Summary of Contents for GOVECS FLEX 2.0

  • Page 1 USER MANUAL...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Basic information Battery Introduction �����������������������������������������������������������������������������4 Battery swap �������������������������������������������������������������������������20 Safety ��������������������������������������������������������������������������������������5 Charging the battery �������������������������������������������������������������21 Safe riding �������������������������������������������������������������������������������6 Safety equipment VIN ������������������������������������������������������������������������������������������7 Lights �����������������������������������������������������������������������������������25 Vehicle overview Tires ��������������������������������������������������������������������������������������26 Main components �������������������������������������������������������������������8 Brakes �����������������������������������������������������������������������������������27 Control and steering components ������������������������������������������9 Brakes fluid level ������������������������������������������������������������������28 Controls User instructions...
  • Page 3: Introduction

    GOVECS scooter and to welcome you among the great number of GOVECS scooter drivers� The batteries installed in GOVECS scooters, are subject to recycling according to the Directive 2006/66/EC of the European Parliament and of the Council of 6 September 2006 on batteries and accumulators and waste batteries and This manual includes instructions concerning proper use, accumulators and repealing Directive 91/157/EEC�...
  • Page 4: Vin

    SAFE RIDING VEHICLE IDENTIFICATION NUMBER (VIN) BEFORE FIRST USE RIDING TECHNIQUE The Vehicle Identification Number is located on Before first use of the scooter charge the battery • Always follow traffic regulations� the right side at the back of the frame� to 100%! •...
  • Page 5: Main Components

    MAIN COMPONENTS CONTROL AND STEERING COMPONENTS 1� Headlight 2� Steering 3� Driver's seat 4� Topcase 5� Rear light 6� Number plate holder 7� Rear wheel, brake, in-hub motor 8� Central stand 9� Crash bumper 10� Side stand 11� Front wheel and front brake 12�...
  • Page 6: Left Hand Controls

    LEFT HAND CONTROLS RIGHT HAND CONTROLS HIGH/LOW BEAM THROTTLE • Press the button to switch between low and high beam for the front lights� • Twist backwards to accelerate� • Use the high beam according to traffic regulations� • Release to decelerate� •...
  • Page 7: Display Elements

    APP & DOWNLOADS Low beam light Warning sign High beam light Clock We are working on it right now and soon you can download the GOVECS FLEX 2�0 App for Android and iOS� Left indicator Right indicator GPS signal Battery count Coverage...
  • Page 8: Ignition

    IGNITION SETTINGS MENU GENERAL OVERVIEW USING THE NFC CARD To access the settings menu press the "Mode" button on the handlebar of the scooter continuously, until the screen changes� To make use of it, the "Mode" button is used to navigate through the menus and the "Horn" button to enter a sub-menu and confirm a selection�...
  • Page 9 7� Position the new key card in front of the NFC sign, until the message "new Key Card Paired" appears on the screen� Now this key card is paired to the scooter • The GOVECS FLEX 2�0 is fitted with a sensor that prevents riding the scooter when the side stand is unfolded�...
  • Page 10 MIRRORS AUTOMATIC STEERING LOCK & ALARM IMPORTANT NOTICE Adjust both mirrors before each ride� Do not ride a scooter with damaged or inproperly adjusted mirrors! This scooter is originally equipped with two mirrors in order to guarantee This scooter is fitted with an automatic steering lock and an alarm (see image below) that prevents full rear visibility to the driver�...
  • Page 11 "click" sound is heard� To remove it, turn anti-clock wise and pull� use of the scooter! • Always charge the battery according to GOVECS • Place the scooter on an even ground and unfold the side instructions�...
  • Page 12 CHARGING THE BATTERY CHARGING THE BATTERY OFF-BOARD CHARGING The following points have to be followed when charging: The docking station provides the possibility of charging one battery outside the scooter� • The cable of the charger can be passed through the groove in the top plastic (see bottom pictures)�...
  • Page 13 CHARGING THE BATTERY LIGHTS In the following table the charging logic of the LEDs is explained� The scooter is equipped with the following lights: LEDs FRONT SOC (%) 0-10 Blink • Daylight running light The energy saving LED diodes do not need 10-20 Blink •...
  • Page 14 • Check if brake discs thickness is above 2 mm • Check free operation of brake levers� Adjust and lubricate when required� This GOVECS scooter is equipped with tubeless tires: • Front tire: MITAS C02 2 ¾ -16 44P • Rear tire: MITAS C09 90/90-16 48P...
  • Page 15 • Remove the detergent with cold water and dry all surfaces� STORAGE GOVECS is not responsible for any damage resulting from the use • Store the vehicle indoors where it is safe from harsh weather of pressurizing water for cleaning the vehicle�...
  • Page 16 The vehicle must undergo a regular inspection every 3100 miles or every 12 months (whichever comes first)� The vehicle must also be inspected after driving the first 310 miles� inspected after driving the first 310 miles� GOVECS FLEX RECOMMENDED MAINTENANCE SCHEDULE FOR B2B SCOOTERS GOVECS FLEX RECOMMENDED MAINTENANCE SCHEDULE FOR B2C SCOOTERS Mileage x 1000 mi...
  • Page 17: Reporting Safety Defects

