Operating instructions
NOTE: Please do not watch videos or use other Apps while the vehicle is in motion.
Doing so, is a safety violation. To watch videos or use Apps, please ensure that the vehicle is in parked mode with handbrake activated.
Please check compatibility Of the device with your mobile phone before purchase.
New phone software versions in the future may or may not be compatible with the device.
In-Warranty replacement will not be applicable for non compatibility Of the mobile phone with the device.
Enjoy it.
Advertisement
Table of Contents
Related Manuals for Blaupunkt 900 Series
Summary of Contents for Blaupunkt 900 Series
- Page 1 CAR MULTIMEDIA SERIES 900 Enjoy it. Operating instructions NOTE: Please do not watch videos or use other Apps while the vehicle is in motion. Doing so, is a safety violation. To watch videos or use Apps, please ensure that the vehicle is in parked mode with handbrake activated. Please check compatibility Of the device with your mobile phone before purchase.
- Page 2 Panel Introduction Head unit features a brilliant capacitive display with a high-end tuner and runs on Android OS Version 9.0. 1 Microphone 2 Reset button Restore to default factory settings of the device. Caution, All personal setting will be lost! 3 POWER/MUTE button Short press: Turn ON device;...
-
Page 3: Table Of Contents
Contents Safety notes Audio playback from USB Android Settings Symbols used Video playback from USB Upgrade & Reset General Warning Image playback from USB System Info Road safety Bluetooth mode Wireless Apple CarPlay and Android Auto Instructions to read this User Manual Starting Bluetooth mode Starting connection Declaration of conformity... -
Page 4: Safety Notes
Safety notes Safety notes General Warning The car sound system was manufactured according to recommended and established safety To avoid any injury or damage to yourself, your car and others, please make sure to do as guidelines in a state of the art facility. Even so, dangers may occur if you do not observe the safety following. -
Page 5: Road Safety
Safety notes Road safety Marks Mark for important preventive measures; please read carefullyto prevent any injury. Observe the following notes about road safety: To avoid any injury or damage to yourself, your car and others, please make sure to do as following. Mark for a special explanation, auxiliary interpretation, imitation and references. -
Page 6: Placing The Device In Operation
Placing the device in operation | Radio Placing the device in operation • Swipe left on the screen to see more source icons. Switching ON/OFF with the POWER button • To switch-ON, press the [ ] button. Note: • To switch-OFF, hold the [ ] button pressed for more than 2 seconds. The figures used in these instructions are intended to facilitate the explanations Volume... -
Page 7: Storing Stations Manually
Radio Starting station seek tuning • Press the [ ] button to adjust the sensitivity of station seek tuning. • Hold the [ ] or [ ] button to start station seek tuning. The radio tunes into If LOC is on, only stations with a strong signal are selected during seek tuning. the next receivable station. -
Page 8: Sound Settings
Sound Settings Sound Settings Volume distribution (Fader/Balance) You can adjust the volume distribution in the vehicle for all sources. Equalizer • Press the [ ] button in EQ menu. You can adjust the equalizer for all sources. The menu for fader and balance is displayed. • Press [ ] on the main menu or [ ] of the current audio source. -
Page 9: Usb Media Playback
(see Connection diagram at the end of these instructions). The movie playback on an external monitor is also possible while driving. Notes: Blaupunkt cannot guarantee that all USB pen drives are compatible with this car 1. Progress Bar audio system. -
Page 10: Video Playback From Usb
Briefly tap on the name of the folder/track. The folder is opened/the track Folder/file list: commences. After starting a title, the playback menu is displayed. Video playback from USB • Select [ Video ] source via the main menu. Note: Folders and videos are selected and started as described under audio playback. Image playback from USB • Select the [ Picture ] via the main menu. -
Page 11: Bluetooth Mode
Bluetooth Bluetooth mode • Ensure that Bluetooth® is activated at the car sound system and at your Bluetooth® device. The Bluetooth® function allows pairing cell phones and media playback devices • Search for new devices/connections on your Bluetooth® device. with the car sound system. • The car sound system appears as "BP900" in the list of Bluetooth® devices. Whena cell phone is paired with the car sound system, you can make phone calls • Establish the connection; you may have to enter the pairing code that was with the built-in hands-free function. -
Page 12: Answer A Call
Bluetooth | Phonelink Answer a call EasyConnection / Phonelink During an incoming call the "Calling" number is displayed. Phonelink function allows the mobile device screen to be displayed on the Car • Press the Green [ ] button to answer a call. Radio screen. • Press the Red [ ] button to reject a call. With EasyConnection/Phonelink you can synchronize the screen from your smart phone to the car multi-media player. - Page 13 Phonelink Tip: • F or your driving safety, please do not use this function during driving. • S ince the mobile phone data cable differs by brand, it is strongly recommended using the original USB data cable to connect so as to ensure connection stability. • D ue to variations in the performance and standard features of mobile phones, the performance of EasyConnection may vary with each individual brand of mobile phone. • B PIN can not guarantee the compatibility of all phones with this device.
