- Page 1 10W/60W/130W/200W/250W Solar Panel USER MANUAL...
-
Page 3: Warnings And Safety Information
ABOUT US ATEM POWER, born in June, 2017, as a synonym for exciting outdoor experience, is an Australian company with dedication and passion for the R&D of high quality products in the field of renewable energy products, batteries and related accessories. Since the company was founded, we have committed to innovation that aims to makes your life infinitely more convenient. -
Page 4: Included In The Kit
INCLUDED IN THE KIT 10W/60W/130W/200W/250W(from left to right) Pulse Width Modulator Controler Note: The PWM controller is not included in 10W and 60W solar panels. INSTRUCTIONS Solar panel will perform at its peak when it faces directly towards the sun. -
Page 5: Menu & Function
SPECIFICATION OF THE CONTROLLER 5V / 2A ; 5V / 2A 133*70*34 mm LCD DISPLAY OF THE CONTROLLER charge on: Stable output Flicking: Floating Mode MENU: you can browse different settings, or long press to enter/exit certain settings. UP:press to increase value. DOWN:press to decrease value. - Page 6 It is about the status of voltage and PWM controller. Controller will enter float charging mode when voltage reaches13.7V LOAD RECHARGE The panel is ready to power the load again when voltage reaches12.6V. CUT-OFF VOLTAGE The controller will sever the connection to the load when the voltage of the battery reaches 10.7V.
-
Page 7: Troubleshooting
TROUBLESHOOTING Symptoms Possible Cause Solution Solar panel doesn't work Solar panel opened or Reconnect despite sufficient sunlight. reversed Wrong setting Set again Load icon doesn't on Low Battery Recharge Load icon flashing slowly Reduce load capacity Overload Load icon flashing fast Short circuit protection Remove short circuit The screen of the... -
Page 8: Warranty
WARRANTY MONTH WARRANTY PERIOD: Full 12 month warranty from date of purchase against all manufacturing defects. WHAT DOES THE WARRANTY COVER? Under normal usage conditions, this warranty covers: 1. Any defect in design or manufacture which results in its failure to perform correctly as described.
