PCB Piezotronics ICP RHM240A01 Installation And Operating Manual page 11

Model Number
RHM 240A01
Performance
Sensitivity(± 20 %)
Measurement Range
Frequency Range(- 5 %)
Broadband Resolution(1 to 10,000 Hz)
Non-Linearity
Environmental
Temperature Range(Operating)
Electrical
Excitation Voltage
Constant Current Excitation
Output Bias Voltage
Discharge Time Constant
Physical
Sensing Element
Housing Material
Electrical Connector 10-32 Coaxial Jack
Electrical Connection Position
Sealing
Mounting Torque
Size (Width x Length x Height) 0.67 in x 1.81 in x 0.6 in
Weight
[5]
All specifications are at room temperature unless otherwise specified.
In the interest of constant product improvement, we reserve the right to change specifications without notice.
®
ICP is a registered trademark of PCB Piezotronics, Inc.
UNIAXIAL STRAIN SENSOR
EN GLISH SI
100 mV/µε 100 mV/µε
50 pk µε 50 pk µε
0.015 Hz 0.015 Hz
0.0001 µε 0.0001 µε
≤ 2 % ≤ 2 %
-65 to +250 °F -54 to +121 °C
20 to 30 VDC 20 to 30 VDC
2 to 20 mA 2 to 20 mA
8 to 14 VDC 8 to 14 VDC
≥ 35 sec ≥ 35 sec
Quartz Quartz
Stainless Steel Stainless Steel
10-32 Coaxial Jack
Side Side
Epoxy Epoxy
7.38 ft-lb 10 Nm
17 mm x 46 mm x 15.2 mm
1.6 oz 45 gm
Optional versions have identical specifications and accessories as listed for the standard model except
where noted below. More than one option may be used.
[1]
[2] - Water Resistant Cable
W
[3]
[4]
[3]
[3]
N OTES:
[1]Based on 100 mV/µε sensitivity.
[2]Calculated from discharge time constant.
[3]Typical.
[4]Zero-based, least-squares, straight line method.
[5]See PCB Declaration of Conformance PS023 for details.
SUPPLIED ACCESSORIES:
Model 080A82 Assembly Lubricant
Model M081A100 M6 x 1.00 flathead screw (1)
Entered: ND Engineer: RPF
Date: 07/31/2023 Date: 07/31/2023 Date: 07/31/2023 Date: 07/31/2023 36895
3425 Walden Avenue, Depew, NY 14043
Revision: C
ECN #: 54044
OPTION AL VERSION S
Sales: BS Approved: RPF Spec Number:
Phone: 716-684-0001
Fax: 716-684-0987
E-M ail: info@ pcb.com
