- Page 1 BUL86874 INSTRUCTIONS FOR HWM - SERIES REV. PAGE Item Title Quantity Number HWM - DOOR ASSY HWM - CENTRE SECTION visit our website: www .hammondmfg.com HWM - REAR MOUNT ASSY visitez notre site Web:...
-
Page 2: Important Safety Cautions
BUL86874 INSTRUCTIONS FOR HWM - SERIES REV. PAGE IMPORTANT SAFETY CAUTIONS NOTE: Read all instructions before installing and usin g the product. Installation and ass embly m ust be perfo rmed by qualifi ed personnel. Ensure that t he flo or/wall st ructure is able to withst and the weight of the c abinet while fully l oaded. -
Page 3: Wall Mount Instructions
BUL86874 INSTRUCTIONS FOR HWM - SERIES REV. PAGE WALLMOUNT INSTRUCTIONS OPTIONAL: Remove front se ction of wallmount to allow for an easie r install. INSTALL WITH NYLON STRIP AT BOTTOM TOOL BOX LEV EL NI VEAU visit our website: www .hammondmfg.com visitez notre site Web:... - Page 4 BUL86874 INSTRUCTIONS FOR HWM - SERIES REV. PAGE OF 9 LEVEL NIVE AU 16" TEMPLATE / MODÈLE ENGLISH Different wall ma terials require different types of screws. Mount back pan using 3/8" dia lag bolts and standard flat wash ers. FRANÇAIS Les différents matériaux de paroi murale nécessitent différents types de vis.
- Page 5 BUL86874 INSTRUCTIONS FOR HWM - SERIES REV. PAGE OF 9...
- Page 6 BUL86874 INSTRUCTIONS FOR HWM - SERIES REV. PAGE OF 9 REVERSE MIDDLE SECTION INSTRUCTIONS...
- Page 7 BUL86874 INSTRUCTIONS FOR HWM - SERIES REV. PAGE OF 9 GROUNDING AND BONDING INSTRUCTIONS Included within optional grounding kit (GRDKIT01): 4 x 1/4-20 4 x 1/4-20 4 x 1/4" 4 x 10-32 4 x 10-32 4 x #10 Locking Nut Slotted Screw Flat Wash er Locking Nut...
- Page 8 BUL86874 INSTRUCTIONS FOR HWM - SERIES REV. PAGE OF 9 Bonding Connection Main Protective Grounding W hen grounding the rack syste m or enclosu re it is essen tial that the mai n protective ground is connected and se cured first with its own nut before any bonding connections are ma de on top.
- Page 9 BUL86874 INSTRUCTIONS FOR HWM - SERIES REV. PAGE OF 9 KNOCK-OUTS AND CABLE WAYS • Knock-outs are located on the top/bottom and sides of the rear section. • The openings allow for cable entry, mounting of conduits, and fan mounting. 3"...
