Summary of Contents for ATEMPOWER AP200MS-B
- Page 1 200W Solar Blanket AP200MS-B USER MANUAL...
-
Page 2: Warnings And Safety Information
ABOUT US ATEM POWER, born in June 2017, as a synonym for exciting outdoor experience, is an Australian company with dedication and passion for the R&D of high quality products in the field of renewable energy products, batteries and related accessories. Since the company was founded, we have committed to innovation that aims to make your life infinitely more convenient. -
Page 3: Package List
PACKAGE LIST MPPT Controller DIMENSIONS 380mm 60mm 1900mm... - Page 4 CONNECTING YOUR SOLAR PANEL • Connect the Alligator Clips to the battery. • Connect the controller to the battery with Anderson plugs. Use the extension cable if needed. • Connect the solar blanket to the controller with Anderson plugs. Note: When uninstalling, you are required to repeat the steps from last to first. Controller Extension Cable Alligator Clips...
-
Page 5: Controller Specifications
SOLAR BLANKET SPECIFICATIONS 18.2V 10.99A 22.4V 11.75A 480*380*60 mm 1900*730*5 mm CONTROLLER SPECIFICATIONS Model CY1220MT-AP Rated Charge Current Rated Discharge Current Rated Voltage 12V/24V auto work MPPT Effciency Max:99% ≥1 5 rated current Over Load, Short Circuit Protection ＜10mA No Load Current Over Voltage Protection 16V;... -
Page 6: Troubleshooting
INDICATOR STATUS MEANING Solar panel voltage is higher than the light control voltage SOLAR Solar panel voltage is less than the light control voltage Number of indicators steady on indicates battery Any status power BATTERY Battery is nearly or already empty. The left indicator is flashing LOAD Battery voltage is abnormal. -
Page 7: Warranty
WARRANTY MONTH WARRANTY PERIOD: Full 12 month warranty from date of purchase against all manufacturing defects. WHAT DOES THE WARRANTY COVER? Under normal usage conditions, this warranty covers: Any defect in design or manufacture which results in its failure to perform correctly as described. Damage or loss incurred in transit. - Page 8 DC-DC CHARGER AP20DC USER MANUAL...
- Page 9 ABOUT US ATEM POWER, born in June 2017, as a synonym for exciting outdoor experience, is an Australian company with dedication and passion for the R&D of high quality products in the field of renewable energy products, batteries and related accessories. Since the company was founded, we have committed to innovation that aims to make your life infinitely more convenient.
-
Page 10: Key Features
KEY FEATURES This DC-DC charger by ATEM POWER, which is ideal for 4WDs, caravans, RVs, trucks, campers, trailers, campervans, commercial vehicles and boats, offers an effective way to charge your auxiliary batteries from the alternator or solar panel (up to 20A) to charge AGM, Gel, calcium, LiFePO4 batteries. It also has a built-in MPPT regulator to maximize energy absorption, thus reducing the load on your engine. -
Page 11: Installation Instructions
INSTALLATION INSTRUCTIONS Please check whether the specification of your cable is compatible with this DC-DC charger. This charger can be installed both horizontally and vertically. Please make sure that the charger is installed as close as possible to the battery you are going to charge, and you also need to make sure that the areas is not susceptible to moisture, water, dust or high temperatures. -
Page 12: How To Use
HOW TO USE 1. DC Battery Start your vehicle and let it idle. And the charger will recognize that there is a charge being applied to the main starting battery. The charger will charge the auxiliary battery when the main starting battery has reached 13V. The main battery will start charging the auxiliary battery when its voltage is or above 11.5V (ACC line connected). -
Page 13: Battery Wiring
BATTERY WIRING This diagram is for a reference only. Local rules and regulations should be followed when installing this unit. 12V Start / Vehicle Battery Fuse / Breaker (Optional) 12V - 40A Temp Sensor Cable (Included) Fuse / Breaker 30A (Optional) MPPT Solar Panel Input 300 W 30A/Isc / 25V/OC... -
Page 14: Technical Specifications
TROUBLESHOOTING Display shows that the charger is not charging: check where the battery is connected; check the terminals; check whether the battery is 12V. Battery is not charging: check whether all connections are connected correctly; check the status of the battery; check the status of your vehicle or solar panel. Battery cannot be fully charged or power cannot be maintained: please check whether your battery has been used for over 3 years;... -
Page 15: Charging Voltage
CHARGING VOLTAGE AGM/GEL LEAD ACID CALCIUM LiFePO4 BOOST 14.3 V 14.0 V 15.0 V 14.0 V CHARGING 14.7V 14.4 V 14.4 V 15.4 V MAINTENANCE 13.5 V 13.5 V 13.5 V CHARGING ALGORITHM Peak Amps Soft Start Minimal Ampere Time Charging algorithm will change according to battery type. - Page 16 WARRANTY MONTH WARRANTY PERIOD: Full 12 months warranty from date of purchase against all manufacturing defects. This DC-DC charger by ATEM POWER comes with guarantees that cannot be excluded under the Australian Consumer Law. WHAT DOES THE WARRANTY COVER? Under normal usage conditions, this warranty covers: Any defect in design or manufacture which results in its failure to perform correctly as described.
