OWNER'S MANUAL
REIONATOR
®
WHOLE HOUSE WATER CONDITIONER
with Triton Electronic Control Valve
Platinum Series
Classic Series
Fusion Series
WQA Gold Seal certified to NSF/ANSI Standards 42 and 44
for meeting or exceeding industry standards of aesthetic
chlorine reduction and softening efficiency.
ACTIVATE YOUR WARRANTY
BY REGISTERING YOUR PRODUCT AT
www.watertech.com
or call 888-254-8412
Advertisement
Table of Contents
Related Manuals for Water Tech RC32-TM
Summary of Contents for Water Tech RC32-TM
- Page 1 OWNER'S MANUAL REIONATOR ® WHOLE HOUSE WATER CONDITIONER with Triton Electronic Control Valve Platinum Series Classic Series Fusion Series WQA Gold Seal certified to NSF/ANSI Standards 42 and 44 for meeting or exceeding industry standards of aesthetic chlorine reduction and softening efficiency. ACTIVATE YOUR WARRANTY BY REGISTERING YOUR PRODUCT AT www.watertech.com...
-
Page 2: Customer Checklist
DEALER CONTACT AND PRODUCT INFORMATION Dealer Name: Dealer Phone Number: Installation Date: Model Number: Serial Number: CUSTOMER CHECKLIST After installation, installer should make sure of the following: Customer has an Owner's Manual Customer knows how to restart system if power goes out ... -
Page 3: Maintenance
Maintenance This manual is applicable to one of the following model numbers: Classic Series: RC32-TM, RC40-TM, RC48-TM, RC64-TM, RC80-TM Platinum Series: RP32-TM, RP40-TM, RP48-TM, RP64-TM, RP80-TM Fusion Series: RF32-TM, RF40-TM, RF48-TM With minimal care, your system is designed to serve you for many years. While constant attention to your system is not necessary, the following suggestions will insure your system’s performance and your... -
Page 4: Do's And Do Not's
Do’s and Do Not’s • DO ALWAYS check your state and local regulations regarding plumbing and electrical connections and placement of the system before installation. • DO install the REIONATOR system into the existing cold water supply line before the water heater and ®... -
Page 5: Product Description
Parts List - RC/RP Triton Control Valve Overflow Elbow Resin Tank Brine Tank PRODUCT DESCRIPTION PART NUMBER Resin Tank 9" x 48" 09-03-0948BLK Resin Tank 10" x 47" 09-03-1047BLK Resin Tank 10" x 54" 09-03-1054BLK Resin Tank 12" x 52" 09-03-1252BLK Resin Tank 13"... - Page 6 Parts List - RF PRODUCT DESCRIPTION PART NUMBER Resin Tank 10" x 35" 09-03-1035NB Resin Tank 12" x 35" 09-03-1235NB Fusion Cabinet Top 09-05-010 Fusion Cabinet Base 09-05-011 Brine Overflow Elbow 07-05-004 Brine Well Assembly 09-04-244 Triton Control Valve 13-V1CCDM...
-
Page 7: Plumbing Connection
Plumbing Connection Typical Plumbing Installation Check local codes for minimum STOP run between Reionator unit and water heater IMPORTANT: Brass or plastic yoke assembly (not shown) is required to connect piping to the bypass valve and is available in either NPT or solvent. -
Page 8: Drain Line Connection
Drain Line Connection Drain Elbow PolyTube Insert Locking Clip Drain Elbow Nut Drain Line CAUTION: Never connect drain line directly into drain, sewer line or trap. Always allow an air gap of at least 25mm (1 inch) or 2 pipe diameters between the drain line and waste water to prevent the possibility of sewage being back siphoned. -
Page 9: Starting Up The System
Starting Up the System Flushing, Conditioning and Sanitizing Did you connect the drain line securely to the valve? STOP Did you connect the brine line securely to the valve? Step 1. Make sure the system is in the “Bypass” position before turning the main water back on. See page 12. - Page 10 Starting Up the System Step 3: continued: Once the valve has completed the “Brine Fill” cycle it will automatically return to service. In step 5 you will set the valve to “Regen Today” so that it will regen tonight at the specified time. If there is any residual chlorine, it should be removed tonight.
-
Page 11: Regeneration Mode
Displays & Programming Instructions GENERAL OPERATION: When the REIONATOR ® is in operation, one of two displays will be shown. The user can alternate between the two displays as desired by pressing the ‘NEXT’ button. System operation is not affected by pressing the ‘NEXT’ button. One of the displays is always the current time of day. The second display is one of the following: either a) days remaining or b) gallons remaining. -
Page 12: Error Message
Set Time of Day / Power Loss The user can also set the time of day. Time of day should only need to be set after extended power outages or when daylight saving time begins or ends. If a power outage lasting longer than two hours occurs, the time of day will flash on and off which indicates the time of day should be reset. -
Page 13: Bypass Valve Operation
Bypass Valve Operation The bypass valve is typically used to isolate the control valve from the plumbing system’s water pressure in order to perform control valve repairs or maintenance. The 1" full flow bypass valve incorporates four positions including a diagnostic position that allows service personnel to work on a pressurized system while still providing untreated bypass water to the facility or residence. - Page 14 Bypass Valve Illustrations FIGURE 1 FIGURE 2 NORMAL OPERATION POSITION BYPASS OPERATION POSITION FIGURE 3 FIGURE 4 DIAGNOSTIC MODE POSITION SHUT OFF MODE POSITION...
-
Page 15: Specifications
Stated Salt Setting @ Stated Salt Setting Hardness Model† (Grains Per Pound) (Grains Per Gallon) (Grains Per Gallon) RC32-TM 3998 @ 3.3 lbs. 13,085 @ 3.3 lbs. RC40-TM 3998 @ 4 lbs. 15,993 @ 4 lbs. RC48-TM 3998 @ 4.7 lbs. - Page 16 ® As with any appliance, proper operation and maintenance is required to ensure trouble-free operation. Please consult your local authorized WaterTech dealer for service. AESTHETIC CHLORINE MODEL* REDUCTION (GALLONS) RC32-TM RC40-TM 1000 RC48-TM 1180 RC64-TM 1580 RC80-TM...
- Page 17 Notes...
- Page 18 Notes...
- Page 19 Notes...
-
Page 20: Limited Lifetime Warranty
Applicable to REIONATOR Models: ® Classic Series RC32-TM, RC40-TM, RC48-TM, RC64-TM, RC80-TM Platinum Series RP32-TM, RP40-TM, RP48-TM, RP64-TM, RP80-TM Fusion Series RF32-TM, RF40-TM, RF48-TM WaterTech Industries (WTI) hereby warrants said equipment, only to the original purchaser at the original installation location.
