Summary of Contents for Siemens KG56N Series
- Page 1 Fridge-freezer KG56N... Information for Use Register your product on My Siemens and discover exclusive services and offers. siemens-home.bsh-group.com/welcome The future moving in. Siemens Home Appliances...
-
Page 2: Table Of Contents
Futher information and explanations are available online: Table of contents 1 Safety .......... 4 6.6 Ice cube maker ...... 16 1.1 General information.... 4 6.7 Accessories ...... 17 1.2 Intended use....... 4 7 Basic operation ...... 17 1.3 Restriction on user group... 4 7.1 Switching on the appliance .. 17 1.4 Safe transport ...... 4 7.2 Operating tips...... 17... - Page 3 12 Defrosting ......... 23 12.1 Defrosting in the freezer compartment ...... 23 13 Cleaning and servicing .... 23 13.1 Preparing the appliance for cleaning ........ 23 13.2 Cleaning the appliance .. 23 13.3 Removing the fittings.... 24 14 Troubleshooting....... 26 14.1 Power failure...... 30 14.2 Conducting an appliance self-test ........ 30 15 Storage and disposal....
-
Page 4: Safety
en Safety 1 Safety Observe the following safety instructions. 1.1 General information ¡ Read this instruction manual carefully. ¡ Keep the instruction manual and the product information safe for future reference or for the next owner. ¡ Do not connect the appliance if it has been damaged in transit. 1.2 Intended use Only use this appliance: ¡... -
Page 5: Safe Installation
Safety en 1.5 Safe installation WARNING ‒ Risk of electric shock! Incorrect installation is dangerous. ▶ Connect and operate the appliance only in accordance with the specifications on the rating plate. ▶ Connect the appliance to a power supply with alternating cur- rent only via a properly installed socket with earthing. ▶... -
Page 6: Safe Use
en Safety Portable multiple socket strips or portable power supply units may overheat and cause a fire. ▶ Do not place portable multiple socket strips or power supply units on the back of the appliance. 1.6 Safe use WARNING ‒ Risk of electric shock! An ingress of moisture can cause an electric shock. - Page 7 Safety en WARNING ‒ Risk of fire! Electrical devices within the appliance may cause a fire, e.g. heat- ers or electric ice makers. ▶ Do not operate electrical devices within the appliance. WARNING ‒ Risk of injury! Containers that contain carbonated drinks may burst. ▶ Do not store containers that contain carbonated drinks in the freezer compartment.
-
Page 8: Damaged Appliance
en Safety ▶ Store raw meat and fish in suitable containers in the refrigerator so that they do not touch or drip on other food. ▶ If the fridge/freezer is empty for an extended period of time, switch off the appliance, defrost it, clean it and leave the door open to prevent the formation of mould. - Page 9 Safety en ▶ Unplug the appliance from the mains or switch off the circuit breaker in the fuse box. ▶ Call after-sales service. → Page 32...
-
Page 10: Preventing Material Damage
en Preventing material damage 3.2 Saving energy 2 Preventing material If you follow these instructions, your damage appliance will use less power. Selecting the installation location ATTENTION! If not rolling freely, the appliance's ¡ Keep the appliance out of direct castors may damage the floor when sunlight. -
Page 11: Installation And Connection
Installation and connection en The subfloor must be sufficiently 4 Installation and con- stable to bear the weight of the appli- ance. nection Permitted room temperature 4.1 Scope of delivery The permitted room temperature de- pends on the appliance's climate After unpacking all parts, check for class. -
Page 12: Connecting The Appliance To The Electricity Supply
en Installation and connection 4.5 Connecting the appliance to the electricity supply Insert the mains plug of the appli- ance's power cable in a socket nearby. The connection data of the appli- ance can be found on the rating plate. → "Appliance", Fig. Page 14 Check the mains plug is inserted properly. -
Page 13: Familiarising Yourself With Your Appliance
Familiarising yourself with your appliance en 5 Familiarising yourself with your appliance 5.1 Appliance You can find an overview of the parts of your appliance here. Refrigerator compartment Lighting → Page 21 Interior ventilation opening Freezer compartment → Page 21 Bottle shelf → Page 15... -
Page 14: Control Panel
en Familiarising yourself with your appliance 5.2 Control panel Temperature controller (stor- age container) → Page 18 You can use the control panel to con- Rating plate → Page 32 figure all functions of your appliance and to obtain information about the Storage container operating status. → Page 15 Fruit and vegetable container with humidity control... -
Page 15: Features
Features en 6.3 Storage container Displays the set temperature for the refrigerator compart- The temperatures in the storage con- ment in °C. tainer are lower than in the refriger- (Refrigerator compart- ator compartment. Temperatures be- ment) switches Super cooling low 0 °C may occur occasionally. on or off. -
Page 16: Door Rack
en Features The air humidity in the fruit and Remove the ice cube tray , fill ¾ vegetable container can be set full with drinking water and re-in- according to the type and amount of sert . food to be stored by moving the humidity controller: ¡... -
Page 17: Accessories
