- Page 1 Ruijie RG-NBS5200 Series Switches RG-NBS5200-24GT4XS&RG-NBS5200-24SFP/8GT4XS& RG-NBS5200-48GT4XS Hardware Installation and Reference Guide Document Version: V1.1 Date: 2022-11-16 Copyright © 2023 Ruijie Networks...
- Page 2 Copyright Copyright © 2023 Ruijie Networks All rights are reserved in this document and this statement. Without the prior written consent of Ruijie Networks, any organization or individual shall not reproduce, extract, back up, modify, or propagate the content of this document in any manner or in any form, or translate it into other languages or use some or all parts of the document for commercial purposes.
- Page 3 Preface Thank you for using our products. This manual will guide you through the installation of the device. This manual describes the functional and physical features and provides the device install ation steps, hardware troubleshooting, module technical specifications, and specifications and usage guidelines for cables and connectors. Audience It is intended for the users who have some experience in installing and maintaining network hardware.
- Page 4 Specification An alert that contains a description of product or version support. 2. Note This manual provides installation steps, troubleshooting, technical specifications, and usage guidelines for cables and connectors. It is intended for users who want to understand the above and have extensive experience in network deployment and management, and assume that users are familiar with related terms and concepts.
-
Page 5: Product Overview
Product Overview 1 Product Overview Ruijie RG-NBS5200 series switches are mainly applicable to the small and medium-sized enterprise (SME) networks to provide services according to business needs to ensure transmission of key data. The RG-NBS5200 series switches provide various interfaces to meet different network construction scenarios. - Page 6 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Overview Current Supported Not supported Power 28 W Consumption Operating temperature: 0° C to 50° C (32° F to +122° F) Temperature Storage temperature: -40° C to +70° C (-40° F to +158° F)
- Page 7 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Overview Note: 1. Reset button 3. 10/100/1000 Base-T Ethernet port 2. System status LED 4. 10GE SFP+ port 5. Nameplate on the bottom of the device The switch restarts after the reset button is pressed for less than 2 seconds.
- Page 8 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Overview Panel Identification State Meaning The switch is not receiving power. Blinking green The switch is running, but is not connected to (0.5 Hz) Ruijie Cloud. System status LED Status Blinking green (10 The switch is being upgraded or initialized.
- Page 9 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Overview latest information. 100Base-FX SFP Port 1000Base-X 10GBase-R SFP+ Port 1000Base-X AC input Rated voltage range: 100 V to 240 V Power Supply Maximum voltage range: 90 V to 264 V...
- Page 10 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Overview Front Panel Figure 1-6 Front Panel of the RG-NBS5200-24SFP/8GT4XS Note: 1. Reset button 4. Combo port 2. System status LED 5. 10GE SFP+ port 3. 1000Base-X SFP port 6. Nameplate on the bottom of the device The switch restarts after the reset button is pressed for less than 2 seconds.
- Page 11 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Overview The device must be intended to be used in a location with equipotential bonding (such as a telecommunication center, a dedicated computer room, or a restricted access area). Heat Dissipation The RG-NBS5200-24SFP/8GT4XS adopts fan for heat dissipation, thereby ensuring normal operation.
- Page 12 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Overview Panel Identification State Meaning Solid green The port is connected. 1.3 RG-NBS5200-48GT4XS Technical Specifications Model RG-NBS5200-48GT4XS Built-in CPU, dual-core processor, and 1 GHz BOOTROM Flash Memory 256 MB SDRAM DDRIII 1 GB The copper cable is not supported.
- Page 13 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Overview Product Appearance On the front panel, the RG-NBS5200-48GT4XS Ethernet switch provides forty-eight 10/100/1000Base-T Ethernet ports and four SFP+ ports. On the back panel, it provides an AC power port.
- Page 14 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Overview Note: 1. Power cord retention clips 3. Protective earthing terminal 2. Three-hole AC power receptacle The device relies on the separate protective earthing terminal. The device installation must be permanently grounded.
- Page 15 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Overview Panel Identification State Meaning Blinking green The port is receiving or transmitting traffic.
