User Guide
English
Eden260
3-D Printer System

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Eden260 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Objet Eden260

  • Page 1 User Guide English Eden260 3-D Printer System...
  • Page 3 Copyright Copyright © 2007 Objet Geometries Ltd. All rights reserved.  This documentation contains proprietary information of Objet Geometries Ltd. This information is  supplied solely to assist authorized users of the Eden 3‐D printing system. No part of this document  may be used for other purposes, and it may not be disclosed to other parties.  The specifications on which this document is based are subject to change without notice. No part of this book may be reproduced in any form or by any means, nor stored in a database or  retrieval system, without prior permission in writing from Objet Geometries Ltd. If this document is distributed as a PDF file, you may print it for internal use. Trademarks The following are registered trademarks of Objet Geometries Ltd.: Objet®, Fullcure®. The following are trademarks of Objet Geometries Ltd.: Eden, Eden500V, Eden350V, Eden350,  Eden330, Eden260, Eden250, PolyJet, PolyLog, Objet Studio, Job Manager, TangoBlack, TangoGray,  VeroBlue, VeroWhite, VeroBlack. Microsoft and Microsoft XP are trademarks of Microsoft Corporation. All names of products and services cited in this book are trademarks or registered trademarks of their  respective companies.  FCC Compliance The Eden systems referred to in this guide have been tested and found to comply with the limits for a  Class A device pursuant to part 15 of the FCC rules. These limits provide reasonable protection  against harmful interference when the equipment is operated in a commercial environment. The Eden  system generates, uses and can radiate radio frequency energy. If not installed and used in accordance  with instructions in the User Guide, the system may cause harmful interference to radio  communications.  Operation of Eden 3‐D printing systems in residential areas may cause unacceptable interference to  radio and TV reception, requiring the operator to take whatever steps are necessary to correct the  interference. Equipment Recycling In the European Union, this symbol indicates that when the last user wishes to discard a product, it  must be sent to appropriate facilities for recovery and recycling. For information about proper  disposal, check your purchase contract, or contact the supplier of the equipment. Limitation of Liability The product, software or services are being provided on an “as is” and “as available” basis. Except as  may be stated specifically in your contract, Objet Geometries Ltd. expressly disclaims all warranties of  any kind, whether express or implied, including, but not limited to, any implied warranties of  merchantability, fitness for a particular purpose and non‐infringement.
  • Page 4 Patents This product is covered by one or more of the following U.S. patents: 4,961,154 5,263,130 5,287,435 5,386,500 5,519,816 5,695,708 6,259,962 6,569,373 6,644,763 6,658,314 6,850,334 6,863,859 7,183,335 7,209,797 7,225,045 Objet Geometries Ltd.  http://www.2objet.com DOC‐00260 Rev. A1 May 2007 DOC-00260 Rev. A1...
  • Page 5: Table Of Contents

    Light ..............................3–4 Safety Considerations......................... 3–4 Disposal ..............................3–4 Work Environment ..........................3–5 Workstation Requirements ......................3–5 Preparing Files for Use with Eden 3‐D Printing Systems ............3–5 Converting CAD Files to STL Format....................3–5 Converting Files to SLC Format ....................... 3–6 Objet Software ............................ 3–6 4 Installing Objet Software How to Install Software for the Eden 3‐D Printing System............4–2 5 Using Objet Studio Opening Objet Studio........................5–2 Preparing Models for Production....................5–3 Arranging the Objet Studio Screen ....................5–4 Placing Duplicate Objects on the Build Tray ................. 5–6 Selecting Objects..........................
  • Page 6 User Alerts ............................6–5 Server Job Manager..........................6–6 Job Manager Screen..........................6–6 Job Manager Operations........................6–8 Making changes to a Job........................6–9 User Alerts ............................6–10 Sending the Tray to the 3‐D printer for Production ..............6–11 7 Operating & Maintaining the Eden 3‐D Printer Starting the Eden260 3‐D Printer ..................... 7–2 Loading Model and Support Cartridges ..................7–3 Producing Models ..........................7–4 Printing Indicators..........................7–6 Resuming Production After Printing has Stopped ............... 7–6 Changing the Model Material ......................7–8 Keeping the Eden 3‐D Printer in Idle Mode................. 7–12 Shutting Down the Eden 3‐D Printer .................... 7–12 DOC-00260 Rev. A1...
  • Page 7 User Guide Maintaining the Eden 3‐D Printer ....................7–14 Routine Maintenance Schedule....................... 7–14 Cleaning the Printing Heads ......................7–14 Pattern Test ............................7–17 Improving Print Quality ........................7–17 Cleaning and Replacing the Wiper ....................7–18 Aligning the Printing Heads ......................7–20 Replacing Printing Heads........................ 7–25 Replacing the UV Lamps ......................... 7–35 Replacing the Waste Container....................... 7–39 8 Handling Printed Models Cooling Models After Printing ......................8–2 Removing the Support Material ...................... 8–2 Storing Models ........................... 8–3 A Printer Elements DOC-00260 Rev.
  • Page 9: About This Guide

    About This Guide Using This Guide..................2 For More Information ..................2 Terms Used in This Guide................3 1–1 DOC-00260 Rev. A1...
  • Page 10: Using This Guide

    About This Guide Using This Guide This user guide provides instructions for installing, operating and  maintaining Eden260 3‐D printing systems. It explains how to use features,  and provides practical examples to guide you as you use the system. The text and figures in this guide are based on Eden260 version 26.0.0.2 and  Objet Studio version 8.0.1.3. This guide assumes that: • all the hardware, software, and network components of your Eden  system are installed, configured, and operating correctly. ® • the operator has a working knowledge of the Windows  PC platform. For More Information Visit http://www.2objet.com/ for more details about Objet’s technology,  products and consumables, and for service and support contacts. For other documents that relate to Eden260 3‐D printing systems, and for  this document in other languages, contact your regional Objet Customer  Support office. If you have any questions about the information presented in this  document, or if you have any comments or suggestions for future editions,  please send a message to support@2objet.com. 1–2 DOC-00260 Rev. A1...
  • Page 11: Terms Used In This Guide

    Eden260 User Guide Terms Used in This Guide Eden printer The Eden260 3‐D printer referred to in this guide. resin The base substance from which photopolymer materials are  made for use in Eden printers. In Objet and Eden software,  “resin” refers to cartridges of model and support materials. model material Material used for building models. support material Material used for supporting the structure of models during  production. The file type used with Objet software. (For more  information, see page 3‐3.) The file type used with Objet software. (These files are  bitmaps of individual slices of the object. For more  information, see page 3‐3.) OTF (Objet Tray Format) The file type containing all of the information needed for a  model‐building job on Objet 3‐D printers. host/server workstation The workstation on which the full version of Job Manager is  installed. This workstation interfaces directly with the Eden  printer and is typically positioned next to it. client/user workstation The workstation on which Objet software is installed, used  for preparing build trays for production on Eden printers.  (There is no limit to the number of client workstations in the  local network.) Eden computer The computer inside the Eden printer that operates it. (This is ...
  • Page 13: Safety

    Safety Safety Features....................2 Symbols and Warnings................3 Safety Guidelines..................4 First Aid for Working With Resins ............6 Waste Disposal....................7 2–1 DOC-00260 Rev. A1...
  • Page 14: Safety Features

    Safety Safety Features Eden260 3‐D printers are designed and manufactured to comply with CE  and FCC standards. It is equipped with the following safety features: Cover lock The cover is locked while the printer is  working. It is released when the printer reverts  to pause or stop mode. WARNING: Do not defeat the safety lock.  Doing so could result in serious personal  injury. If the safety lock does not function  correctly, contact your service provider. Cover interlock  The internal AC power supply (to the UV lamp,  switch motion motors and the tray heater) is turned off  when the cover is opened. WARNING: Do not defeat the interlock  switch. Doing so could result in serious  personal injury. If the interlock does not  function correctly, contact your service  provider. UV screen  The transparent section of the cover blocks  harmful UV radiation, allowing the operator to  view the model as it is being made. Circuit breaker The main power supply is turned off by an  internal switch in case of an electrical  malfunction. Grounded chassis The frame and chassis of the printer are  grounded to prevent electrical shock. If the Eden system is not used as specified in this guide, the safety features may not provide adequate protection.
  • Page 15: Symbols And Warnings

