- Page 1 BoomBox for Bowens Mount BB-36DB BB-ST-1024 BB-48DB BB-ST-1255 INSTRUCTIONS...
- Page 2 Setting Up the BoomBox For Monolights and studio strobes with Bowens mounts, align the mounting tabs with the Bowens mount and insert the BoomBox into the Bowens mount. Turn the BoomBox clockwise until it locks. Open the BoomBox, and push the center ring over the shaft until it’s all the way in, just like an umbrella.
- Page 3 Deflector Extension (BB-48DB and BB-ST-1255 Only) The deflector extension moves the deflector further away from the BoomBox’s interior for a wider and more even light spread. To install the deflector on the extension, follow these steps: Open the BoomBox, and screw the threaded end of the extension into the shaft.
- Page 4 Removing the BoomBox To remove the BoomBox from a Bowens mount: Press the light fixture’s Bowens release. Turn the BoomBox counterclockwise and remove it from the light. If necessary, remove the diffuser, deflector, and extension. Then close the BoomBox by carefully pulling on the center ring.
- Page 5 Changing the Adapter Ring Adapter Rings for Broncolor, Elinchrom, and Profoto are available separately. Three or four Philips screws and washers secure the adapter ring to the BoomBox, depending on your model. Pull back the fabric, and use a Phillips screwdriver to remove the screws and washers.
- Page 6 SPECIFICATIONS BB-36DB BB-48DB Size 36 in. (91.4 cm) 48 in. (121.9 cm) Octagonal Octagonal Shape Lights with Bowens Lights with Bowens Compatibility mount mount Removable Front Diffuser Accepts Grid Requires Speed Ring No, provided No, provided 36 in. (91.4 cm) 48 in.
- Page 7 Adapter Ring for Broncolor • BBAR-BRL Adapter Ring for Elinchrom • BBAR-EL Adapter Ring for Profoto • BBAR-PRO Angler Grid for the BB-36DB BoomBox • BB-G36 Angler Grid for the BB-48DB BoomBox • BB-G48 Angler Grid for the BB-ST-1024 BoomBox • BB-G1024 Angler Grid for the BB-ST-1255 BoomBox •...
- Page 8 One-Year Limited Warranty This Angler product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later.
