D
S
ean
toves
Dean Forge Fabrication Ltd. Dean Prior, Buckfastleigh, Devon TQ11 0LS
T e l:
0 1 3 6 4 6 4 3 5 7 4
w w w.d e a n–f o r g e.c o.u k
e m a i l: s t o v e s @ d e a n-f o r g e.c o.u k
Operating Instructions for the Dean Forge Hembury 6 & 8
All stoves meet the essential type test requirement BS
EN13240:2001 + Amd 2:2004, CE marked
Unpacking Stove
Remove all packaging and stickers, Check the protective brick lining and the baffle plate has
not move in transit. Remove the glove pack and operating tool from the inside of the stove.
Safety Note
Warning- The external parts of the appliance will get very hot to the touch and due care will
be needed when operating.
All stoves before being operated must be checked that the installation complies with all local,
national and European standards.
Before the stove is first used or when fitting other appliances into the room, please check that
adequate air vents are in place to cover the requirements of such appliances.
Extractor Fans. When operating an extractor fan in the same room or space as the appliance
the extractor fan could cause the stove not to function properly and pull dangerous fume into
the room. This must be checked by a trained qualified engineer before using the stove
Important
You will find an H shaped plate with holes drill in it, situated on the top of the main grate. This
grate is design to retain the ash when burning wood only and must NOT be use when burning
solid fuel (smokeless fuel or similar) or a mixture of wood and solid fuel. This plate can be
lifted out prior to lighting the fire, if required. Although the stove will burn wood straight on
the solid fuel grate, the H shaped plate retains the ash and helping to give a slower and hotter
burn. The ash can be pulled forward and pushed to the back, where it will drop though to the
ash pan. Always leave a small layer of ash on the plate.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dean Forge Hembury 6
Summary of Contents for Dean Forge Hembury 6
- Page 1 @ d e a n-f o r g e.c o.u k Operating Instructions for the Dean Forge Hembury 6 & 8 All stoves meet the essential type test requirement BS...
-
Page 2: Door Operation
Wood & Suitable fuels Dry wood, 18% moisture content or below must be used or the stove and flue will tar up and the door won’t stay clean. Wood is best seasoned by splitting it into a log and dried for 2 years in a covered area allowing air to pass through. - Page 3 The primary air control is indicated with a single slot. This control is used for lighting the fire or boosting the fire. This is also the main control when burning solid fuel. Pull fully out for maximum air flow to the fire and fully in to close the air flow. The secondary air wash control is indicated with double slots.
- Page 4 When loading the fire be careful not to leave logs projecting over the log retainer as you may crack the glass when closing the door. The ash should be emptied before it reaches the top of the ash pan to prevent ash dropping into the primary air ducts.
-
Page 5: Pre-Season Check
Please Note: When lighting the stove for the first time the paint on the stove will cure and give off a metallic smell. It is advisable to ventilate the room ie. open the windows. This will subside after the stove has been burning hot for at least 2 hours. The appliances have been assessed and are suitable for intermittent burning. -
Page 6: Health And Safety Precautions
As with all stoves, fireguards must be installed when young children are present. Chimney All Dean Stoves must have a minimum chimney height of 4m measuring from the stove outlet, the chimney must not be less than 150mm (6”) internal diameter. -
Page 7: Register Plates
Always check the current building regulations. Flue Connections and Outlets Dean Stoves can be flued from the top and the back, or with a vertical back box. Horizontal flue from back of stove should not exceed 150mm. -
Page 8: Data Plate
All flue connections must be sealed. Doors in the register plate must be present or a soot box fitted in the back or side of the fireplace to enable access to clean the chimney when the stove is installed without a flue liner. The installation of a flue liner is recommended. If the chimney has been lined and cannot be swept through the stove an access door on the first length of flue must be installed for cleaning access. - Page 9 It must be considered when fitting air vents that it is taken into account any other appliance fitted within the room. Please Note: Extractor fans when operating in the same room or space as the appliance may cause problems. Air vent inlet grills must not be inadvertently blocked. Air vents must not be fitted in positions where they can be inadvertently covered up.
-
Page 10: Ec Declaration Of Conformity
EC Declaration Of Conformity The Undersigned, representing the following: Manufacturer Dean Forge Ltd Dean Prior, Buckfastleigh, Devon, TQ11 0LS Herewith declare that the products: Description Product Code Hembury 5 STDFHE5MF Hembury 5 Slimline STDFHE5SLMF Hembury 6 STDFHE6MF Hembury 8 STDFHE8MF Description of product: Hembury multifuel heating stove product range. - Page 11 Provisions to which the product conforms: Product: Roomheater fired by solid fuel as covered under the scope of the standards listed. Intended use: Space heating in residential building. Characteristic Performance Report Fire Safety Satisfies Hembury 5- STDFHE5MF Co @ 13% 0² Wood 0.31% Ancit 0.31% 5.3Kw @ 83% Wood -5Kw @ 67.8% Ancit 6931-2 Emission of combustible...
- Page 12 THE DEAN FORGE FABRICATION LTD STOVES GUARANTEE Dean Forge Fabrication Ltd offers a five year guarantee which covers the main body of the stove for manufacturing defects. In the event of any failure we will replace any defective part free of charge, labour cost excluded.
- Page 14 Dean Forge Fabrication Ltd Dean Prior Buckfastleigh Devon TQ11 0LS PRODUCT REGISTRATION Name ......................Address ...............................................................................Phone Number: ..........Suppliers Details: Name ......................Address ...............................................................................Phone Number: ..........Installers Details: Name ......................Address ......................................................................
