PCB Piezotronics ICP RHM240A01 Installation And Operating Manual page 12

PCB Piezotronics Inc. claims proprietary rights in
the information disclosed hereon. Neither it nor any
reproduction thereof will be disclosed to others
without the written consent of PCB Piezotronics Inc.
ELECTRICAL CONNECTOR
10-32 UNF - 2A
B
MOUNTING HOLE PREPARATION:
n x
.199 [5.05] .45 [11.4]
x
M6x1 - 6H .35 [8.9]
4 APPLY LUBRICANT (080A82 OR EQUIVALENT) TO THE
THREADS AND THE HEAD OF THE MOUNTING BOLT
3 TORQUE SCREW TO 86 IN-LBS [10 Nm] MINIMUM
A
2 MOUNTING SURFACE MUST BE FLAT TO WITHIN
.001 [.03] WITH AT LEAST A SURFACE FINISH OF 125 [3.2]
1 DRILL PERPENDICULAR TO MOUNTING SURFACE WITHIN 1°
UNLESS OTHERWISE SPECIFIED TOLERANCES ARE:
DIMENSIONS IN INCHES
DECIMALS XX ±.01
XXX ±.005
ANGLES ` 2 DEGREES
CABLE TOLERANCES IN ENGLISH
1"≤ LENGTH < 1' = +1"/ - 0
1'≤ LENGTH < 5' = +2"/ - 0
5'≤ LENGTH < 100' = +6"/ - 0
100'≤ LENGTH = +1'/ - 0
FILLETS AND RADII
.003 - .005
2
.24 [6.0]
.18 [4.6]
1
DIMENSIONS IN MILLIMETERS
NJF
[ IN BRACKETS ]
DECIMALS X ± 0.3
XX ± 0.13
TITLE
ANGLES ` 2 DEGREES
CABLE TOLERANCES IN METRIC
2.54cm ≤ LENGTH < 30.5cm = +2.54cm/ - 0
30.5cm ≤ LENGTH < 1.5m = +5.1cm/ - 0
1.5m ≤ LENGTH < 30.5m = +15.2cm/ - 0
30.5m ≤ LENGTH = +30.5cm/ - 0
FILLETS AND RADII
0.07 - 0.13
2
REV
F
1.58 [40.0]
1.15 [29.2]
DRAWN CHECKED
07/27/23 07/27/23
JDM
INSTALLATION DRAWING
MODEL 240XXX SERIES
STRAIN SENSOR
1
REVISIONS
DESCRIPTION
ADDED NOTE #4
.67 [17.0]
MODEL M081A100:
M6x1 - 6g X .87 [22.0] LONG
FLAT HEAD HEX SCREW
2X .60 [15.2]
2
ENGINEER
07/27/23
RF
3425 WALDEN AVE. DEPEW, NY 14043
(716) 684-0001 E-MAIL: sales@pcb.com
DWG. NO.
CODE
IDENT. NO.
52681
SCALE: 1.5X
1
DIN
54044
B
3
A
22493
SHEET 1 OF 1
