Summary of Contents for EVS Synapse UDR108
- Page 1 INSTALLATION AND OPERATION MANUAL Synapse UDR108 UHD, FHD, HD and SD distribution amplifier with 8 reclocked outputs (single wire 12Gb/s SDI) Version 1.00 | September 2023...
- Page 3 In particular, EVS makes no warranty regarding the use or the consequences of use of this manual and the information contained herein. Furthermore, EVS may not be held liable for any direct or indirect,...
-
Page 4: General Information
NEVER bypass any fuse. NEVER replace any fuse with a value or type other than those specified. NEVER attempt to repair this product. If a problem occurs, contact your local EVS distributor. NEVER expose this product to extremely high or low temperatures. -
Page 5: Table Of Contents
2. Unpacking and Placement 3. The UDR108 Card 4. Settings Menu 4.1. Introduction 4.2. System Settings 5. Status Menu 5.1. Introduction 5.2. Status Items 6. Events Menu 7. LED Indication 8. Block Schematic 9. Connector Panels ICONOGRAPHY Warning Note Synapse UDR108 | Contents |... -
Page 7: What's New
INSTALLATION AND OPERATION MANUAL What's New? In the Installation and Operation Manual the icon has been added on the left margin to highlight information on updated features. Synapse UDR108 | What's New? |... -
Page 9: Introduction
High density, intuitive operation and high-quality processing are key features of the system. Synapse offers a full range of converters and processing modules. Please visit the EVS website at www.evs.com for the information on our new products and the latest updates. -
Page 10: Unpacking And Placement
2. Unpacking and Placement Unpacking The EVS Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. -
Page 11: The Udr108 Card
HD SDI 1485 Mbit/s (SMPTE 292M) • 3Gb/s SDI 2970 Mbit/s (SMPTE 424M) • Ultra HD 12 Gb/s (SMPTE 2082-1) • MADI • ASI/DVB Applications The UDR108 can be used as a single channel generic wideband 12 Gb/s distribution amplifier. Synapse UDR108 | 3. The UDR108 Card |... - Page 12 Block Schematic 4 | September 2023 | Issue 1.00.F...
-
Page 13: Settings Menu
Allows to enable or bypass the regeneration of the timing of input signal A at the output. By default, this feature is set to On. Mute_A Allows to mute the video outputs. By default, this feature is set to Off. Synapse UDR108 | 4. Settings Menu |... -
Page 14: Status Menu
5. Status Menu 5.1. Introduction The Status menu provides information about the current status of each item listed below. There are no defaults for status indicators. The status depends on the presence of the input signals. 5.2. Status Items Item Description SDI-Input_A This status item indicates the presence of a valid SDI signal on the input. -
Page 15: Events Menu
A slot number of the source of this event. Message String The message string is defined in the card and is therefore fixed. It may be used in controlling software like Synapse Set-up to show the event. Synapse UDR108 | 6. Events Menu |... - Page 16 Tags The tag is also defined in the card. The tag has a fixed meaning. When controlling or monitoring software has to make decisions based on events, it is easier to use the tag instead of interpreting a string. The first implementation is the tag-controlled switch in the GPI16.
-
Page 17: Led Indication
This LED indicates the presence of a valid SDI video signal on input A. Connection LED This LED lights up after the card has initialized. The LED lights up for 0.5 seconds every time a connection is made to the card. Synapse UDR108 | 7. LED Indication |... -
Page 18: Block Schematic
Block Schematic 10 | September 2023 | Issue 1.00.F... -
Page 19: Connector Panels
INSTALLATION AND OPERATION MANUAL Connector Panels The UDR108 can be used with the BPU03 connector panel. Synapse UDR108 | 9. Connector Panels |...
