- Page 1 BoomBox for Bowens Mount BB-26DB-V2/BB-36DB-V2/BB-48DB-V2 BB-ST-1024-V2/BB-ST-1255-V2 INSTRUCTIONS...
- Page 2 Setting Up the BoomBox For Monolights and studio strobes with Bowens mounts, align the mounting tabs with the Bowens mount and insert the BoomBox into the Bowens mount. Turn the BoomBox clockwise until it locks. Open the BoomBox, and push the center ring over the shaft until it’s all the way in, just like an umbrella.
- Page 3 Attaching the Diffusers The inner and outer diffusers add two levels of diffusion that soften and spread the light for an even and flattering effect. The diffusers can be used with or without the deflector plate. Attach the inner diffuser by attaching the diffuser's touch-connect strips to the touch connect tabs inside the BoomBox.
- Page 4 Changing the Adapter Ring Adapter Rings for Broncolor, Elinchrom, and Profoto are available separately. Make sure to use V2 (144 mm) adapter rings. Unfasten the zipper and pull back the fabric around the BoomBox adapter ring. Use a Philips screwdriver to remove the screws and washers, then remove the thumbscrew and washer.
-
Page 5: Specifications
SPECIFICATIONS BB-26DB-V2 BB-36DB-V2 BB-48DB-V2 Size 26 in. (66 cm) 36 in. (91.4 cm) 48 in. (121.9 cm) Octagonal Octagonal Octagonal Shape Lights with Lights with Lights with Bowens Bowens Compatibility Bowens mount mount mount Removable Front Diffuser Accepts Grid Requires Speed... - Page 6 Recommended Accessories Adapter Rings Model # Mount type BBAR-BRL-144 Broncolor Elinchrom BBAR-EL-144 BBAR-PRO-144 Profoto BBAR-BOW-144 Bowens Grids Model # Compatible Boombox BB-26DB-V2 BB-G26 BB-36DB-V2 BB-G36 BB-G48 BB-48DB-V2 BB-G-1024-V2 BB-ST-1024-V2 BB-G-1255-V2 BB-ST-1255-V2...
-
Page 7: One-Year Limited Warranty
One-Year Limited Warranty This Angler product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. - Page 8 anglerlights.com...
