Specifications

Display
Maximum data points
Channels
Sample rate
Transient capture
Analysis software
Data output
Open input indication
Low battery indication
Power supply
Battery life
AC Adaptor
Standards
Operating Temperature
Operating Humidity
Current Clamp Jaw opening
Dimensions
Weight
Voltage
40Hz to 1kHz
Current
50/60Hz
Peak Measurement
Copyright © 2012 Extech Instruments Corporation (a FLIR company)
All rights reserved including the right of reproduction in whole or in part in any form.
This Manual: http://www.manuallib.com/file/2693250
Multi-function LCD
16,350 Voltage and 16,350 Current values
Single channel, TRMS AC Voltage or Current
1s to 24h selectable
>0.244mS
2000/XP/ Vista
USB port
"LO" appears on the LCD
Empty battery symbol appears on the LCD
4 AAA Batteries and 1 CR 3V memory button battery (CR2032 or
equivalent)
5 days (approximately)
9V, 0.5A
C C
CAT III 600V
0 to 50°C , 32 to 122°F
<70% RH
12.7mm (0.5")
114 x 63 x 34mm (4.5 x 2.5 x 1.3")
248g (8.7oz.)
Range
10VAC to 600.0VAC
10A to 200.0A
8.0 to 850.0V
www.extech.com
Accuracy
±2.0%±1V
±2.0%±1A
±5.0%
6 DL150-EU-EN-V2.4-3/12