    Eden260 User Guide Symbols and Warnings This following table lists the warning labels located on or in Eden printers. Warning Meaning Location Comments Symbol Hazard (general) The main label on  Caution. the back of the  printer. Hot surface  Near head block. Risk of burns. Do  not touch this  surface when hot. High voltage  Near UV lamp  Risk of electric  connectors, on  shock. the rear, left and  right covers of  the UV enclosure. Ultra Violet  Near UV lamp Risk of injury from  radiation ultraviolet radiation.  Always use  protective eyewear  during operation. Moving parts Near tray Risk of injury from ...
  • Page 16: Safety Guidelines

    Safety Safety Guidelines The following general guidelines, together with the instructions provided  throughout this user guide, ensure user safety while operating and  maintaining the Eden260 system. If the system is not operated as specified,  the userʹs safety may be compromised. Eden Printer Installation and removal of the Eden printer should only be done by  qualified service personnel.  The Eden printer should only be operated by persons trained by an  Objet customer‐support representative. Service operations should be performed only by personnel who have  been instructed in relevant safety precautions. All personnel operating or maintaining the Eden printer should know  the location of first aid and emergency equipment and how to use it.  Never block access to this equipment. Never attempt to open the main cover of the printer while it is working.  Never bypass the interlock safety switch. If the interlock safety switch ever fails, or if servicing is ever necessary  while the main cover is open, never stare directly at the UV lamp  without glasses that screen out UV radiation. For this purpose,  ordinary sunglasses with UV screening are adequate. Never connect the power plug to a socket that does not have a ground  (earth) wire, and never disconnect the ground. Doing so may expose  the operator to serious danger from electric shock. The power cable should be connected at an easily accessible electric  socket near the printer. Never insert screwdrivers, wires, or other objects into the power supply  housing.  Leave a minimum of 15 centimeters between ventilation openings and  walls or other objects. Several parts of the printer remain extremely hot even after it has  stopped operating. Avoid touching the main power supply, the UV‐ lamp power supply, UV lamps, and the printing heads. Notify co‐workers and those who have access to the Eden system before  beginning non‐routine and hazardous work. Report any potential dangers and safety‐related accidents to your  safety officer or to other appropriate authorities.
  • Page 17: Model And Support Material

    Eden260 User Guide Model and Model and support materials are made of resins. Although precautions  Support must be taken when handling resins directly, all model and support  Material materials used by the Eden system are handled in sealed cartridges.  Normally, operators of the Eden printer should never be directly exposed  to dangerous materials. Most of the following recommendations for  handling resins apply to the unlikely event of a leak or spill. If this should  occur, follow the specific instructions printed on the resin cartridge used. Resins are flammable. Store cartridges of model and support materials  indoors, in a dry area with adequate ventilation, between 16‐27 degrees  Celsius (60‐81 degrees Fahrenheit). Never expose them to flames, heat  or sparks. Keep resins away from areas where food and drink are stored,  prepared and consumed. Uncured resin is toxic. Ensure that resin does not come in contact with  the eyes. If there is any chance that resin may splash into the eyes, wear  safety goggles. Minimize direct contact with the skin to prevent  irritation and other health hazards. Prolonged contact may cause burns. To prevent respiratory irritation, ventilate all areas where resins are  directly handled or exposed to the air. The ventilation system should  totally replace the air 20 times per hour. Clean resin spills with disposable towels or other absorbent, non‐ reusable material, such as sawdust or activated charcoal. Rinse the spill  area with denatured or isopropyl alcohol (IPA), followed by soap and  water. Dispose of the absorbent material in accordance with local  regulations. Do not wash contaminated clothing at home; clothing should be  professionally laundered. Dispose of contaminated shoes, belts and other leather items. Absorbed  resin may re‐expose the user when these items are worn again. 2–5 DOC-00260 Rev. A1...
  • Page 18: First Aid For Working With Resins

    Safety First Aid for Working With Resins In general, try to avoid direct contact with uncured resin. If skin or eyes  comes into contact with resin, wash the area immediately and thoroughly  with water, and follow the first‐aid instructions below. Contact with If uncured resin comes in contact with skin, wash the affected area  Skin immediately and thoroughly with soap and cool water, then remove  contaminated clothing. Pay particular attention to flushing the hair, ears,  nose and other parts of the body that are not easily cleaned.  Use cool water to prevent skin pores from opening, so that the resin  does not easily penetrate the skin.  Do not use solvents to clean skin.  If large areas of skin have been exposed to resin, or if prolonged contact  results in blisters, seek medical attention.  Avoid the accidental transfer of resin from the hands to other areas of  the body, especially to the eyes.  If protective cream was used, do not reapply it until the skin has been  completely cleansed. Contact with If uncured resin comes in contact with the eyes, flush immediately with  Eyes large amounts of water for 15 minutes and seek medical attention.  Avoid sunlight, fluorescent light, and other sources of ultraviolet  radiation. The wearing of contact lenses when working near resin is not  recommended. If resin splashes into the eyes when contact lenses are worn,  immediately remove the lenses and flush the eyes with water.  Clean and disinfect the contaminated lenses. Do not wear contact lenses until eye irritation disappears. Ingestion If resin is swallowed, refer to the cartridge label for specific instructions.  Seek medical attention immediately.
  • Page 19: Waste Disposal

    Eden260 User Guide Waste Disposal Fully cured resins present no special safety or health‐related issues.  However, check if local regulations regard cured and partially cured resins  as hazardous industrial waste, and comply with all applicable regulations  governing their disposal. When removing the waste container from the Eden printer, protective  gloves are not required. When directly handling uncured resins,  neoprene or nitrile gloves are recommended.  When handling cured materials that may not be completely cured on  the surface, common latex gloves are adequate.  Even if not classified as hazardous industrial waste or otherwise  regulated, resin materials must be packaged and disposed of in a  manner that prevents human contact with the waste. Therefore, take  steps to prevent the contamination of both groundwater and surface  water. Empty resin cartridges are sealed to prevent leakage. Do not attempt to  reuse them, and do not puncture them. Discard contaminated clothing, shoes, empty containers, etc., in  accordance with any applicable laws and regulations. 2–7 DOC-00260 Rev. A1...
  • Page 21: Introducing The Eden 3-D Printing System

    Work Configurations ...................2 Source Files ....................3 STL Files ......................3 SLC Files ......................3 Resins  ......................4 Storage ......................4 Shelf Life ......................4 Light ......................... 4 Safety Considerations ..................4 Disposal ......................4 Work Environment..................5 Workstation Requirements  ................5 Preparing Files for Use with Eden 3‐D Printing Systems.......5 Converting CAD Files to STL Format ............5 Converting Files to SLC Format..............6 Objet Software....................6 3–1 DOC-00260 Rev. A1...
  • Page 22: Work Configurations

    Introducing the Eden 3-D Printing System Figure 3-1: The Eden260 3-D Printer Work Configurations The Eden260 3‐D printing system can be set up as a single‐station system or  as a multi‐station system. When connected to a local computer network, the  system can serve multiple users. In such configurations, each user  workstation (client) prepares files with Objet Studio software for  production. A server (host), typically next to the 3‐D printer, acts as a job  manager that sends production jobs to the printer for production.  Figure 3‐2 shows the Eden260 printer set up in a multi‐client configuration. Client workstations Eden server KVM switch Printer workstations Eden printer Figure 3-2: Multi-client network configuration 3–2 DOC-00260 Rev. A1...
  • Page 23: Source Files