-
Page 14: Aux In
AUX IN | Camera Input | SWC | File Manager AUX IN File Manager This device features AUX input for audio / video playback. The AUX-IN RCA inputs • Select [ Files ] in the main menu to enter File Manager menu. are located at the rear of the device. -
Page 15: Settings
Settings Settings General Bluetooth • Select an option to access/setup. • Manage Bluetooth devices. In the settings menu, you can adjust the basic settings for the different functions of the device to your requirements. • In the main menu, press the [ Settings ] button. The settings menu is displayed. • Call up the submenus with the buttons in the lower area of the settings menu. -
Page 16: Key Light
Settings Key Light CANBUS Settings Upgrade & Reset • Set the color of Keys on the front display. • View and manage CANBUS Settings. • Upgrade the software & Reset the default settings. Android Settings System Info • Refer to Steering wheel control in previous chapter. • View and manage the Android Settings. • View System Informations. Factory • Acess Factory configuration. Default Password: 8888... -
Page 17: Wireless Apple Carplay And Android Auto
Apple CarPlay / Android Auto Wireless Apple CarPlay and Android Starting connection • Find [Settings] -> [General] -> [PhoneLink Auto Application], Choose [Apple Carplay/Android This unit features wireless Apple CarPlay and Android Auto]. Auto. • Turn on the Bluetooth and WiFi button on your CarPlay and Android Auto is a smarter, safer way to use phones. -
Page 18: Useful Information
Warranty | Service Useful information Service If your device should need service or to get more information about our local Warranty authorised service center, you can email us at We provide a 2 year manufacturer's warranty for products bought within the Email: Support@blaupunktcar.in India, For devices purchased outside the India, the warranty terms issued by our respective responsible domestic agency is valid. -
Page 19: Connection Diagram
Connection diagram Wiring Diagram RCA output socket Diagram of power cable and RCA Cable FM 87.5~108.0MHz Speaker prohibit grounding! Note:only work within DC10.5V-16V power AM 522KHz~1620KHz AUX-L AUX-R F-CAMERA AMP+12V MIC- MIC+ RCA-L AUX-V RCA-R V-OUT Power Cable Diagram Brown Gray with Black Key1 Pink... -
Page 20: Troubleshooting
Troubleshooting What appears to be trouble is not always serious. Please check the following points before calling a service center. Problem Cause Corrective action General Unit fuse blown. Install new fuse with correct rating. Unit can not power on Car battery fuse blown. Install new fuse with correct rating. - Page 21 Appendix This item incorporates copy protection technology that is protected by U.S. patents and other intellectual property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited. Windows® und Windows Media® are registered trademarks of the Microsoft Corporation in the U.S.A. and/or other countries. This product is protected by certain intellectual property rights of Microsoft.