operation en Pull out the ice storage container operation 7 Basic operation and remove the ice cubes. operation 7.1 Switching on the appli- ance Electrically connect the appliance. → Page 12 Note: If the appliance has been previously switched off using the control panel, press and hold for three seconds. -
Page 18: Setting The Temperature
en Additional functions 7.4 Setting the temperature 8 Additional functions Setting the refrigerator compartment temperature 8.1 Super cooling Press the required temperature. ▶ With Super cooling, the refrigerator To reach the set temperature, slide compartment cools as cold as pos- the temperature controller for the sible. -
Page 19: Manual Super Freezing
Additional functions en After operation, the appliance Switching off manual Super switches from automatic Super freez- freezing ing to normal operation. Press (Freezer compartment). ▶ Activating automatic Super 8.4 Holiday mode freezing Press and hold (Freezer com- If you are going to be away for a long ▶... -
Page 20: Freshness Mode
en Alarm Switching on energy-saving mode 9.2 Temperature alarm Press ▶ If the freezer compartment becomes lights up. too warm, the temperature alarm is switched on. Switching off energy-saving mode A warning tone sounds and the set Press temperature (freezer compartment) ▶ flash. -
Page 21: Refrigerator Compartment
Refrigerator compartment en Tip: Store highly perishable food 10 Refrigerator compart- such as fish, sausages and meat in the coldest zone. ment Warmest zone You can keep meat, sausage, fish, The warmest zone is at the very top dairy products, eggs, prepared meals of the door. -
Page 22: Tips For Freezing Fresh Food
en Freezer compartment ¡ Place the food over the whole area 11.4 Shelf life of frozen food of the frozen food containers. at −18 °C ¡ To quickly and gently freeze larger quantities of fresh food, place this Food Storage time in the bottom frozen food con- Fish, sausages, pre- up to tainer. -
Page 23: Defrosting
Defrosting en 13.2 Cleaning the appliance 12 Defrosting WARNING Risk of electric shock! 12.1 Defrosting in the freezer An ingress of moisture can cause an compartment electric shock. Do not use steam- or high-pres- The fully automatic NoFrost system ▶ sure cleaners to clean the appli- ensures that the freezer compartment ance. -
Page 24: Removing The Fittings
en Cleaning and servicing Lift the storage container at the 13.3 Removing the fittings front and remove it . If you want to clean the fittings thor- oughly, remove these from your ap- pliance. Removing the shelf Pull out and remove the shelf. ▶... - Page 25 Cleaning and servicing en Lift the frozen food container at the Loosen the clip on the left side of front and remove it . the container by pressing it to- gether and remove the ice cube maker . Removing the front of the container You can remove the front of the fruit and vegetable container to facilitate...
-
Page 26: Troubleshooting
en Troubleshooting 14 Troubleshooting You can rectify minor faults on your appliance yourself. Read the troubleshoot- ing information before contacting after-sales service. This will avoid unneces- sary costs. WARNING Risk of electric shock! Incorrect repairs are dangerous. Repairs to the appliance should only be carried out by trained specialist ▶... - Page 27 Troubleshooting en Fault Cause and troubleshooting A warning tone The freezer compartment door is open. sounds and the tem- Close the freezer compartment door. ▶ perature display (freezer compartment) flash. The door alarm is switched on. A warning tone Different causes are possible. sounds and the set Press ▶...
- Page 28 en Troubleshooting Fault Cause and troubleshooting The set temperature is The freezer compartment door was open for a long not reached. time. The evaporator (refrigeration unit) in the noFrost system is heavily iced up. Fully automatic de- Requirement: Store the frozen food well insulated in a frosting no longer cool place.
- Page 29 Troubleshooting en Fault Cause and troubleshooting The appliance hums, Not a fault. A motor is running, e.g. refrigerating unit, bubbles, buzzes, fan. Refrigerant flows through the pipes. The motor, gargles, clicks or switches or solenoid valves are switching on or off. crackles.
-
Page 30: Power Failure
en Storage and disposal a If, at the end of the appliance self- 14.1 Power failure test, 5 audible signals sound and During a power failure, the temperat- the temperature display LEDs light ure in the appliance rises; this re- up with a different brightness, in- duces the storage time and the qual- form customer service. - Page 31 Act 1986. the soil and the ground water. ¡ Please visit our web- ¡ Do not keep any re- site https:// placed spare part(s) www.siemens- from the product in home.bsh-group.in/na- exposed area. tional-e-waste-recyc- ling-program to find...
-
Page 32: Customer Service
Customer Service directory or on our website. Helpline no.: 1800-209-1850 (Monday to Saturday – 8 am to 8 pm) Email ID: service.in@siemens- home.BSH-Group.com 16.1 Product number (E-Nr.) and production number (FD) You can find the product number (E- Nr.) and the production number (FD) - Page 36 BSH Hausgeräte GmbH Carl-Wery-Straße 34 81739 München, GERMANY siemens-home.bsh-group.com Manufactured by BSH Hausgeräte GmbH under the trademark licence of Siemens AG *9001731123* 9001731123 (020817)
