PRODUCT SERIES
SÉRIE DE PRODUIT
1
2
FRONT VIEW
(SIDE PANELS REMOVED)
ITEM NUMBER
DESCRIPTION
1
DCZ4 RACK FRAME
2
VENTED DOOR
3
TOP PANEL
4
SIDE PANEL
5
MOUNTING RAILS (PAIR)
DCZ4
4
DATA CONFIG.
1
2
1
2
2
ASSEMBLY INSTRUCTIONS
INSTRUCTIONS DE MONTAGE
5
8
visit our website:
visitez notre site Web:
BUL86906
PAGE 1 OF
3
REAR VIEW
www.hammondmfg.com
B
REV.
4
