ABB LMIU1500 Instruction Manual

Lmiu 1500w mini inverter

Advertisement

Quick Links

THIS UNIT CONTAINS A
RECHARGEABLE VALVE-REGULATED
LEAD ACID BATTERY. PLEASE
RECYCLE OR DISPOSE OF
PROPERLY.
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ THIS MANUAL AND FOLLOW ALL SAFETY INSTRUCTIONS
THOROUGHLY BEFORE OPERATING THE
BEFORE CONTACTING TECHNICAL SUPPORT MAKE SURE TO FOLLOW ALL STEPS IN SEQUENCE AND REFER TO
THE TROUBLESHOOTING GUIDE INCLUDED IN THIS MANUAL.
1. Install in accordance with the National Electrical Code and local regulations.
2. The LMIU contains potentially hazardous voltages. Installation, maintenance and service work should be performed by qualified
and trained personnel.
3. Units to be installed only as per configuration described in this instruction manual.
4.
Electricians and end-users need to ensure product system compatibility before final installation.
5. The AC voltage rating of this equipment is specified on the product label. Do not connect the LMIU equipment to any other voltage.
6. All unused wires must be capped to prevent shorting.
7. The LMIU should be mounted securely and in locations and at heights where it will not be readily subjected to tampering by
unauthorized personnel.
8. The use of accessory equipment and replacement parts not recommended by manufacturer may cause an unsafe condition and will
void the warranty.
9. Do not mount near gas or electric heaters.
10. Do not let power supply cords touch hot surfaces.
11. Do not use this equipment for other than its intended use.
12. DO NOT USE OUTDOORS.
13. The LMIU uses sealed valve regulated lead acid batteries. Batteries can be punctured if not handled properly, therefore use caution
when servicing batteries. In the event battery acid comes in contact with eyes or skin, flush with fresh water and consult a physician
immediately.
MODEL NUMBER
LMIU1500
120/277 VAC, 60Hz
NOTE: At 120Vac, unit is rated at power factor 0.8. For loads having a power factor below 0.8, unit capacity needs to be derated.
At 277Vac, unit is rated at unity power factor. For loads having a power factor below 1, unit capacity needs to be derated.
All ABB inverter products receive 100% quality inspection before shipment to ensure proper and satisfactory operation.
When operated under normal conditions, ABB inverter products will provide years of dependable service.
For the complete warranty information, please refer to the landing page of our website (http://www.lightalarms.com).
Tel: (888) 552-6467
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
AC SPECS
17.6 / 6.3 Amps
WARRANTY
Fax: (800) 316-4515
LMIU 1500W Mini Inverter
INTERRUPTIBLE EMERGENCY LIGHTING
UNIT INVERTER INSTRUCTION MANUAL
LMIU INVERTER SYSTEM
U
EMERGENCY POWER AVAILABLE FOR LOAD
90 MIN
2H
1500W
1136W
LMIU 1500W Mini Inverter
APPROX.
WEIGHT
3H
4H
789W
673W
395lbs.
11/22 750.2207 Rev. B
1/12

Advertisement

Table of Contents
loading

Summary of Contents for ABB LMIU1500

  • Page 1 At 277Vac, unit is rated at unity power factor. For loads having a power factor below 1, unit capacity needs to be derated. WARRANTY All ABB inverter products receive 100% quality inspection before shipment to ensure proper and satisfactory operation. When operated under normal conditions, ABB inverter products will provide years of dependable service.
  • Page 2 LMIU 1500W Mini Inverter WARNING: DE-ENERGIZE THE CIRCUIT BEFORE INSTALLATION OR MAINTENANCE. WARNING: DO NOT ENERGIZE THE CIRCUIT UNTIL ALL STEPS HAVE BEEN SUCCESSFULLY COMPLETED. ALWAYS TURN OFF THE INVERTER MODULE AND THE AC SUPPLY TO THE EQUIPMENT AND DISCONNECT THE BATTERY BEFORE SERVICING. ONLY QUALIFIED SERVICE TECHNICIANS WARNING: SHOULD SERVICE THIS EQUIPMENT.
  • Page 3: Installation

    LMIU 1500W Mini Inverter INSTALLATION STEP 1: MOUNTING THE MINI INVERTER TO WALL (SEE FIGURE 1) a. Remove the front cover of the Mini Inverter cabinets by removing the two screws located on the front of the cover of each cabinet and retain for later use.
  • Page 4 LMIU 1500W Mini Inverter ELECTRICAL SINGLE LINE DIAGRAM FOR LMIU 1500W SINGLE CIRCUIT Configuration:120Vin//120Vout Circuit: Normally-ON OUTPUT SWITCHED INPUT Neutral(Wht) Mini Inverter comes pre-wired 277VAC(ORG) for 120V. For 277V connections 120VAC(BLK) remove red wire from Neutral(Wht) Transformer 120V terminal and wire UNSWITCHED to 277V terminal.
  • Page 5 LMIU 1500W Mini Inverter STEP 4: WIRING TO SWITCHED INPUT POWER SUPPLIED TO THE SWITCHED AND UNSWITCHED INPUTS MUST BE FED FROM THE SAME CAUTION: BRANCH CIRCUIT. The Mini Inverter can be configured for various modes of operation as described below. a.
  • Page 6: Manual Test

