bypass valve and is available in either NPT or solvent. -
Page 8: Drain Line Connection
DRAIN LINE CONNECTION Brine line elbow Locking clip Locking clip Air gap CAUTION: Never connect drain line directly into drain, sewer line or trap. Always allow an air gap of at least 25mm (1 inch) or 2 pipe diameters between the drain line and waste water to prevent the possibility of sewage being back siphoned. -
Page 9: Starting Up The System
STARTING UP THE SYSTEM Flushing, Conditioning and Sanitizing Did you connect the drain line securely to the valve? Did you connect the brine line securely to the valve? Step 1. Make sure the system is in the “Bypass” position before turning the main water back on. - Page 10 STARTING UP THE SYSTEM Check all connections to make sure the system has no leaks. Once you’ve verified all stages of regeneration are working appropriately, and have verified there are no leaks, fill the brine tank with sodium chloride or potassium chloride softening pellets. Step 3.
- Page 11 DISPLAYS & PROGRAMMING CLOCK / HOME LEFT / BACK RIGHT / NEXT SET CLOCK Press CLOCK one time. The hours will begin to flash. to adjust the hour. The hours will cycle through AM and PM. Once the hour is set correctly, press one time to set the minutes.
- Page 12 DISPLAYS & PROGRAMMING CLOCK / HOME LEFT / BACK RIGHT / NEXT SETTING REGENERATION TIME Enter the Installer Screens by pressing and holding simultaneously for 3-5 seconds. Once the display changes, press until you reach the “Regeneration Time” display. When on the “Regeneration Time” display, use to adjust the hour.
-
Page 13: Bypass Valve Operation
BYPASS VALVE OPERATION The bypass valve is typically used to isolate the control valve from the plumbing system’s water pressure in order to perform control valve repairs or maintenance. The 1" full flow bypass valve incorporates four positions including a diagnostic position that allows service personnel to work on a pressurized system while still providing untreated bypass water to the facility or residence. - Page 14 BYPASS VALVE ILLUSTRATIONS FIGURE 1. FIGURE 2. NORMAL OPERATION BYPASS OPERATION Treated Supply Supply Supply water exits water enters water exits water enters FIGURE 3. FIGURE 4. DIAGNOSTIC MODE SHUT OFF MODE POSITION Supply Supply No water Supplywater is shut off water exits water enters exits...
- Page 15 Cosmetic damage that does not affect the process functionality of the equipment is not covered. Water Tech Industries makes every effort to ensure that all illustrations and specifications are correct. However, these do not imply a warranty that the product is merchantable or fit for a particular purpose, or that the product may not vary from the illustrations and specifications.
- Page 16 WTI is contingent on proper execution of the procedures set forth in the WTI Warranty RGA policy. No person or representative is authorized to assume for Water Tech Industries any liability on its behalf, or in its name, except to refer the purchaser to this warranty.
