Page 1: Quick Start Guide
P-660H-Tx v2 ADSL2+ 4-port Gateway Quick Start Guide Version 3.40 2/2007 Edition 1... - Page 2 CD. 1 On the included CD, click Multimedia Auto Provisioner > Installation Tutorial. 2 At the end of the tutorial, click Configuration Genie to set up your P-660H-Tx v2 to connect to the Internet. P-660H-Tx v2 Quick Start Guide...
-
Page 3: Hardware Connections
1 Hardware Connections 1 DSL: Use the gray telephone wire to connect your P-660H-Tx v2’s DSL port to a telephone jack (or to a splitter, if one is already installed). 2 ETHERNET: Use the yellow Ethernet cable to connect a computer to an ETHERNET port for initial configuration and/or Internet access. - Page 4 • The DSL light is on when the P-660H-Tx v2 has a DSL connection. • The INTERNET light is on when you are able to access the Internet and blinks when the P-660H-Tx v2 is send- ing or receiving data.
-
Page 5: Internet Connection Setup Wizard
5 If you do not see the connection test screen, or if the connection test is not successful, check your connections and restart the P-660H-Tx v2. If you still cannot access the Internet, follow the steps in the following section. You should have information provided by your Internet Service Provider. - Page 6 4 Select Go to Wizard setup. Then, click Apply. 5 Click INTERNET SETUP. Wait while your P-660H-Tx v2 tries to detect your DSL connection. 6 Follow the directions in the wizard. Do not change default settings if your ISP did not provide information.
- Page 7 P-660H-Tx v2 Quick Start Guide 7 If the connection test is not successful, you may see either a screen similar to one of the following. Either click Restart the Internet Setup Wizard if available to have the ZyXEL Device detect your connection again...
- Page 8 Use this section to set up your Internet connection manually if you do not see the ISP Parameters for Internet Access screen when you run the wizard (see section 3). 1 Follow step in section 2 Select Go to Advanced setup. Then, click Apply. P-660H-Tx v2 Quick Start Guide in order to log in to the web configurator.
- Page 9 4 The Internet Connection screen appears. Enter the information exactly as provided by your ISP. Click Apply. Note: The fields available in this screen depend on the Mode you select. 5 If you still cannot access the Internet, see Troubleshooting and/or contact your Internet Service Provider (ISP) for assistance. P-660H-Tx v2 Quick Start Guide...
-
Page 10: Troubleshooting
DHCP Setup and ensure that DHCP is set to None. Your ISP gives your computer an IP address directly. If you want to access the P-660H-Tx v2 again, you need to use a static IP address in the same subnet as your P-660H-Tx v2 (the P-660H-Tx v2’s default IP address is 192.168.1.1). - Page 11 2 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page. P-660H-Tx v2 Quick Start Guide ). Run the Internet Setup wizard again. Check whether you can access the...