    LMIU 1500W Mini Inverter STEP 7: START-UP PROCEDURE a. Turn on switch located on right hand side of inverter module in the electronic cabinet. Emergency lights and indicator will not illuminate. b. Energize AC main supply. Status Indicator on the left side of electronic cabinet will illuminate. For information on the Status Indicator, see Information Section: FEATURES AND OPTIONS.
  • Page 7: System Reset

    LMIU 1500W Mini Inverter SYSTEM RESET Resetting the system: Depending on the sequence of installation, some units may require a system reset. To reset, press and hold test switch on left side of unit for 6 seconds. MAINTENANCE BATTERY: The batteries supplied in this equipment are high quality maintenance-free Valve Regulated Lead Acid design. Ambient temperature of electrical room where batteries are installed should be 25°...
  • Page 8 LMIU 1500W Mini Inverter NORMALLY-OFF OPERATION Circuit configured to operate in Normally-Off mode. UTILITY UNSWITCHED Utility (120V) Neutral Unswitched INPUT input Neutral UNSWITCHED Ground INPUT Configuration shown: 120V in // 120V out. For 277V in // 277V out, SWITCHED connect utility hot wire to 277V position TB1 LOCATION INPUT CIRCUIT #1...
  • Page 9: Features And Options

    LMIU 1500W Mini Inverter FEATURES AND OPTIONS SYSTEM OPERATION • The diagnostic/charger is a self-contained, fully automatic microcontroller-based system. • When installation is complete, only the battery connection is needed. AC power need not be energized. Unit goes directly into lockout mode and waits for AC power to be restored. 1.
  • Page 10 LMIU 1500W Mini Inverter 4. LIGHTING LOAD TESTING The test is fully automatic. To ensure accurate data from a connected and functional lighting load: • The battery must be at or near full power. The program will delay data capture for a minimum of 48 hours following any discharge or reset. •...
  • Page 11: Troubleshooting Guide

    LMIU 1500W Mini Inverter TROUBLESHOOTING GUIDE STATUS TROUBLESHOOTING GUIDE INDICATOR SYMPTOMS PROBLEM CORRECTIVE ACTION (LED) None, if unit is in Normally ON Lamp load is ON Unit is operating correctly. mode. None, if unit is in Normally OFF Lamp load is OFF Unit is operating correctly.
  • Page 12 Consult Customer Service for current warranty information. All information and specifications contained in these instructions are subject to change due to engineer design, errors and omissions. © 2022 ABB. All rights reserved. Tel: (888) 552-6467 Fax: (800) 316-4515 11/22 750.2207 Rev. B...
  • Page 13: Important Safeguards

    At 277Vac, unit is rated at unity power factor. For loads having a power factor below 1, unit capacity needs to be derated. WARRANTY All ABB inverter products receive 100% quality inspection before shipment to ensure proper and satisfactory operation. When operated under normal conditions, ABB inverter products will provide years of dependable service.
  • Page 14 LMIU1500W - 4 Option Mini Inverter WARNING: DE-ENERGIZE THE CIRCUIT BEFORE INSTALLATION OR MAINTENANCE. WARNING: DO NOT ENERGIZE THE CIRCUIT UNTIL ALL STEPS HAVE BEEN SUCCESSFULLY COMPLETED. ALWAYS TURN OFF THE INVERTER MODULE AND THE AC SUPPLY TO THE EQUIPMENT AND DISCONNECT THE BATTERY BEFORE SERVICING.
  • Page 15 LMIU1500W - 4 Option Mini Inverter INSTALLATION STEP 1: MOUNTING THE MINI INVERTER TO WALL (SEE FIGURE 1) a. Remove the front cover of the Mini Inverter cabinets by removing the two screws located on the front of the cover of each cabinet and retain for later use.
  • Page 16 LMIU1500W - 4 Option Mini Inverter ELECTRICAL SINGLE LINE DIAGRAM FOR LMIU 1500W WITH 4 CIRCUITS (-4 OPTION) Configuration:120Vin//120Vout OUTPUT Circuit #1: Normally-ON SWITCHED INPUT Circuit #2: Normally-OFF Circuit #4 Circuit #3 & 4: Switched Circuit #3 Circuit #2 Circuit #1 Neutral(Wht) Mini Inverter comes pre-wired for 120V.
  • Page 17 LMIU1500W - 4 Option Mini Inverter STEP 4: WIRING TO SWITCHED INPUT POWER SUPPLIED TO THE SWITCHED AND UNSWITCHED INPUTS MUST BE FED FROM THE SAME CAUTION: BRANCH CIRCUIT. The Mini Inverter model with -4 option, and each circuit within in it, can be configured for various modes of operation as described below. a.
  • Page 18: Step 7: Start-Up Procedure

