D
S
ean
toves
Dean Forge Fabrication Ltd. Dean Prior, Buckfastleigh, Devon TQ11 0LS
T e l: 0 1 3 6 4 6 4 3 5 7 4
w w w.d e a n–f o r g e.c o.u k
e m a i l: s t o v e s @ d e a n-f o r g e.c o.u k
Operating Instructions for the Dean Stoves
Hembury 5 SE
nd
(HEM5SE issue 2
July 2013)
All stoves meet the essential type test requirement BS
EN13240:2001 + and 2:2004, CE marked
The Clean Air Act 1993 and Smoke Control Areas
Under the Clean Air Act local authorities may declare the whole or part of the district of the
authority to be a smoke control area. It is an offence to emit smoke from a chimney of a
building, from a furnace or from any fixed boiler if located in a designated smoke control area.
It is also an offence to acquire an "unauthorised fuel" for use within a smoke control area
unless it is used in an "exempt" appliance ("exempted" from the controls which generally apply
in the smoke control area).
The Secretary of State for Environment, Food and Rural Affairs has powers under the Act to
authorise smokeless fuels or exempt appliances for use in smoke control areas in England. In
Scotland and Wales this power rests with Ministers in the devolved administrations for those
countries. Separate legislation, the Clean Air (Northern Ireland) Order 1981, applies in
Northern Ireland. Therefore it is a requirement that fuels burnt or obtained for use in smoke
control areas have been "authorised" in Regulations and that appliances used to burn solid
fuel in those areas (other than "authorised" fuels) have been exempted by an Order made and
signed by the Secretary of State or Minister in the devolved administrations.
The Dean Stoves, Hembury 5 SE has been recommended as suitable for use in smoke
control areas when burning wood logs.
To use the Hembury 5 SE in smoke controlled areas the smoke control kit must be fitted to the
stove.
Further information on the requirements of the Clean Air Act can be found here :
http://smokecontrol.defra.gov.uk/
Your local authority is responsible for implementing the Clean Air Act 1993 including
designation and supervision of smoke control areas and you can contact them for details of
Clean Air Act requirements
Important
You will find an H shaped plate with holes drill in it, situated on the top of the main grate. This
grate is design to retain the ash when burning wood only and must NOT be use when burning
solid fuel (smokeless fuel or similar) or a mixture of wood and solid fuel. This plate can be
lifted out prior to lighting the fire, if required. Although the stove will burn wood straight on
the solid fuel grate, the H shaped plate retains the ash and helping to give a slower and hotter
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Hembury 5 SE and is the answer not in the manual?

Questions and answers

Related Manuals for Dean Hembury 5 SE

Summary of Contents for Dean Hembury 5 SE

  • Page 1 The Dean Stoves, Hembury 5 SE has been recommended as suitable for use in smoke control areas when burning wood logs. To use the Hembury 5 SE in smoke controlled areas the smoke control kit must be fitted to the stove.

  • Page 2: Safety Note

    burn. The ash can be pulled forward and pushed to the back, where it will drop though to the ash pan. Always leave a small layer of ash on the plate. Unpacking Stove Remove all packaging and stickers, Check the protective brick lining and the baffle plate has not move in transit.

  • Page 3: Door Operation

    Door Operation The door handle can become very hot so use the glove provided. Handle:- When closed the door handle will be pointing down and straight with the door, twist the door handle about ¼ of a turn anti – clockwise to open the door. Controlling the stove Diagram A: Primary and secondary air controls situated below the door...
  • Page 4 Lighting The Stove When Using Wood Lay a fire of sticks and paper. Firelighters can be used if necessary. Check the secondary air lever is fully open and the primary air is partially open. Light the fire and as the fire catches the paper you may then fully open the primary air vents.

  • Page 5: Pre-Season Check

    Warning: The ash pan and content can be hot and must be store in a non- flammable container away from flammable material then disposed of only when they are completely cold and there no risk of causing a fire. Lighting The Stove With Solid Fuel Remove the H shaped woodburning plate if in place.
  • Page 6 If the stove has been used for a long period of time we suggest the chimney be swept twice a year. Notes Down draughts In adverse weather conditions down a draught may occur this could make the stove smoke, if this should happen shut all the stove air controls.

  • Page 7: Health And Safety Precautions

    As with all stoves fireguards must be installed when young children are present. Chimney All Dean Stoves must have a minimum chimney height of 4m measuring from the stove outlet, the chimney must not be less than 150mm (6”) internal diameter.

  • Page 8: Register Plates

    Minimum from back of Minimum from side of appliance to combustibles appliance to combustibles Hembury 5 SE 700mm 600mm It may be necessary to shield a beam or mantle piece from the heat. The single wall flue must be at least 3 times its diameter away from combustible materials i.e. 150mm (6”) flue 450mm (18”) away from combustible materials.
  • Page 9 The Hembury 5 SE model requires a 125mm (5”) first length of flue then stepping up into a minimum of 150mm (6”) liner. When the Hembury 5 SE has a smoke except air slider fitted the flue liner can be reduced to 125mm (5”).

  • Page 10: Data Plate

    DEFRA screw and close combustion manifold. The Hembury 5 is supplied with a DEFRA screw fitted and must be left in place when using the stove in smoke controlled areas. This screw can be removed when installed in a non-smoke controlled area and a minimum of 150mm diameter flue is fitted to the stove.
  • Page 11 October 2010 a compliant Carbon Monoxide Alarm must be fitted Table of mean flue temperatures with closed doors Stove Type Flue gas temp down stream of spigot, closed doors. Wood logs Ancit Hembury 5 SE 233°C 289°C Flue Gas Mass Flow Stove Type Flue gas mass flow (g/s)

  • Page 12: Ec Declaration Of Conformity

    EC Declaration Of Conformity The Undersigned, representing the following: Manufacturer Dean Forge Ltd Dean Prior, Buckfastleigh, Devon, TQ11 0LS Herewith declare that the products: Description Product Code Hembury 5 STDFHE5MF Hembury 5 Slimline STDFHE5SLMF Hembury 6 STDFHE6MF Hembury 8 STDFHE8MF Description of product: Hembury multifuel heating stove product range.
  • Page 13 Provisions to which the product conforms: Product: Roomheater fired by solid fuel as covered under the scope of the standards listed. Intended use: Space heating in residential building. Characteristic Performance Report Fire Safety Satisfies Hembury 5- STDFHE5MF Co @ 13% 0² Wood 0.31% Ancit 0.31% 5.3Kw @ 83% Wood -5Kw @ 67.8% Ancit 6931-2 Emission of combustible...
  • Page 14 THE DEAN FORGE FABRICATION LTD STOVES GUARANTEE Dean Forge Fabrication Ltd offers a five year guarantee which covers the main body of the stove for manufacturing defects. In the event of any failure we will replace any defective part free of charge, labour cost excluded.

  • Page 16: Product Registration

    ..........................................................Phone Number: ..........Suppliers Details: Name ......................Address ...............................................................................Phone Number: ..........Installers Details: Name ......................Address ...............................................................................Phone Number: ..........HETAS Registration Number……………………………………………………. Dean Forge Fabrication Ltd Dean Prior Buckfastleigh Devon TQ11 0LS...
