Instruction booklet
GB
English
TVF XT 75
TUMBLE DRYER
This symbol reminds you to read this
booklet.
! Keep this instruction booklet on hand in order to refer
to it when necessary. Take it with you when you
move, and should you sell this appliance or pass it
on to another party, make sure that this booklet is
supplied along with the dryer so that the new owner
may be informed about warnings and suggestions on
how the appliance works.
! Read these instructions carefully; the following
pages contain important information on installation
and suggestions on how the appliance works.
To activate your free* 5 Year Parts Guarantee
*Labour charges not included. Terms and consitions apply. Lines open 364 days a year.
Calls are free from a BT landline. Charges from other providers and mobiles may apply.
www.hotpoint.co.uk
Contents
Installation, 2-3
Warnings, 4-5
The Display, 8
Start and programmes, 9-13
Laundry, 14
Troubleshooting, 15
Service, 16
Product data, 17
Call free on 0800 519 2102
Levelling
Electrical connection
GB
1
Advertisement
Table of Contents
Related Manuals for Hotpoint TVF XT 75
Summary of Contents for Hotpoint TVF XT 75
-
Page 1: Table Of Contents
To minimise the risk of fire Maintenance and Care, 6 Switching off the electricity Cleaning the filter after each cycle Check the drum after each cycle TVF XT 75 Cleaning the dryer Dryer description, 7 The front The back Control panel... -
Page 2: Installation
Installation Where to put your dryer ! Ensure that the end of the tube is not directed toward the air intake vent at the rear of the dryer. Place your dryer at a distance from gas ! The vent tube should not exceed 2.4 metres in ●... -
Page 3: Electrical Connection
Installation Open window venting ! Do not use extension cords. ! The power cord must not be bent or The end of the tube squashed. should be directed ! The power cord should be regularly downwards, to prevent checked. If the supply cord is damaged, it warm moist air from must be replaced by the manufacturer, its condensing in the room or... -
Page 4: Warnings
Warnings Check to see if the dryer is empty before ! The appliance has been designed and ● loading it. built according to international safety The back of the dryer could standards. ● become very hot. Never touch it These warnings are given for safety reasons and must be followed carefully. -
Page 5: To Minimise The Risk Of Fire
Warnings To minimise the risk of fire in your or explosive substances. Highly flammable tumble dryer, the following should be substances commonly used in domestic observed: environments including cooking oil, Tumble dry items only if they have been acetone, denatured alcohol, kerosene, ●... -
Page 6: Maintenance And Care
Maintenance and Care Switching off the electricity 3. Replace it correctly. Ensure the filter is fully located flush into the tumble dryer Unplug your dryer when not using it, when trim. cleaning it and during all maintenance operations. 4. Remove any lint that has built up on the inside of the door and around the door seal. -
Page 7: Dryer Description
Dryer Description The front The back Rating plate Air Intake Vent Model & Serial Control Panel numbers Vent Tube fitted here Drum Caution: Hot! Filter Control panel Indicator CHILD LOCK CLEAN FILTER HEAT LEVEL PROGRAMME Button & Light Icon Button & Lights knob Display Unit &... -
Page 8: The Display
The Display The Display has three main functions, each with its corresponding button. Dryness Sensing Levels After selecting a programme that has a Sensor Dry option, press and release the button until the required dryness sensing level is displayed. If the sensing option is not available with your selected programme, the display will flash and the buzzer will beep three times. -
Page 9: Start And Programmes
Start and Programmes Choosing a programme your laundry and take out items that are dry 1. Plug the dryer into the electrical socket. while others continue drying. When you close 2. Sort your laundry according to fabric type (see the door again, press the START/PAUSE button in Laundry). - Page 10 Start and Programmes Shirts High heat option This is a programme for shirts made from cotton. ● It can be used for load sizes up to 3kg (approximately 10 shirts). ● The duration of this programme will depend on the size of the load, the dryness setting selected and the spin ●...
- Page 11 Start and Programmes Wool Programme This is a programme for tumble dryer safe garments marked with the symbol ● It can be used for load sizes up to 1kg (approximately 3 sweaters). ● We recommend that garments are turned inside out before drying. ●...
-
Page 12: Programmes Table
Start and Programmes Programmes Table READY TO WEAR PROGRAMMES - Programme Options available Dryness Levels available ✓ ✓ - High An Automatic programme Dry from Damp ● - Medium ✓ ✓ - High An Automatic programme ● Business Week - Medium ✓... -
Page 13: The Controls
Start and Programmes The Controls Sound If selected, gives a signal at the end of the drying cycle, Programmes knob ● to remind you that the clothes are ready to be removed. ! Warning, if after pressing the START/PAUSE button Not available with the Heat &... -
Page 14: Laundry
Laundry Sorting your laundry Drying times Check symbols on clothing labels to make sure The table (see below) presents APPROXIMATE drying ● that the articles can be tumble dried. times in Minutes. Weights refer to dry garments. Sort laundry by fabric type. ●... -
Page 15: Troubleshooting
Troubleshooting One day your dryer seems not to be working. Before you call your Service Centre (see Service), go through the following troubleshooting suggestions: Problem: Possible causes / Solution: The tumble dryer won’t start. The plug is not plugged into the socket, or not making contact. ●... -
Page 16: Service
Rest assured though, no one knows a Hotpoint appliance better than we do and our service is second to none... Wherever you are we can be there - we have over 1,000 highly skilled Hotpoint engineers covering the whole of the UK and Ireland ensuring fast, reliable, local service. -
Page 17: Product Data
Product Data... (EU Regulation 392/2012) Brand Hotpoint Models TVF ET 75B TVF XT 75B Rated capacity of Cotton laundry for the standard programme at full load 7 kg Energy efficiency class B The weighted Annual Energy Consumption (AE ) 471.8 kWh Consumption per year, based on 160 drying cycles of the standard cotton programme at full and partial load, and the consumption of the low-power modes. - Page 20 1 9 5 1 2 4 5 5 8 . 0 0 N 05/2014 - LION fpg . Four Ashes, Wolverhampton...