-
Page 16: Preparation Before Installation
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Preparation Before Installation 2 Preparation Before Installation 2.1 Safety Suggestions To avoid personal injury and device damage, carefully read the safety suggestions before you install the RG -NBS5200 series. The following safety suggestions may not cover all possible dangers. - Page 17 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Preparation Before Installation is 30 mA. A leakage protector with 30 mA rated action current supports less than ten power supplies (that is, action current of the leakage protector/2/maximum leakage current of each power supply = 30/2/1 .5 = 10). In other words, the leakage protector with 30 mA rated action current supports no more than ten power supplies.
- Page 18 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Preparation Before Installation The battery may experience an extremely high or low temperature or a low air pressure at a high altitude during use, storage or transportation. Leaving the battery in an extremely high temperature and/or low air pressure surrounding environment may result in an explosion or the leakage of flammable liquid or gas .
- Page 19 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Preparation Before Installation 2.2.3 Cleanness Dust poses a severe threat to the running of the device. The indoor dust falling on the device may be absorbed by the static electricity, causing bad contact of the metallic joint. Such electrostatic absorption may occur more easily when the relative humidity is low.
- Page 20 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Preparation Before Installation 2.2.5 Grounding A good grounding system is the basis for stable and reliable operation of the device, preventing lightning strokes and resisting interference. Carefully check the grounding conditions at the installation site according to the grounding requirements, and perform grounding operations properly as requi red.
- Page 21 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Preparation Before Installation 2.2.6 Lightning Resistance When the AC power cable is imported outdoors and directly connected to the po wer port of the RG-NBS5200 series switch, use the lightning line bank to prevent the switch from being hit by lightning shocks. In this case, connect the mains supply AC cable to the lightning line bank, and connect the switch to the lightning line bank.
-
Page 22: Installation Tools
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Preparation Before Installation 2.3 Installation Tools Table 2-4 List of Installation Tools Phillips screwdriver, flathead screwdriver, related electric cables and optical cables, bolts, diagonal Common Tools pliers, and straps Special Tools... -
Page 23: Product Installation
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Installation 3 Product Installation 3.1 Installation Flowchart 3.2 Confirmations Before Installation Before installation, confirm the following points : Check whether ventilation requirements are met for the switch. - Page 24 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Installation Check whether the requirements of temperature and humidity are met for the switch. Check whether power cables are already laid out and whether the requirements of electrical current are met.
- Page 25 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Installation Figure 3-3 Attaching the Brackets to the Rack 3.3.2 Mounting the Switch on a Table Attach the four rubber pads to the recessed areas on the bottom of the switch, as shown in Figure 3-4 and Figure 3-5.
-
Page 26: Grounding The Switch
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Installation Place the switch on the table, as shown in Figure 3-5. Figure 3-5 Mounting the Switch on the Table The device must be installed and operated in the place that can restrict its movement. -
Page 27: Connecting External Cables
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Installation The grounding electric resistance should be less than 1 Ω. To guarantee the security of the body and the device, the switch must be well-grounded. The grounding resistance for combined grounding should be less than 1 Ω. -
Page 28: Checking After Installation
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Product Installation 3.7 Checking After Installation Before checking the installation, switch off the power supply so as to avoid any personal injury or damage to the component due to connection errors . -
Page 29: System Commissioning
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide System Commissioning 4 System Commissioning 4.1 Establishing the Configuration Environment Establishing the Configuration Environment Use the network cable to connect a PC to the switch. Figure 4-1 Configuration Environment Connecting the Console Cable ... - Page 30 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide System Commissioning The console cable is correctly connected; the PC is already started; parameters are configured. Checking After Power-on (Recommended) After power-on, you are advised to perform the following checks to ensure the normal operation of follow -up configurations.
-
Page 31: Troubleshooting Flowchart
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Troubleshooting 5 Troubleshooting 5.1 Troubleshooting Flowchart 5.2 Troubleshooting Common Faults Symptom Possible Causes Solution management A password is manually configured but Press the reset button to restore the default interface login it is forgotten. - Page 32 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Troubleshooting Check whether the power socket is normal. The status LED is off The power supply is not enabled, or the Check whether the power cable is correctly after power-on. power cable is loosened.