    Eden260 User Guide When installing the Objet software, you choose whether to install it as a  client station or as a master station (server or standalone station). The Objet software arranges the jobs it receives according to their priorities,  resin type, and other factors. In multi‐workstation configurations, the  operator of the server—typically the production administrator—has total  control over the jobs sent to the 3‐D printer, and can prioritize and delete  jobs, review job history and reprint a job, and so on. Source Files Eden 3‐D printing systems produce three‐dimensional models designed  with most 3‐D CAD tools and with other job‐specific 3‐D applications.  Eden systems accept: • STL files • SLC files Eden systems feature the capability of producing both types of model files  simultaneously. STL Files STL is short for Standard Triangulation Language. This language views any  object as a collection of surfaces, and describes each surface of the object as  a collection of triangles.  For example, a square can be described as two triangles; a cube (six  squares) as 12 triangles. Curved surfaces need more triangles to describe  them. The higher the tolerance (for smooth surfaces), the more triangles are  needed. The result is that high‐quality object descriptions mean very heavy  files.  Most CAD software can export STL files. The Eden system utilizes these  files for building models (rapid prototyping), and also for directly making  molds for mass‐producing items. STL files are ASCII (text) files. The content of each file begins with “solid”  and ends with “end‐solid” (both lower case). Between these keywords is a  list of the triangles that describes the faces of the solid model. Each triangle  defines a single normal vector directed away from the solid’s surface,  followed by its X‐Y‐Z coordinates. These are expressed as Cartesian  coordinates and are floating‐point values. The coordinates of all triangles ...
  • Page 24: Resins

    Introducing the Eden 3-D Printing System Resins Model and support materials used for producing models with Eden  printers are made of resins, which are composed of reactive monomers and  oligomers. Care must be taken when storing and handling them, both to  protect operators and the environment, and to ensure their effectiveness.  Signs of premature polymerization in the resin cartridge include bulging,  leaking, the emission of heat, and unusual odor. Exposure to heat can cause  resin to gel in the cartridge. To prevent this, observe the following  guidelines when handling and storing Eden modeling and support  materials. Storage Resins used with Eden systems are supplied in UV‐proof cartridges.  • To ensure product stability, do not allow resins to come into contact  with metal. Plastics made from monomer‐soluble materials (such as  polystyrene or polyvinyl chloride) are not suitable for storing resins. • When not in use, keep resin cartridges tightly sealed to prevent  contamination, the effects of exposure to UV radiation, and accidental  spillage.  • Store cartridges of resins indoors, in a dry area with adequate  ventilation, between 16–27 degrees Celsius (60–81 degrees Fahrenheit).  If exposed to heat or flames, cartridges may burst or ignite. • Make sure that resins are stored in accordance with all local regulations  and other applicable requirements. Shelf Life Eden resins have a limited shelf life. The expiry date on the label is valid  when properly stored in an undamaged, unopened cartridge. Always  rotate your stock of resin, so that the cartridge with the earliest date is used  first. Light When resin is not in its sealed cartridge, make sure to shield it from ...
  • Page 25: Work Environment

    Eden260 User Guide Work Environment Extreme heat and humidity conditions can adversely affect the operation of  the Eden 3‐D printer. Therefore, it is recommended that you use ventilation  or air‐conditioning systems, if necessary, to keep the work area within the  following ranges: • 18°–25° C (64°–77° F) • 30%–70% relative humidity Workstation Requirements Server/ Client Workstation Stand-alone Station Processor Pentium 4, 3.0 GHz (min.) Pentium 4, 3.0 GHz (min.) Operating System Microsoft Windows XP or  Microsoft Windows XP or  Windows 2000 Windows 2000 Graphics Card Supporting open GL,  Supporting open GL,  with 256 MB of memory with 256 MB of memory 2 GB (min.) 1 GB (min.) CD Drive IDE CD ROM IDE CD ROM...
  • Page 26: Converting Files To Slc Format

    4. In the file format option, choose binary or ASCII. (Binary files are  smaller than files saved in ASCII format; they are, however,  functionally identical in Objet Studio.) Save 5. Click   or  Converting When converting files to SLC format, it is recommended that you set a layer  Files to SLC thickness of 15 microns (0.015 mm). Since SLC files cannot be orientated in  Format Objet Studio, it is important that models are properly orientated before  being saved as SLC files. Considerations for suitable model orientation are  explained in “Model Orientation” on page 5‐9. Objet Software Objet software for the Eden 3‐D printing system consists of two  applications: • Objet Studio • Job Manager Objet Studio With Objet Studio, you prepare source files for production in Eden 3‐D  printers. Objet Studio offers you a wide variety of file‐preparation options,  but always consists of the following basic procedure: 1. Inserting one or more objects on the build tray 2. Positioning the object(s) on the tray 3. Configuring object and tray parameters 4. Saving the tray configuration as an otf (Objet Tray Format) file 5.
  • Page 27 Eden260 User Guide Using Job Manager is described in detail in chapter chapter 6, “Using Job  Manager. Client computers can be connected, via the local network, to different Eden 3-D printers, but only to one at a time. The client Job Manager displays the status of the 3-D printer to which the client is currently connected.
  • Page 29: Installing Objet Software

    Installing Objet Software How to Install Software for the Eden 3‐D Printing System ....2 4–1 DOC-00260 Rev. A1...
  • Page 30: How To Install Software For The Eden 3-D Printing System

    How to Install Software for the Eden 3-D Printing System The Objet Studio setup wizard guides you when installing the Objet  software. During installation, you must choose to install either the server  (“host”) application or the client application.  To install Objet software: 1. Insert the Objet Studio CD into the disk drive. Start Explore 2. Right‐click the   button and select   (or use any other method  for displaying files on the computer). Setup 3. Open the CD‐drive folder and select  Figure 4-1:Objet Setup—installation wizard Welcome screen Next 4. When the Welcome screen appears, click  Figure 4-2: Objet Setup—Select Components screen 4–2 DOC-00260 Rev. A1...
  • Page 31 • Objet Studio and Job Manager Select   for the server (host) station and  for a standalone station—that is, the computer directly connected to  the Eden printer. Figure 4-3: Objet Setup—Choose Destination Location screen 6. In the Choose Destination Location screen, verify the destination folder  Next and click  .  It is recommended that you do not change the default destination folder. Figure 4-4: Objet Setup—Select Program Folder screen 4–3...
  • Page 32 Installing Objet Software 7. In the Select Program Folder screen, verify the pre‐selected folder in  which the Objet Studio icons will be installed.  • To install the icons in another program folder, select it.  • Next To continue, click  Figure 4-5: Objet Setup—Select Printer Type screen 8. In the Select Printer Type screen, select the Objet 3‐D printer used for  producing models.  Next To continue, click  Installation begins and the Setup Status screen appears, showing the  progress of the installation process. Figure 4-6: Objet Setup—Setup Status screen 4–4 DOC-00260 Rev. A1...
  • Page 33 Eden260 User Guide When the Objet program installation is complete, the final InstallShield  Wizard screen appears. Figure 4-7: Objet Setup—final wizard screen 9. To complete installation, you must restart the computer. To do so,  Finish remove the CD from the disk drive, select “Yes…” and click  The computer shuts down and restarts, and the software installs the  appropriate icon(s) on the computer desktop:  • Objet Studio • Job Manager (for servers and standalone stations) • Stop Job Manager (for servers and standalone stations) 4–5 DOC-00260 Rev. A1...
  • Page 35: Using Objet Studio

    Using Objet Studio Opening Objet Studio ..................2 Preparing Models for Production ..............3 Arranging the Objet Studio Screen ............4 Selecting Objects..................... 6 Copying and Pasting Objects ............... 6 Placing Duplicate Objects on the Build Tray..........6 Positioning Objects on the Build Tray ............7 Automatic Positioning................... 7 Manual Positioning..................8 Model Orientation..................9 Selecting and Manipulating Objects on the Build Tray ......10 Selecting Objects................... 10 Object Position on the Z‐Axis ..............10 Repositioning Objects.................. 11 Valid Object Placement ................13 Grouping Objects ..................13 Using a Grid to Position Objects ..............14 Changing an Object’s Orientation.............. 15 Freezing an Object’s Orientation..............
  • Page 36: Opening Objet Studio

    Programs selecting Objet Studio from the   >   menu. Objet Studio opens, displaying an empty build tray. Figure 5-1: Objet Studio opening screen The icons shown in this chapter are available only when relevant toolbars  are displayed. You can control the toolbars displayed at any time, and you  can re‐arrange them on the screen. To customize the toolbars displayed in Objet Studio: Toolbars 1. From the View menu, select  2. In the Customize dialog box, select the toolbars you wish to display, and  click  Figure 5-2: Toolbar selection dialog box 3. Click and drag the toolbars to position them as you wish on the Objet  Studio screen. 5–2 DOC-00260 Rev. A1...
  • Page 37: Preparing Models For Production

