- Page 1 INSTALLATION & CONFIGURATION MANUAL GDR416 4K, 3GB/S, HD AND SD FOUR INPUT DISTRIBUTION AMPLIFIER WITH 4 RECLOCKED OUTPUTS PER CHANNEL...
- Page 2 (for manuals on hardware products) or on the EVS website on the following page: http://www.evs.com/contacts. User Manuals on EVS Website The latest version of Media Infrastructure manuals are available at: https://mi-sftp.evs.com/ The user manuals for other EVS products can be found at the EVS download center, on the following webpage: https://www.evs.com/en/download-area.
- Page 3 ● NEVER operate this product in an explosive atmosphere. Warranty: EVS warrants their products according to the warranty policy as described in the general terms. That means that EVS Broadcast Equipment SA can only warrant the products as long as the serial numbers are not removed.
-
Page 4: Table Of Contents
A Quick Start When Powering-up Changing settings and parameters Front Panel Control Example of changing parameters using front panel control EVS Cortex Software Menu Structure Example The GDR416 Card Introduction Features ... - Page 5 EVS Broadcast Equipment SA Port1/2-Bias Port1/2-Bias-Stat Port1/2-Wavelength SFP2-Temp-Stat SFP2-Volt-Stat Port3/4-Enabled Port3/4-Power Port3/4-Pow-Stat Port3/4-Bias Port3/4-Bias-Stat Port3/4-Wavelength Events Menu Introduction What is the Goal of an event? ...
-
Page 6: Introduction To Synapse
MORE SYNAPSE FRAMES Although not required to use Cortex with a Synapse frame, you are strongly advised to use a remote personal computer or laptop PC with EVS Cortex installed, as this increases the ease of use and understanding of the modules. -
Page 7: Unpacking And Placement
EVS Broadcast Equipment SA 2 Unpacking and Placement Unpacking The EVS Synapse card must be unpacked in an anti-static environment. Care must be taken NOT to touch components on the card – always handle the card carefully by the edges. The card must be stored and shipped in anti-static packaging. -
Page 8: A Quick Start
Changing settings The front panel controls or the EVS Cortex can be used to change and parameters settings. An overview of the settings can be found in chapter 5, 6 and 7 of this manual. -
Page 9: Example Of Changing Parameters Using Front Panel Control
EVS Broadcast Equipment SA Example of With the display as shown below changing parameters using front panel control RRC18 [Select Card] >S01=SFS10 Pressing the ► selects the SFS10 in frame slot 01. The display changes to indicate that the SFS10 has been selected. In this example the Settings menu item is indicated. -
Page 10: Evs Cortex Software
INSTALLATION AND CONFIGURATION MANUAL GDR416 EVS Cortex can be used to change the settings of Synapse modules EVS Cortex from a PC, either locally or remotely. The software enables Software communication based on TCP/IP between the Setup PC and Synapse frames/modules. -
Page 11: The Gdr416 Card
EVS Broadcast Equipment SA 4 The GDR416 Card Introduction The GDR416 is a four channel 3Gb/s, HD, SD SDI reclocking distribution amplifier. Having four inputs, with each input having 4 outputs, makes this card the ideal 4K DA. Quad channel DA with 16 outputs ... -
Page 12: Settings Menu
INSTALLATION AND CONFIGURATION MANUAL GDR416 5 Settings Menu Introduction The settings menu displays the current state of each GDR416 setting and allows you to change or adjust it. Settings can be changed using the front panel of the Synapse frame (SFR18, SFR08 or SFR04) or with Cortex. -
Page 13: Pll_Set_B
EVS Broadcast Equipment SA PLL_set_B The GDR416 is capable of re-clocking a range of 3Gbit/s, HD and SD SDI transport stream bitrates. PLL_Set_B is used to set input B of the GDR416 to the correct bitrate of the incoming signal. -
Page 14: Reclocker_D
INSTALLATION AND CONFIGURATION MANUAL GDR416 Reclocker_D The setting item Reclock_D determines if the incoming signal on input D will be reclocked by the GDR416. The settings are: Auto: Auto selection between Bypass and Reclocked. ■ Bypass: Does not re-clock the incoming signal ■... -
Page 15: Note
EVS Broadcast Equipment SA Note: If PLL_Set_# is set to 1485 or 2970 Mb/s it is possible that a properly applied 270Mb/s signal (with a high signal strength and low jitter) will pass through. However we do not advice to use this situation because it could sometimes “miss-clock”. -
Page 16: Status Menu
INSTALLATION AND CONFIGURATION MANUAL GDR416 6 Status Menu Introduction The status menu indicates the current status of each item listed below. There are no defaults for status indicators. Status depends of input signals being present or not. SDI-Input_A This status item indicates the presence of a valid SDI signal on input A. -
Page 17: Sfp1-Type
EVS Broadcast Equipment SA SFP1-Type This status item displays the type name/number SFP I/O module A. SFP2-Vendor This status item displays the name of the SFP I/O module B. SFP2-Type This status item displays the type name/number SFP I/O module B. -
Page 18: Sfp2-Volt-Stat
INSTALLATION AND CONFIGURATION MANUAL GDR416 case Temperature monitoring is not available or the module is not inserted. SFP2-Volt-Stat These indicate whether the voltage usage of SFP input/output module B is Too_High, High, OK, Low or Too_Low. Can also be NA in case Voltage monitoring is not available or the module is not inserted. -
Page 19: Events Menu
EVS Broadcast Equipment SA 7 Events Menu Introduction An event is a special message that is generated on the card asynchronously. This means that it is not the response to a request to the card, but a spontaneous message. What is the Goal of... -
Page 20: The Tag
INSTALLATION AND CONFIGURATION MANUAL GDR416 The Tag The tag is also defined in the card. The tag has a fixed meaning. When controlling or monitoring software should make decisions based on events, it is easier to use the tag instead of interpreting a string. The first implementation is the tag controlled switch in the GPI16. -
Page 21: Led Indication
EVS Broadcast Equipment SA 8 LED Indication Input A LED This LED indicated the presence of a valid video signal on input A. Input B LED This LED indicated the presence of a valid video signal on input B. Input C LED This LED indicated the presence of a valid video signal on input C. -
Page 22: Block Schematic
INSTALLATION AND CONFIGURATION MANUAL GDR416 9 Block Schematic GDR416 GDR26 RECLOCKER WITH BYPASS RECLOCKER WITH BYPASS RECLOCKER WITH BYPASS RECLOCKER WITH BYPASS RACK CONTROLLER INTERNAL SYNAPSE BUS... -
Page 23: 10 Connector Panels
EVS Broadcast Equipment SA 10 Connector Panels The GDR416 can be used with the BPH43, BHX43, BPH48-T and BPH48R. Unused inputs and outputs must be terminated with the correct impedance! If the outputs are not correctly terminated, the resulting eye patterns and cable lengths will be seriously decreased.
