- Page 1 INSTALLATION AND CONFIGURATION MANUAL CDV07 ANALOG VIDEO DISTRIBUTION AMPLIFIER(S)
- Page 2 (for manuals on hardware products) or on the EVS website on the following page: http://www.evs.com/contacts. User Manuals on EVS Website The latest version of Media Infrastructure manuals are available at: https://mi-sftp.evs.com/ The user manuals for other EVS products can be found at the EVS download center, on the following webpage: https://www.evs.com/en/download-area.
- Page 3 ● NEVER operate this product in an explosive atmosphere. Warranty: EVS warrants their products according to the warranty policy as described in the general terms. That means that EVS Broadcast Equipment SA can only warrant the products as long as the serial numbers are not removed.
-
Page 4: Table Of Contents
'INSTALLATION AND CONFIGURATION MANUAL CDV07 Introduction to Synapse An Introduction to Synapse Local Control Panel Remote Control Capabilities Unpacking and Placement Unpacking Locating the card A Quick Start When Powering-up Default settings ... - Page 5 EVS Broadcast Equipment SA Input What information is available in an event? The Message String The Tag Defining Tags The Priority The Address LED Indication POWER LED INPUT LED Block Schematic ...
-
Page 6: Introduction To Synapse
Synapse is a modular system designed for the broadcast industry. Synapse High density, intuitive operation and high quality processing are key features of this system. Synapse offers a full range of converters and processing modules. Please visit the EVS Broadcast Equipment SA Website at http://www.evs.com to obtain the latest information on our new products and updates. -
Page 7: Unpacking And Placement
EVS Broadcast Equipment SA 2 Unpacking and Placement Unpacking The EVS Synapse card must be unpacked in an anti-static environment. Care must be taken to NOT to touch component on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. -
Page 8: A Quick Start
'INSTALLATION AND CONFIGURATION MANUAL CDV07 3 A Quick Start When Powering-up On powering up the Synapse frame, the card set will receive basic data and default initialisation settings. All LEDs will light during this process. After initialisation, several LEDs will remain lit – the exact number and configuration is dependant upon the number of inputs connected and the status of the inputs. -
Page 9: Example Of Changing Parameters Using Front Panel Control
EVS Broadcast Equipment SA Example of With the display as shown below changing parameters using RRC18 [Select Card] front panel control >S01=SFS10 Pressing the ► selects the SFS10 in frame slot 01. The display changes to indicate that the SFS10 has been selected. -
Page 10: Synapse Setup Software
'INSTALLATION AND CONFIGURATION MANUAL CDV07 Synapse SetUp Software can be used to change the settings of Synapse SetUp Synapse modules from a PC, either locally or remotely. The Software software enables communication based on TCP/IP between the setup PC and Synapse frames/modules. Each Synapse frame is addressed through its rack controller’s unique IP address, giving access to each module, its menus and adjustment items. -
Page 11: The Cdv07 Card
EVS Broadcast Equipment SA 4 The CDV07 Card Introduction The EVS CDV07 is distribution amplifiers providing a low loss electronically balanced input with loop through or terminate connector. If necessary the input can be used truly floating. Back planes The CDV07 can be used with a BPL01 or BPL07 back plane. If the BPL01 is used then the CDV07 has eight outputs. -
Page 12: Settings Menu
'INSTALLATION AND CONFIGURATION MANUAL CDV07 5 Settings Menu Introduction The settings menu displays the current state of each setting within the CDV07 and enables the item to be changed or adjusted. Settings can be changed using the front panel of the Synapse frame (SFR18 or SFR04) or Synapse SetUp software. -
Page 13: Status Menu
EVS Broadcast Equipment SA 6 Status Menu Introduction The status menu indicates the current status of each item listed below Input This status item indicates whether an analogue video signal is present at the input. The status can be Present if a video signal... -
Page 14: Events Menu
'INSTALLATION AND CONFIGURATION MANUAL CDV07 7 Events Menu Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message What is the Goal? The goal of events is to inform the environment about a changing condition on the card. -
Page 15: The Tag
EVS Broadcast Equipment SA The Tag The tag is also defined in the card. The tag has a fixed meaning. When controlling or monitoring software should make decisions based on events, it is easier to use the tag instead of interpreting a string. -
Page 16: Led Indication
'INSTALLATION AND CONFIGURATION MANUAL CDV07 8 LED Indication POWER LED The power LED indicates the presence of power on the CDV07. INPUT LED This LED indicated the presence of a valid analog video signal on the input. -
Page 17: Block Schematic
EVS Broadcast Equipment SA 9 Block Schematic CDV07 ANALOG VIDEO 1 NOT with BPL07 ANALOG VIDEO 2 ANALOG VIDEO 3 ANALOG VIDEO IN DC COUPLED ATTENUATION ANALOG VIDEO 4 LOOP (BPL07 only) GAIN ANALOG VIDEO 5 ANALOG VIDEO 6 ANALOG VIDEO 7 ANALOG VIDEO 8 µP... -
Page 18: Connector Panel
'INSTALLATION AND CONFIGURATION MANUAL CDV07 10 Connector Panel The CDV07 can be used with the following backplanes: BPL01, BPL07. !Unused inputs and outputs must be terminated with the correct impedance! BPL01 BPL07 ANALOG VIDEO INPUT ANALOG VIDEO OUTPUT 1 (OR LOOP WITH BPL07) ANALOG VIDEO OUTPUT 2 ANALOG VIDEO OUTPUT 3 ANALOG VIDEO OUTPUT 4...