    Eden260 User Guide Preparing Models for Production To produce models from model files, you must select one or more files and  position the models on the Objet Studio build tray. If you know what type  of modeling material will be used to produce the models, make sure it is  selected in the toolbar. Figure 5-3: Modeling material selection toolbar Note: It is not necessary to select the modeling material now, but it is recommended—each type of modeling material has unique characteristics that may affect the valid positioning of objects on the build tray.
  • Page 38: Arranging The Objet Studio Screen

    “bounding box” surrounding the object (see figure 5-24 on page 5-17). Open 6. Click  The dialog box closes and Objet Studio places the model(s) on the build  tray. You can place additional models on the build tray by repeating this  procedure. Arranging the Objet Studio Screen The default screen layout displays the perspective view of the build tray and  the tray hierarchy pane, which lists the elements placed on the tray. Figure 5-5: 2-view (default) screen layout You can view models from different angles by changing the default screen  layout. 5–4 DOC-00260 Rev. A1...
  • Page 39 Eden260 User Guide To change the Objet Studio screen layout: Layout From the View menu, select  , then the desired number of build‐ tray views. 2 Views  is the default screen layout, already displayed (see  figure 5‐5). By default, the Entity Properties dialog box is also displayed. 3 Views  adds top and front views to the default screen layout (see  figure 5‐7). 4 Views  displays top, front and right views (see figure 5‐8). 1 View  expands the perspective view to fill the screen (see figure 5‐9). You can also change the screen layout with toolbar icons. Figure 5-6: Screen layout icons Figure 5-7: 3-view screen layout Figure 5-8: 4-view screen layout 5–5...
  • Page 40: Placing Duplicate Objects On The Build Tray

    Using Objet Studio Figure 5-9: 1-view screen layout You can change the perspective of the active viewing pane by clicking any  of the nine viewing icons. Figure 5-10: Viewing-pane perspective icons Placing Duplicate Objects on the Build Tray In addition to initially placing multiple copies of the object on the build tray  from the Insert dialog box (figure 5‐4 or figure 5‐12), you can decide later to  duplicate objects on the tray. You can, of course, insert the same object from  its file more than once. An easier way, however, is to copy and paste the  object. Selecting You select an object by clicking it, either on the tray or in the tray hierarchy  Objects pane. Its image on the build tray changes color (to light blue) and its name  is highlighted in the tray hierarchy pane.  Copying and You access the Copy and Paste commands as in other Windows applications: Pasting • Edit by opening the ...
  • Page 41: Positioning Objects On The Build Tray

    Eden260 User Guide Figure 5-11: Paste Special dialog box Positioning Objects on the Build Tray To produce models efficiently and with the required finish, it is important  to carefully position objects on the build tray. Objet Studio features the  automatic positioning of objects. However, you should check to make sure  that the objects are orientated logically for your needs, according the  considerations explained in “Model Orientation” on page 5‐9. Automatic There are two ways to have Objet Studio position the items on the build  Positioning tray. • Arrange models Anytime you insert an object onto the build tray, select    in the Insert dialog box. Figure 5-12: Arrange models option in the Insert dialog box Open When you click ...
  • Page 42: Manual Positioning

    Using Objet Studio Figure 5-13: Tray before objects are properly arranged Figure 5-14: Tray after objects have been automatically arranged Because of the unique characteristics of each type of modeling material, it is recommended that you select the material before inserting objects on the tray with automatic positioning or running Automatic Placement.
  • Page 43: Model Orientation

    Eden260 User Guide Model Orientation The orientation of models on the build tray affects how quickly and  efficiently they will be produced by the 3‐D printer, where and how much  support material is used, and whether or not model parts will have a gloss  finish. Therefore, you should consider a variety of factors when deciding  how to place models on the tray, using the following positioning rules.  X-Y-Z Rule This rule considers a modelʹs outer dimensions. Since the printing heads move back and forth along the X‐axis, the  printing time along this axis is relatively short, compared to printing  time along the Y‐axis and Z‐axis. From this point of view, it is advisable  to place the objectʹs longest dimension along the X‐axis. Since high‐resolution models are built up, on the Z‐axis, in 16‐micron  layers, it is very time‐consuming to print a tall object. From this point of  view, it is advisable to place the objectʹs smallest dimension along the Z‐ axis. Since the printing heads measure about 2 inches (5 centimeters) on the  Y‐axis, models measuring less than this (on the Y‐axis) are printed in  one pass. From this point of view, it is advisable to place the objectʹs  intermediate dimension along the Y‐axis. Tall-Left Rule This rule considers models where, after being orientated on the build tray  according to other considerations, one side is taller than the other. Since the printing heads move along the X‐axis from left to right, taller  sections on the right require the printing heads to scan unnecessarily  from the left until reaching them. If, on the other hand, the taller  sections are positioned on the left of the tray, the printing heads only  have to scan the model until printing these sections—once the lower  parts have been completed. Therefore, you should position the taller  side of the model, when possible, on the left. The following rules are based on the fact that support material is not  required on the top of the printed model. Recess-Up Rule This rule considers models containing surface recesses.
  • Page 44: Selecting And Manipulating Objects On The Build Tray

    In practice, the Eden system prints all models on the build tray on a one- millimeter bed of support material. The importance of positioning objects directly on the build tray with Objet Studio is to correctly display the objects on the screen.
  • Page 45: Repositioning Objects

    After you manually manipulate an object with the mouse, its new  properties are displayed in the Transform tab of the Entities Properties dialog  box.  The Entities Properties dialog box is displayed by default (see figure 5-5 on page 5-4) and whenever the screen layout is changed or refreshed (see “Arranging the Objet Studio Screen” on page 5-4). 5–11 DOC-00260 Rev. A1...
  • Page 46 Figure 5-16: Entities Properties dialog box, Transform tab You can make precise changes to the object on the build tray by selecting  the object (either on the tray or in the tray hierarchy pane) and changing its  values in the dialog box. Note: You can only change the height of the objects on the build tray if this is allowed by the Objet Studio settings (see “Object Position on the Z-Axis” on page 5-10.) The properties displayed in the Transform tab of the Entities Properties dialog  box are absolute values, representing the actual position of the object on the  build tray. Another way of repositioning objects on the tray using precise ...
  • Page 47: Valid Object Placement

    Eden260 User Guide • The Relative Transform dialog box, accessible from the Object menu. Figure 5-18: Relative Transform dialog box Valid Object To ensure that models do not overlap when you position them on the build  Placement tray, you can select the Dynamic Checking icon   from the Tools toolbar.  When selected, Objet Studio only allows the positioning of objects if they  do not interfere with other objects on the tray. Note that the space occupied  by an object includes the “bounding box” surrounding it (see figure 5‐24 on  page 5‐17).  Note: Because of the unique characteristics of each type of modeling material, it is recommended that you select the material before precisely positioning objects on the tray.
  • Page 48: Using A Grid To Position Objects

    Using Objet Studio Using a Grid to Displaying a grid on the image of the build tray can be useful when  Position positioning objects. You can make use of this feature by clicking the grid  Objects toolbar icons or by selecting menu options.  Icon Menu Option Result Tools > Grid Displays a grid over all build tray views. Tools > Snap to grid When moving the object, it aligns with the  nearest grid line. Enables you to change the grid origin  (X‐ and Y‐axis meeting point) by clicking  on the build tray. Cancels the changes made to the grid  origin and restores the default grid. You can review and configure grid settings—and apply them—from the  Options dialog box. To use the Options dialog box: Options 1. From the Tools menu, select  , and display the Grid tab. Figure 5-20: Options dialog box, Grid tab, showing the default settings The dialog box displays the current grid settings.
  • Page 49: Changing An Object's Orientation

    Eden260 User Guide Changing an There are several methods for changing the orientation of objects on the  Object’s build tray. Orientation To rotate an object: Select the object and use the Rotate icon or Object menu options (see  “Repositioning Objects” on page 5‐11). To select an object’s plane and re-align it with one of six basic directions: • From the Plane Alignment toolbar: 1. Click the Select Plane icon  2. Click a plane on an object displayed on the build tray. 3. Click the appropriate align icon— Align Bottom Align Top Align Front...
  • Page 50: Display Options