-
Page 33: Appendix A Connectors And Connection Media
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Appendix A Connectors and Connection Media 1000BASE-T/100BASE-TX/10BASE-T Ports The 1000BASE-T/100BASE-TX/10BASE-T supports adaptation of three rates and automatic MDI/MDIX crossover at these three rates. The 1000BASE-T complies with IEEE 802.3ab, and uses the cable of 100-ohm Category-5 or Supper Category-5 UTP or STP, which can be up to 100 m. - Page 34 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix A Connectors and Connection Media Optical Fiber Connection For the optical fiber ports, select single-mode or multimode optical fibers for connection according to the fiber module connected. Figure A-4 shows the connection schematic diagram.
-
Page 35: Appendix B Mini-Gbic And Spf+ Module
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix B Mini-GBIC and SPF+ Module Appendix B Mini-GBIC and SPF+ Module SFP modules (mini-GBIC module) and 10G SFP+ modules are available to cope with interface types of switch modules. You can select the mini-GBIC module to suit your specific needs. The models and technical specifications of som e mini-GBIC and 10G SFP+ modules are listed below. - Page 36 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix B Mini-GBIC and SPF+ Module GE-SFP-SX -9.5 GE-SFP-LX 1310 -9.5 SFP-MM850 -9.5 SFP-SM1310 1310 -9.5 Table B-2 Models and Technical Specifications of the Mini-GBIC-GT Module Standard 1000Base-T SFP Type DDM (Yes/No)
- Page 37 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix B Mini-GBIC and SPF+ Module Rate/Distance Module Pairs GE-SFP-SX-SM1310-BIDI 1000 Mbps/500 m GE-SFP-SX-SM1550-BIDI GE-SFP-LX20-SM1310-BIDI 1000 Mbps/20 km GE-SFP-LX20-SM1550-BIDI GE-SFP-LH40-SM1310-BIDI 1000 Mbps/40 km GE-SFP-LH40-SM1550-BIDI XG-SFP-SR-SM1270-BIDI 10 Gbps/300 m XG-SFP-SR-SM1330-BIDI XG-SFP-LR-SM1270-BIDI 10 Gbps/10k m...
- Page 38 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix B Mini-GBIC and SPF+ Module Table B-6 Models and Technical Specifications of the 10G SFP+ Cables Copper Module Connector Conductor Wire Data Model Cable Type Type Diameter (AWG) Rate(Gb/s) (Yes/No)
-
Page 39: Appendix C Surge Protection
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix C Surge Protection Appendix C Surge Protection Installing the AC Power Arrester (Surge Protection Cable Row) The external surge protection cable row must be used on the AC power port to preven t the switch from being struck by lightning when the AC power cable is introduced from the outdoor and directly connected to the power port of the switch. - Page 40 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix C Surge Protection During the switch usage, the Ethernet port arrester must be connected to the switch to prevent the switch damage by lightning before the outdoor network cable connects to the switch.
- Page 41 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix C Surge Protection Poor arrester grounding: The grounding line must be as short as poss ible to ensure that it is in good contact with the switch grounding terminal. Use the multimeter to confirm the contact after grounding.
-
Page 42: Appendix D Cabling Recommendations
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix D Cabling Recommendations Appendix D Cabling Recommendations When RG-NBS5200 series switches are installed in standard 19-inch cabinets, cables are tied in the binding rack on the cabinet by the cabling rack, and top or bottom cabling is adopted according to the actual situation in the equipment room. - Page 43 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix D Cabling Recommendations Route and bundle power, signal, ground cables separately. When the cables are close to each other, cross them. When power cables are parallel to signal cables, the distance between them must b e 30 mm (1.18 in.).
- Page 44 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix D Cabling Recommendations Wrap up unnecessary or excess cables and bind them to the appropriate rack position, where device operation is not affected and no damages occur to the device and cables during commissioning.
- Page 45 Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix D Cabling Recommendations Diameter of Cable Bundle (mm) Space between Bundles (mm) 80 to 150 10 to 30 150 to 200 200 to 300 No knot is allowed in cabling or bundling.
-
Page 46: Appendix E Site Selection
Ruijie RG-NBS5200 Series Switches Hardware Installation and Reference Guide Appendix E Site Selection Appendix E Site Selection The equipment room should be at least 5 km away from the heavy pollution source such as the smelter, coal mine , and thermal power plant, 3.7 km away from the medium pollution source such as the chemical industry, rubber...