    LMIU1500W - 4 Option Mini Inverter STEP 6: START-UP WITH NO LOAD CONNECTED. a. Confirm load is not connected. b. Follow start-up procedure in Step 7. STEP 7: START-UP PROCEDURE a. Turn on switch located on right hand side of inverter module in the electronic cabinet. Emergency lights and indicator will not illuminate.
  • Page 19 LMIU1500W - 4 Option Mini Inverter ® NEXUS (OPTION) ® NO WIRING IS REQUIRED FOR THE NEXUS VERSION. See Nexus® addendums: 750.1532 and 750.1641 for more information and antenna installation. See Nexus®Pro addendums: 750.1641 and 750.2060 for antenna installation and important information before powering up unit. MANUAL TEST Press test switch for 1 second to initiate a 1 minute manual test.
  • Page 20 LMIU1500W - 4 Option Mini Inverter NORMALLY-ON OPERATION All four(4) circuits configured to operate in Normally-On mode. For 277 V output: red wire must be removed from 120 V side of Important: terminal block and wired to 277 V side of terminal block. Switched input Orange Orange...
  • Page 21 LMIU1500W - 4 Option Mini Inverter NORMALLY-OFF OPERATION All four(4) circuits configured to operate in Normally-Off mode. For 277 V output: red wire must be removed from 120 V Important: side of the terminal block and wired to 277 V side of terminal block.
  • Page 22 LMIU1500W - 4 Option Mini Inverter SWITCHED LOAD OPERATION All four(4) circuits controlled by switches. Utility Orange Orange input Neutral Black Black TB1 LOCATION Ground Hot(120V) Neutral UTILITY Neutral TO OBTAIN Ground TO OBTAIN CAP ALL 120Vac OUTPUT 277Vac OUTPUT UNUSED CONNECT RED WIRE TO APPROPRIATE NEUTRAL...
  • Page 23 LMIU1500W - 4 Option Mini Inverter COMBINATION OF NORMALLY-ON, NORMALLY-OFF AND SWITCHED LOAD OPERATION Circuit #1: Normally-ON Circuit #2: Normally-OFF Circuit #3 & 4: Switched Utility Orange Orange input Neutral Black Black TB1 LOCATION Ground Hot(120V) Neutral UTILITY Neutral Ground TO OBTAIN CAP ALL TO OBTAIN...
  • Page 24 LMIU1500W - 4 Option Mini Inverter FEATURES AND OPTIONS SYSTEM OPERATION • The diagnostic/charger is a self-contained, fully automatic microcontroller-based system. • When installation is complete, only the battery connection is needed. AC power need not be energized. Unit goes directly into lockout mode and waits for AC power to be restored. 1.
  • Page 25 LMIU1500W - 4 Option Mini Inverter 4. LIGHTING LOAD TESTING The test is fully automatic. To ensure accurate data from a connected and functional lighting load: • The battery must be at or near full power. The program will delay data capture for a minimum of 48 hours following any discharge or reset. •...
  • Page 26 LMIU1500W - 4 Option Mini Inverter Terminal block for Dry form “C” contact Terminal block location for dimming control Figure 12 2. Connect the Lighting Control signal cables from the external Lighting Dimming Control panel to the terminal blocks (left side of cabinet) identified by IN1, IN2, IN3 or IN4 in the Mini Inverter.
  • Page 27: Troubleshooting Guide

    LMIU1500W - 4 Option Mini Inverter TROUBLESHOOTING GUIDE STATUS TROUBLESHOOTING GUIDE INDICATOR SYMPTOMS PROBLEM CORRECTIVE ACTION (LED) None, if unit is in Normally ON Lamp load is ON Unit is operating correctly. mode. None, if unit is in Normally OFF Lamp load is OFF Unit is operating correctly.
  • Page 28 Consult Customer Service for current warranty information. All information and specifications contained in these instructions are subject to change due to engineer design, errors and omissions. © 2022 ABB. All rights reserved. Tel: (888) 552-6467 Fax: (800) 316-4515 11/22 750.2208 Rev. B...
  • Page 29 ADDENDUM NORMALLY-ON OPERATION: All four(4) circuits configured to operate in Normally-On mode. For 277 V output: red wire must be removed from 120 V side of Important: terminal block and wired to 277 V side of terminal block. Orange Orange Switched input Black Black...
  • Page 30 ADDENDA FONCTIONNEMENT NORMALEMENT ALLUMÉ: Tous les quatre (4) circuits configurés pour fonctionner en mode normalement allumé. Pour la sortie 277 V: le fil rouge doit être enlevé du côté 120 V du Important: bornier et câblé au côté 277 V du bornier.