    Using Objet Studio Freezing an If you manipulate an object on the build tray, you can freeze its orientation  Object’s so that it does not change when you perform Automatic Placement (see  Orientation “Automatic Positioning” on page 5‐7). To freeze an object’s orientation: 1. Select a model on the build tray. Advanced 2. In the Options tab of the Entity Properties dialog box, click  The Advanced Properties dialog box opens. Figure 5-21: Advanced Properties dialog box—”Lock Orientation” selected 3. Select the Lock Orientation check box. 4. Close the Advanced Properties dialog box. Display Options From the View menu, you can change the way objects are displayed on the  screen. The default method for displaying models on the build tray is as  solid (“shaded”) objects.  Figure 5-22: Tray and model displayed in shaded view The other display options are wire frame and points.
  • Page 51 Eden260 User Guide Figure 5-23: Tray and model displayed in Wire frame view To revert to the shaded view: View > Shaded Select   or click the Shaded icon  To display objects as boxes, showing their maximum dimensions instead of the model geometry: View > Display Bounding Box Select ...
  • Page 52: Tray Viewing Options

    Note: You can repeat this procedure for other objects, so that different objects on the build tray are displayed in different colors. Objet Studio displays objects to be produced with matte and glossy finishes in different colors. See “Surface Finish” on page 5-19 and “Object Color Codes”...
  • Page 53: Surface Finish

    Eden260 User Guide Icon Tool Tip Name Purpose Spin Mode When used with   and  , the movement of  the build tray continues after you release the  mouse button. To stop the movement, click in  the active view pane or click one of these icons. Zoom In Each mouse click zooms one step to the center  of the active viewing pane. Zoom Out Each mouse click zooms‐out one step from the  center of the active viewing pane. Pan Left Each mouse click moves the build tray to the  left in the viewing pane by one step. Pan Right Each mouse click moves the build tray to the  right in the active viewing pane by one step. Pan Up Each mouse click moves the build tray up in  the active viewing pane by one step. Pan Down Each mouse click moves the build tray down in  the active viewing pane by one step. Advance Forward The same as  . Each mouse click zooms in to  the tray displayed in the active viewing pane. Advance Backward The same as  . Each mouse click zooms out ...
  • Page 54: Handling Completed Trays

    Using Objet Studio To choose the finish type for a model: 1. Select the model. Matte 2. In the Options tab of the Entity Properties dialog box, select   or  Glossy or— 1. Right‐click the model on the build tray. At the bottom of the pop‐up menu, the current finish type is not  enabled (that is, you cannot select it). 2. To change the finish type, select the other (enabled) option. Note: To distinguish between models with different finishes, the color of objects displayed on the build tray—when they are not selected—is different for each type.
  • Page 55: Object Color Codes

    Eden260 User Guide Object Color To view the color code for objects displayed: Codes Constraints Settings From the Tools menu, select  Figure 5-27: Constraints Settings dialog box, showing object color codes To change the color settings: 1. Click the current color displayed in the Constraints Settings dialog box. 2. From the color palette that opens, select a color and click  Note: The color of objects already displayed does not change automatically.
  • Page 56: Printing The Tray File

    To send the tray to the production queue: Build Tray From the File menu, select  or— Click  The tray file is sent to Job Manager. Objet Studio closes and Job Manager  opens, so you can monitor the progress of your trays. Note: To return to Objet Studio, click the New Job icon Additional Objet Studio Features Dividing You can use the Split Object feature to produce objects larger than the build  Objects tray by dividing the model into separate parts. You can also use this feature  to produce only a specific section of a model. To split an object: 1.
  • Page 57: Choosing The Support Strength

    Eden260 User Guide The composite parts are saved as new stl files with “Part 1,” “Part 2,”  etc., added to the original file name. Note: Before printing the newly created stl files, it is recommended that you check them for defects in an STL-repair application, such as Magics, by Materialise. Choosing the When producing models, support material fills some hollow and empty  Support sections (see “Model Orientation” on page 5‐9). Objet Studio allows you to  Strength adjust the strength of the structure formed with the support material. This  adjustment is useful when producing either large/massive models or small/ delicate models. For most purposes, the default setting provides adequate ...
  • Page 58: Printing The Screen Display On Paper

    Using Objet Studio To display a cross section of the tray: Section 1. From the Tools menu, select  or— Click   on the toolbar. The Section dialog box opens. Figure 5-31: Section dialog box 2. Select the Enable Clicking check box. 3. Use the slider controls for the X‐, Y‐, and Z‐axes to cut the tray so that  you see the cross section you want. Figure 5-32: Whole view Figure 5-33: Cross-section view, after using the Z-slider Printing the You can print the view displayed in the active pane on a regular (paper) ...
  • Page 59: Exporting And Importing Objet Build Trays

    Eden260 User Guide Saving the You can save the image displayed in the active viewing screen as a graphic  Screen Display file. as an Image To save the screen display as an image: File Save Bitmap… 1. From the File menu, select  The Save Bitmap dialog box opens. Figure 5-34: Save Bitmap dialog box 2. At the top of the dialog box, select the appropriate folder. 3. At the bottom of the dialog box, enter a file name. 4. Open the Save as type pull‐down menu, and select the file format. Save 5. Click ...
  • Page 60: Advanced Features

    Using Objet Studio Advanced Features The Objet Studio features described in this section are only accessible if the  application is set to Advanced mode.  To see the current Objet Studio setting: Open the Tools menu. Figure 5-35: Tools menu, showing Advanced mode selected If Advanced is checked, the advanced features are enabled.  To change the Advanced setting: Advanced Click   in the Tools menu. The following message is displayed, reminding you that the change will  only take effect the next time you open Objet Studio, even though the  check mark in the Tools menu appears/disappears after you make the  change. Figure 5-36: Configuration-change message 5–26...
  • Page 61: Save Tray As

    Eden260 User Guide Save Tray As… In addition to saving the tray as an otf file, for printing with an Eden 3‐D  printer, you can save a group of objects positioned on the tray as an stl file.  You can then use this file as any other stl file, both in Objet Studio and in  other applications. You can also display this and other stl files as “floating”  objects, without the build tray. This is useful for inspecting objects from  every angle. To save the build tray as an stl object: Save Tray As… 1. From the File menu, select  Figure 5-37: Save As dialog box 2. At the top of the dialog box, select the appropriate folder. 3. At the bottom of the dialog box, enter a file name. STL Files (*.stl) 4. Open the Save as type pull‐down menu, and select ...
  • Page 62: Configuring The Gl Driver

    OpenGL 2. In the Options dialog box, display the Advanced tab and click  Driver Configuration… Figure 5-38: Accessing GL-driver configuration Note: If the Advanced tab is not displayed, activate the Advanced setting in the Tools menu and restart Objet Studio. The dialog box that opens contains tabs that display the pixel format ID  (index) for the window and the memory. Figure 5-39: OpenGL Driver Configuration dialog box You can display the values and make changes to them by clicking ...
  • Page 63 Eden260 User Guide To perform a test of the driver configuration and enter the suggested pixel format ID: Choose Format 1. Select  .  Test 2. Click  Objet Studio returns the recommended pixel format ID. Figure 5-40: Recommended pixel format ID 3. Click  .  4. In the OpenGL Driver Configuration dialog box (figure 5‐39), select  Pixel Format ID  and enter this number.
  • Page 65: Using Job Manager

    Using Job Manager Client Job Manager..................2 Job Manager Screen ..................3 User Alerts....................... 5 Server Job Manager ..................6 Job Manager Screen ..................6 Job Manager Operations ................8 Making changes to a Job ................9 User Alerts..................... 10 Sending the Tray to the 3‐D printer for Production ........ 11 6–1 DOC-00260 Rev. A1...
  • Page 66: Client Job Manager

    If there are several printers on the local network, client computers can connect to any of them, but only one at a time. • Job Manager installed on the computer directly connected to a specific  3‐D printer displays the queue and status for all jobs sent to that 3‐D  printer by client computers on the network. It also allows editing and  manipulation of all jobs, and enables re‐sending previously‐printed  jobs to the printer. Client Job Manager When you open the client Objet Studio / Job Manager software for the first  time, a dialog box opens prompting you to connect to an Eden server  computer. To do this, the server computer must be operating and connected  to the local network.  Browse Click   to find and select the name of the required server  computer and then click   to close the dialog box.
  • Page 67: Job Manager Screen

