Brigade DC-204-AI Quick Start Manual

Ai connected dashcam
Hide thumbs Also See for DC-204-AI:

Advertisement

Table of Contents

QuickStart Guide
for the AI Connected Dashcam
Part Number:
7477/7487
Model Number: DC-204-AI (UK/EU)
DC-205-AI (NA)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC-204-AI and is the answer not in the manual?

Questions and answers

Related Manuals for Brigade DC-204-AI

Summary of Contents for Brigade DC-204-AI

  • Page 1 QuickStart Guide for the AI Connected Dashcam Part Number: 7477/7487 Model Number: DC-204-AI (UK/EU) DC-205-AI (NA)

  • Page 2: Installing The Dashcam

    Par la présente, Brigade Electronics Group PLC déclare que l’équipement Pelo presente, a Brigade Electronics Group PLC declara que o tipo de radio de type DC-204-AI est conforme à la directive 2014/53/UE et au equipamento de rádio DC-204-AI está em conformidade com a Diretiva règlement S.I.
  • Page 3 Step 2: SIM Installation Instructions 1. Please ensure that your working environment is clean and dry before beginning the SIM card installation. 2. To gain access to the SIM card slot, use the TORX screwdriver provided and undo the screw to reveal the slot. 3.

  • Page 4: Choose The Mounting Location

    Step 3: Choose the Mounting Location 4" 4" 0.5 - 4m 20" - 13' Select a suitable location within the wiper area to mount the dashcam that provides a clear view of the road ahead and does not obstruct the view while driving. The most suitable location is near the rear view mirror on the windscreen preferably on the driver’s side.
  • Page 5 Step 4: Mount the Dashcam Using an alcohol pad, thoroughly clean and then dry the area of the windscreen where the device will be mounted. Remove the bracket from the kit and peel off the 3M protective film. Ensure that the “UP” arrows are pointing towards the top of the windscreen then stick the bracket on the windshield.
  • Page 6 Step 5: Connecting to the Power Lead Route the cable from the power source to the dashcam’s location Connect the power: - POWER to permanent feed Power Red - GND to ground GND Black CAN.H Yellow - ACC to ignition CAN.L Green - SENSOR 1 must connect to ACC Orange...
  • Page 7 Step 6: Test the Dashcam Status LEDs: Off: Device power off Green: Device power on Off: No alarm Red flash: Alarm happens Off: GPS working normal Red flash: GPS signal poor Off: Connected to server Red: Unable to connect to server Panic Button Off: WiFi disabled/Client mode on Green: AP mode on...

  • Page 8: Initial Setup

    Step 7: Initial Setup 1. Download Smart Controller application from the app store on your mobile. 2. Turn AP Mode on, to do this, click the button on the dashcam twice. 3. Connect to the Wi-Fi ‘ST-XXXXXXXXXX’ 4. On the Smart Controller application login with the default login: Username: admin Password: admin Please refer to the SIM Pack instructions to complete SIM activation form.
  • Page 9 Step 8: Calibration To calibrate the unit, please select the preferences tab in the Smart Controller app. Enter the parameters highlighted below Click save and exit the app DSC Autocalibration will commence as soon as the vehicle is moving and will complete after five minutes...
  • Page 10 Notes: - Audio: Set to off by default, to enable it please refer to Section 4.2.2.2 of the DC-204-AI Series Installation & Operation Guide - Privacy mode is disabled by default, to enable it, please refer to Section 4.4.2.3 of the DC-204-AI Series Installation &...
