- Page 1 led port-a-cube CT-LLED CT-SLED INSTRUCTIONS...
- Page 2 Introduction Congratulations on purchasing the Angler LED Port-a-Cube. The Angler LED Port-a-Cube is a foldable and portable lighting solution for product photography. It features bright LEDs adjusted for 5400K color temperature, and are built into the Port-a-Cube so there’s no extra assembly.
- Page 3 Precautions Please read all instructions carefully before assembling and operating this product. Use this light with only the rated voltage on the power supply, as any misuse could risk damage or malfunction. Avoid using this light in any high-moisture environments, as this could also cause damage or malfunction.
- Page 4 Silver reflective lining Background pocket LED strip Touch-fastener strips Handle Top photo Front photo Mesh pocket window window Closing panel...
- Page 5 Backgrounds (gray, green, white, black) Power adapter Diffuser Power cable...
- Page 6 Assembling the LED Port-a-Cube Fold up panels A, B, and C. Make sure the touch-fastener strips are fully connected. (Optional) Insert the blank end of the background into the background pocket on panel D, and match the touch-fastener pads with the touch-fastener strips on panel F.
- Page 7 5. (Optional) To attach the diffuser, pull the top open, and connect the diffuser to the touch-fastener strips on panels A and C so the diffuser covers the LED strip when assembled. 6. Plug the LED Port-a-Cube into an AC power source.
- Page 8 Packing the LED Port-a-Cube Unplug the power adapter from the power outlet and the LED strip’s power cable. Disassemble the LED Port-a- Cube so each panel is lying flat, and insert the backgrounds into the background pocket. 3. Fold panel B onto panel F. Make sure the LED power cable is not sticking out.
- Page 9 5. Fold the Port-a-Cube together. 6. Fold the flap over matching the touch fastener strips. You can store the power adapter, cables, and diffuser in the outer mesh pocket.
-
Page 10: Specifications
Specifications CT-SLED 17" LED count 5400 K Color temperature 50 W Power consumption 85–260 V, 50/60 Hz Input power 25–40 V @ 1500 mA Output (voltages vary 30–55 V @ 900 mA depending on the input) 28–45 V @ 1200 mA 17"... -
Page 11: One-Year Limited Warranty
One-Year Limited Warranty This Angler product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. - Page 12 anglerlights.com...