    Eden260 User Guide Job Manager On a client computer, Job Manager displays the queue of jobs sent by that  Screen computer to the Eden printer server. Print Queue Print History Figure 6-2: Client Job Manager screen Information for each of the queued jobs is displayed, including the job  status: Status Meaning Waiting Printing of this job has not started. Building Printing of this job is in progress. Paused Printing of this job began, but was interrupted by the  administrator before being completed. Stopped Printing of this job was terminated by the administrator,  and was put in the print queue again. Error Errors occurred during the printing of this job, and it was  placed in the print queue again. Objet Studio Editing This job is now being edited in  Previewing The operator at the server computer is inspecting the ...
  • Page 68 Using Job Manager To inspect the build tray: 1. Select the job. Edit 2. Click the Edit Job icon   or open the Job menu and select  Objet Studio opens, displaying the build tray. To make changes to it, see  “Making changes to a Job” on page 6‐9. The following operations are available from the client Job Manager  interface: Icon Menu Option Purpose 3‐D Printer >  Launches Objet Studio; to prepare new trays. New Job 3‐D Printer >  Displays a network‐browsing dialog box, to  Set Printer connect to an Eden server computer. To specify  a computer, it must be operating and  connected to the local network. —— Displays the status of the Eden 3‐D printer (see  figure 6‐3). 3‐D Printer > Report Displays options for user messages and alerts  (paper printer, e‐mail, SMS—see “User Alerts”  on page 6‐5).
  • Page 69: User Alerts

    Eden260 User Guide Figure 6-3: Eden printer status screen User Alerts Job Manager can alert you and others to the status of the jobs sent to the  server for printing. The following events can be reported: • The level of model or support material is low. • The job was interrupted. • The job was completed successfully. To send messages, make sure that e‐mail software supporting MAPI is  installed on the Eden server computer. To send SMS messages, the e‐mail  program must convert the messages and transmit them. Microsoft Outlook,  for example, can do this; Outlook Express cannot. In addition, the cellular  phone service must support the transmission of e‐mail messages by SMS.  With SMS alerts, only the subject line of the e‐mail message is transmitted. Note: In the e-mail program, make sure the security settings are set to “low” and add the server Job Manager to the “trusted” list (select Tools >...
  • Page 70: Server Job Manager

     in  the relevant sections. Figure 6-5: Event selection for alerts 4. Select the desired events for sending alerts and click  The parameters for “Low level of material” alerts are set on the Eden server computer. Server Job Manager When you open the server Objet Studio / Job Manager for the first time, you  are prompted to connect to an Eden 3‐D printer. To do this, the printer must  be on and connected to the local network. If you click Yes, the Setting  Network Connection dialog box opens.  Figure 6-6: Eden-printer connection dialog box Browse Click ...
  • Page 71 Eden260 User Guide Print Queue Current Job Info Print History Figure 6-7: Server Job Manager screen Print Queue Information for each of the queued jobs is displayed, including the job  status: Status Meaning Waiting Printing of this job has not started. Building Printing of this job is in progress. Paused Printing of this job began, but was interrupted by the  administrator before being completed. Stopped Printing of this job was previously terminated by the  administrator, and later put in the print queue again. Error Errors previously occurred during the printing of this job,  and it was placed in the print queue again. Editing This job is now being edited (with Objet Studio) on the Eden  server computer. Previewing The slices of this job are being displayed in a separate  window. ...
  • Page 72: Job Manager Operations

    Note: Alternatively, you can drag the job from the History section to the  print queue. To manipulate jobs in other ways, see “Job Manager Operations,” below. Job Manager The following table summarizes the main operations available from the  Operations server Job Manager interface. Many of the icons are active only if a job is  selected.  Icon Menu Option Purpose 3‐D Printer >  Launches Objet Studio for preparing new trays. New Job 3‐D Printer >  Displays a network‐browsing dialog box, to  Set Printer connect to an Eden server computer. To specify  a computer, it must be operating and  connected to the local network. 3‐D Printer >  Enables you to load previously‐saved jobs (otf  Add Job... files). 3‐D Printer > Report Displays options for user messages and alerts ...
  • Page 73: Making Changes To A Job

    Eden260 User Guide Icon Menu Option Purpose Job > Restart Job For a stopped job in the print queue: Starts  printing the selected job from the beginning.  For a selected job in the History section: Moves  the job to the print queue and changes its status  to Waiting. Job > Stop... Instructs the Eden printer to stop printing after  curing the currently printed slice. (Printing can  be continued with the Resume icon or menu  option.) Job > Pause... Instructs the Eden printer to stop printing after  curing the currently printed slice. Use instead of  Stop when you intend to continue printing the job  shortly. Job > Resume Continues printing the current job after  printing was stopped with the Stop or Pause  icon or menu option.  Job > Delete Job... Removes the selected job from the queue. Job > Review Job… Opens a window displaying the selected tray.  In this window, you can view the tray from  different angles. Job > Job Info… Opens a window displaying the properties of  the selected model. Job > Edit Job… Launches Objet Studio and loads the selected  tray, to enable making changes to it before  being printed. (See “Making changes to a Job,” ...
  • Page 74: User Alerts

    Using Job Manager User Alerts Job Manager can alert you and others to the status of the jobs sent to the  server for printing. This is especially useful during long printing jobs, when  the operator is away from the Eden 3‐D printer. The following events can be  reported: • The level of model or support material is low. • The job was interrupted. • The job was completed successfully. For details on how to configure alert messages, see “User Alerts” on  page 6‐5. To set parameters for “Low level of material” alerts: Material Consumption…. 1. From the 3‐D Printer menu, select  2. In the dialog box that opens, set the time or the material weight  remaining that triggers the alert message. Figure 6-8: Materials Consumption alert dialog box The dialog box shown above also pops up over the Job Manager screen to ...
  • Page 75: Sending The Tray To The 3-D Printer For Production

    Eden260 User Guide Material warning icon Figure 6-9: Insufficient material warning When the time set in the dialog box triggers the remote alert message, the  warning icon changes color—from a yellow to a red background. Sending the If there is a job in the print queue, it is sent automatically to the Eden  Tray to the 3-D printer—as long as it is on, there is a connection to the printer, and the  printer for printer is on line. Chapter 7 describes starting and operating the Eden  Production printer. 6–11 DOC-00260 Rev. A1...
  • Page 77: Operating & Maintaining The Eden 3-D Printer

    Operating & Maintaining the Eden 3-D Printer Starting the Eden260 3‐D Printer ...............2 Loading Model and Support Cartridges...........3 Producing Models  ..................4 Printing Indicators ..................6 Resuming Production After Printing has Stopped........6 Changing the Model Material ..............8 Keeping the Eden 3‐D Printer in Idle Mode...........12 Shutting Down the Eden 3‐D Printer ............12 Maintaining the Eden 3‐D Printer............14 Routine Maintenance Schedule..............14 Cleaning the Printing Heads ..............14 Pattern Test....................17 Improving Print Quality ................17 Cleaning and Replacing the Wiper............18 Aligning the Printing Heads ..............20 Replacing Printing Heads ................25 Replacing the UV Lamps ................
  • Page 78: Starting The Eden260 3-D Printer

    Operating & Maintaining the Eden 3-D Printer Printer cover Printing-materials compartment Filter compartment Waste compartment Figure 7-1: The Eden260 3-D Printer Starting the Eden260 3-D Printer CAUTION! Do not attempt to operate the Eden printer before being trained by an • Objet customer-support representative.
  • Page 79: Loading Model And Support Cartridges

    Figure 7-2: Eden260 interface Eden installations utilize one monitor for displaying both the computer running Objet Studio / Job Manager and the computer installed inside the Eden printer. Make sure that the KVM (keyboard-video-mouse) switch is in the correct position so that the Eden printer interface is displayed.
  • Page 80: Producing Models

    Operating & Maintaining the Eden 3-D Printer Tips about replacing cartridges: You can replace resin cartridges either before or during printing. • You can replace partially used cartridges to avoid the need for replacing • them during printing. You can load partially used cartridges, as long as they contain more •...
  • Page 81 Eden260 User Guide Printer set to online mode (green) Block temp. behind Block temp. behind model heads support heads Temp. of each Temp. of each model head support head Block temp. in front Block temp. of support heads in front of model heads Tray temp.
  • Page 82: Printing Indicators