    Tire size & type Front: 2¾ R16 , Rear: 90/90 R16 | 16“ Tubeless from Mitas However, NHTSA cannot become involved in any individual problems between you, your dealer, or GOVECS AG� Braking system Hydraulic disc brakes Max.
  • Page 18 TECHNICAL INSPECTION / TECHNISCHE INSPEKTION / CONTRÔLE TECHNIQUE / TECHNISCHE INSPECTIES TECHNICAL INSPECTION / TECHNISCHE INSPEKTION / CONTRÔLE TECHNIQUE / TECHNISCHE INSPECTIES VIN / FIN / NIV / FRAMENUMMER :________________________________________________ Inspection * Mileage Date Next Inspection Signature Stamp Inspektion Kilometerstand Datum Nächste Inspektion Unterschrift...
  • Page 19 TECHNICAL INSPECTION / TECHNISCHE INSPEKTION / CONTRÔLE TECHNIQUE / TECHNISCHE INSPECTIES TECHNICAL INSPECTION / TECHNISCHE INSPEKTION / CONTRÔLE TECHNIQUE / TECHNISCHE INSPECTIES Inspection * Mileage Date Next Inspection Signature Stamp Inspection * Mileage Date Next Inspection Signature Stamp Inspektion Kilometerstand Datum Nächste Inspektion Unterschrift...
  • Page 20 TECHNICAL INSPECTION / TECHNISCHE INSPEKTION / CONTRÔLE TECHNIQUE / TECHNISCHE INSPECTIES TECHNICAL INSPECTION / TECHNISCHE INSPEKTION / CONTRÔLE TECHNIQUE / TECHNISCHE INSPECTIES Inspection * Mileage Date Next Inspection Signature Stamp Inspection * Mileage Date Next Inspection Signature Stamp Inspektion Kilometerstand Datum Nächste Inspektion Unterschrift...
  • Page 21 TECHNICAL INSPECTION / TECHNISCHE INSPEKTION / CONTRÔLE TECHNIQUE / TECHNISCHE INSPECTIES Inspection * Mileage Date Next Inspection Signature Stamp Inspektion Kilometerstand Datum Nächste Inspektion Unterschrift Stempel Contrôle Kilométrage Date Contrôle suivante Signature Cachet Inspectie Kilometerstand Datum Volgende inspectie Handtekening Stempel...
  • Page 22 GOVECS AG Bavariafilmplatz 7, Geb� 3a Service Hotline: +49 800 788 788 30 82031 Grünwald service@govecs�com Germany www�govecsgroup�com I Online-Shop: www�govecs-scooter�com...