    Operating & Maintaining the Eden 3-D Printer Printing When the printer is ready, the main Eden interface screen changes (see  Indicators figure 7‐4): • The mode changes from Pre‐print to Printing.  • The specific activity being performed is shown in the “current activity”  field.  • Current job‐printing information is displayed. • The printing progress bar is displayed. • The Stop and Pause buttons are enabled. Printer mode Current Activity Stop button Job information Progress bar Pause button Maintenance message Figure 7-4: Eden interface during printing When printing begins, Job Manager sends seven slices to the Eden printer. ...
  • Page 83 Eden260 User Guide 3. In the Job Manager interface, click the Resume icon  4. In the Continue from Slice dialog box that appears, confirm the slice  number, after checking the Eden printer interface. Printer mode Last slice printed Figure 7-5: Eden interface after interrupted printing Figure 7-6: Continue from Slice confirmation dialog box in server (Job Manager) interface 5. If, for any reason, the correct number does not appear in the dialog  box, enter the number and click  You cannot continue printing the model if: • The number of the last slice printed does not appear in the Eden  interface, even if the server computer displays the Continue from Slice ...
  • Page 84: Changing The Model Material

    Figure 7-7: Starting the Resin Replacement wizard from the Options menu Next 2. From the opening screen, click   to display the Resin Selection  screen.  3. From the drop‐down menu, choose the type of model material (resin)  Next you want to install, and click  Figure 7-8: Resin Selection screen Note: This selection automatically affects the resin setting in Objet Studio. 7–8 DOC-00260 Rev. A1...
  • Page 85 Eden260 User Guide 4. In the Resin Replacement Cycle screen, choose the appropriate cycle for  the model material you want to install. Two options are available,  depending on the new model material to be used: • Short Cycle, for changing to a darker and more opaque material. During this cycle, which takes about 25 minutes, the air valve is  opened, and the pump purges the material from the feed tube and  printing block. • Long Cycle, for changing to a lighter and more transparent material. During this cycle, which takes about 60 minutes, the feed tube and  printing block are flushed with a cleansing solution after being  purged of the current material. Figure 7-9: Resin Replacement Cycle screen Note: The short cycle does not require user intervention. The long cycle, however, requires user presence to replace material cartridges in the printer.
  • Page 86 Operating & Maintaining the Eden 3-D Printer 7. When prompted by the wizard screen, remove the model‐material  cartridge. Select the check box to confirm that you have done so, and  Next click  • If you are performing the short resin‐replacement cycle, continue with  step 10. • If you are performing the long resin‐replacement cycle, continue with  step 8, below. 8. When prompted, insert the cleanser cartridge in place of the model  material that you removed. Select the check box to confirm that you  Next have done so, and click  The wizard flushes the print heads with the cleanser. This takes about  25 minutes. Figure 7-11:Resin replacement (long cycle): flushing heads with cleanser 9. When prompted, remove the cleanser cartridge. Select the check box  Next and click  The wizard clears the print heads and feed tubes of the cleanser. This  takes about 5 minutes. Figure 7-12:Resin replacement (long cycle): clearing heads of cleanser 7–10 DOC-00260 Rev.
  • Page 87 Eden260 User Guide 10. When prompted, insert the new cartridge of model material. Select the  Next check box and click  Figure 7-13:Insert New Model Container screen The Eden printer begins the process of filling the print heads with the  new model material. This may take up to 15 minutes. Figure 7-14:Resin replacement: filling heads with new model material Done 11. When the final wizard screen appears, click   to close the wizard. CAUTION: Dispose of cartridges of Eden model and support material in accordance with all applicable laws and regulations. If necessary, the cartridges can be disassembled for recycling.
  • Page 88: Keeping The Eden 3-D Printer In Idle Mode

    Operating & Maintaining the Eden 3-D Printer Keeping the Eden 3-D Printer in Idle Mode Between printing jobs, the Eden 3‐D printer can be kept on for up to one  week. If the printer will not be used for more than a week, use the  shutdown wizard to automatically perform the procedures that must be  done before turning off the printer (see “Shutting Down the Eden 3‐D  Printer,” below). When the Eden 3‐D printer stops printing models, the Eden application  automatically reduces the temperature of the printing heads as follows: Time after printing Mode Change in heating of print heads 15 minutes first  Standby 1 none 10 hours heating reduced (to room temp.) next  Standby 2  ...
  • Page 89 Eden260 User Guide Next 2. In the Shutdown Wizard dialog box, click  Next 3. In the next wizard screen, verify that the tray is empty and click  The shutdown procedure begins, and the steps of this procedure are  displayed in the dialog box that follows. Figure 7-16:Shutdown dialog box, showing first step in the procedure The Shutdown procedure may take up to 10 minutes while the  following tasks are performed: a. The printing block returns to its starting point on all axes. b. The printing heads are heated. c. The printing heads are cleared of any remaining material. After these tasks are completed, the final wizard dialog box appears, in  which you choose whether or not to shutdown the computer in the  Eden printer. Figure 7-17:Shutdown Wizard dialog box, showing last step in the procedure 4.
  • Page 90: Maintaining The Eden 3-D Printer

    Clean the build tray and  the surrounding area  inside the printer. Weekly Restart the Eden printer  computer. Monthly, and after  Align the print heads. See “Aligning the  replacing prints heads Printing Heads” on  page 7‐20. Monthly Inspect the exhaust  system (duct, fan,  connections). Every 2000 hours of  Preventive maintenance  Contact your Objet  printing or once a year by authorized service  support center. engineer. At least once a year Replace the activated  Contact your Objet  charcoal filter. support center. Cleaning the Periodic inspection and cleaning of the orifice plates on the bottom of the  Printing Heads print block ensures that the printing nozzles are not blocked. A wizard  guides you through the procedure, and adjusts components of the Eden  printer to enable you to perform it. This procedure takes about 20 minutes,  and should be done at the beginning of the work day or before a big  printing job. To clean the printing heads: 1.
  • Page 91 Eden260 User Guide 3. Follow the instructions on the wizard screens, and select the check  boxes to confirm that: • you have checked that the tray is empty. • you have closed the cover. Figure 7-18:Head cleaning procedure—step 3 Next 4. Click  .  5. When the following screen appears, open the cover. Figure 7-19:Head cleaning wizard—steps 5–10 WARNING: The print head orifice plates (bottom surface) may be hot. Do not touch them with your bare hands, and proceed with caution.
  • Page 92 Operating & Maintaining the Eden 3-D Printer Figure 7-20:Cleaning the heads It is recommended that you use this opportunity to also clean the roller and the UV-lamp lenses (to the left and right of the print heads). 10. When you have finished cleaning, select the confirmation check box in  Next the wizard screen (see figure 7‐19) and click ...
  • Page 93: Pattern Test

    Eden260 User Guide Pattern Test The pattern test is the basic verification of the printer’s ability to produce  quality models, since it demonstrates the condition of the nozzles in the  print heads. Make sure, therefore, that you perform this test weekly, and  whenever you suspect a printing problem. To perform the pattern test: 1. Make sure that the build tray is empty. 2. In the Eden printer, tape an A‐4 sheet of pink paper to the center of the  build tray. 3. In the Eden computer interface, open the Options menu and select  Pattern Test , or press  The Eden printer prints a series of lines on the test paper. Figure 7-22:Sample Pattern Test 5. Carefully inspect the test paper to see if there are missing lines.  Too many missing lines, especially if they are in the same area, is an  indication that the quality of printing when producing models will be  poor. If this is the case, see “Improving Print Quality,” below. Note: Acceptable print quality is subjective, and depends on the type and scale (size) of the models produced.
  • Page 94: Cleaning And Replacing The Wiper

    Cleaning and A rubber wiper blade removes excess material from the printing heads  Replacing the after the purge sequence. This is done automatically before each print job,  Wiper and performed manually during maintenance tasks. You must periodically  clean this wiper and check if it needs replacing. To inspect and clean the wiper: 1. Prepare— • isopropanol (IPA—isopropyl alcohol) or ethanol (ethyl alcohol) • disposable cleaning gloves • an Objet‐supplied cleaning cloth or equivalent • a spare wiper blade 2. Start the Clean Wiper wizard from the Eden Options menu. Figure 7-23:Starting the Clean Wiper wizard Next 3. Close the Eden printer cover, and click   in the wizard screen. 7–18 DOC-00260 Rev. A1...
  • Page 95 Eden260 User Guide 4. Follow the instructions on the wizard screens, and select the check  boxes to confirm that: • you have checked that the tray is empty. • you have closed the cover. Figure 7-24:Wiper Cleaning procedure—step 4 Next 5. Click  .  6. When the following screen appears, open the cover. Figure 7-25:Wiper Cleaning procedure—steps 7–9 7. Put on the cleaning glove. 8. Inspect the wiper.  • If it needs cleaning, soak the cloth with the cleaning fluid and use it  to remove the debris. • If it needs replacing, grasp it and pull it up and out of its bracket.  Then insert the new wiper blade, making sure that it is straight and  secured well on both sides. 9. In the wizard screen, select the confirmation check box (see figure 7‐25) ...
  • Page 96: Aligning The Printing Heads

    Operating & Maintaining the Eden 3-D Printer 11. Select the confirmation check boxes in the wizard screen and click  Next Figure 7-26:Wiper Cleaning procedure—final screen Done 12. Click   to close the wizard. Aligning the You should check the alignment of the printing heads—  Printing Heads • once a month • after replacing one or more heads • if model quality is not acceptable even after cleaning the orifice plate on  the bottom of the print block (see “Cleaning the Printing Heads” on  page 7‐14) The head‐alignment procedure takes about 20 minutes. To check the alignment of the printing heads: 1.
  • Page 97 Eden260 User Guide Figure 7-27:Positioning the transparency on the build tray 6. Make sure that the transparency sheet is lying flat, and tape it to the  tray. 7. In the wizard screen, select the check box to confirm that the  Next transparency sheet is placed on the build tray, and click  The Eden printer prints the head alignment test on the transparency.  8. When the following screen appears, remove the transparency. Figure 7-28:Head Alignment wizard—steps 8–10 7–21 DOC-00260 Rev. A1...
  • Page 98 Operating & Maintaining the Eden 3-D Printer The transparency sheet is printed with sets of vertical lines in seven  columns, each column showing the results from a different print head.  Figure 7-29:Part of a sample head-alignment test • The three columns on the right were printed by the heads used for  applying model material. From right to left, the columns represent  heads M1, M2, M3, respectively. (There is no column for head M0  because its alignment is used as a reference for aligning all other  heads.) • The four columns of lines on the left were printed by the heads used  for applying support material when producing models. The  columns represent heads S3, S2, S1 and S0, respectively. 9. For each column of lines, use a magnifying glass or loupe to inspect  pairs of consecutive rows printed on the transparency to see where the  vertical lines align. Alignment-line numbering, left-to-right Row pairs Figure 7-30:Comparing rows of alignment lines Note: It does not matter which pair of lines you inspect, since they were all printed by the same head.
  • Page 99 Eden260 User Guide 11. In the next wizard screen, select the head(s) needing alignment, based  Next on your inspection of the transparency, and click  Figure 7-31:Head selection screen Note: If you select M0—the head used for the head-alignment reference— you are choosing, in effect, to align all of the other heads. The first in a series of alignment screens appears for the heads you  selected. Figure 7-32:Head alignment screen 12.
  • Page 100 Operating & Maintaining the Eden 3-D Printer When you have finished aligning all of the heads, the following screen  is displayed. Figure 7-33:Updating System Parameters confirmation screen 14. To save the alignment changes, make sure that Yes is selected, and click  Next Figure 7-34:Final head alignment screen 15. In the final wizard screen, choose to either repeat the head alignment  procedure or close the wizard.  • If the most closely aligned vertical lines for a print head were at  either extreme—the first or seventh lines—choose Yes to run the  head‐alignment wizard again.  The transparency test will show if the heads are now properly  aligned, and—if not—the wizard will allow you to “fine tune” the  alignment. • If the vertical lines for the print heads were not aligned at either  extreme, choose No to close the wizard. 7–24 DOC-00260 Rev. A1...
  • Page 101: Replacing Printing Heads

    • Tests reveal that the material printed by a printing head is underweight  (that is, not enough material is being outputted). Note: Weight tests are performed only by an authorized service engineer. Replacing print heads is expensive. Replace them only after consulting with Objet customer support to determine that head replacement is necessary. A wizard guides you through the procedure of replacing a printing head,  and adjusts components of the Eden printer to enable you to perform it.  Only replace a printing head with the aid of the wizard. The procedure  takes about 75 minutes, and consists of the following phases:  A. Identifying the head(s) needing replacement. ...
  • Page 102 To replace a printing head: 1. Prepare— • replacement printing head(s) • isopropanol (IPA—isopropyl alcohol) or ethanol (ethyl alcohol) • disposable safety gloves (included in the head replacement kit) • an Objet‐supplied cleaning cloth or equivalent • a flat‐head screwdriver (5 mm) • the scale supplied by Objet for use in the weight test Note: Make sure that you have these items before running the Quick Head Replacement wizard. 2. Start the Quick Head Replacement wizard from the Eden Options menu  (see figure 7‐23 on page 7‐18). Next 3.
  • Page 103 Eden260 User Guide 7. Take note of the warning screen that appears (see figure 7‐37). To  prevent damage to the print block, you must install the new head  Next immediately after removing the defective one.    if you are ready to  continue. Figure 7-37:Head Replacement warning screen 8. Open the Single Head Replacement kit, and remove the safety gloves  and the instructions. 9. Put on the safety gloves.  10. When the Head(s) Replacement wizard screen is displayed, open the  Eden printer cover to remove the defective printing head.  Note: The Eden printer disconnects power to the heads for your safety. Figure 7-38:Replace the defective head when this screen appears 7–27...
  • Page 104 Operating & Maintaining the Eden 3-D Printer Removing the 11. On the print block, release the upper and lower screws that secure the  Defective Head printing head in the block. (If necessary, you may use a screwdriver to  loosen the screws.) Figure 7-39:Releasing the locking screws 12. Press down on the upper and lower locking screws to release the  printing head. Figure 7-40:Releasing the printing head 13. Loosen the screws on the door of the compartment protecting the  printing‐head driver cards (A), then pull and lift up the door (B). Figure 7-41:Opening the printing head compartment 7–28 DOC-00260 Rev. A1...
  • Page 105 Eden260 User Guide 14. Pull the printing‐head driver card out of its socket so that the head is  free (A), and remove it from the bottom of the print block (B). Figure 7-42:Releasing the printing-head driver card to remove the head 15. Make sure that along with the head, you remove the two rubber O‐ring  seals. Figure 7-43:O-ring seals on the head housing Important: If the seals are not removed with the head, they are probably stuck to the print block housing. If so, remove them.
  • Page 106 Operating & Maintaining the Eden 3-D Printer Installing the 16. Inspect the replacement head, and make sure that the O‐ring seals are  New Head in place (see figure 7‐43). 17. Gently insert the replacement head into the vacant slot in the print  block, and push the printing‐head driver card into its socket. Note: Make sure to insert the head with driver card facing its socket, in the rear of the print block. Figure 7-45:Inserting the printing-head driver card into its socket 18.
  • Page 107 Eden260 User Guide 22. With your fingers, make sure that the new head is level and even with  the other heads. Figure 7-47:Checking the level of the new head 23. In the Installation check wizard screen, select the check box to confirm  that the new head is level and even with the other heads, and click  Next Figure 7-48:Installation check screen 24. In the next wizard screen, select the check box to confirm that you have  removed all tools and objects from the Eden printer. Figure 7-49:Cleared-tray confirmation screen 7–31 DOC-00260 Rev. A1...
  • Page 108 Operating & Maintaining the Eden 3-D Printer If the installation was successful, the wizard continues by performing a  vacuum leakage test. Figure 7-50:Vacuum Leakage Test progress screen If the vacuum leakage test is successful, the wizard continues by filling  the heads, then heating and purging them. Continue with “Weight  Calibration” on page 7‐34. If a vacuum leakage is detected, or if other problems occur, see  “Installation Problems,” below. Installation • If the Eden software does not sense the replaced head, the following  Problems warning screen appears.  Figure 7-51: Incorrect-installation screen, showing which head(s) to re-insert If this happens:  a. Open the printing head compartment (see figure 7‐41 on page 7‐28). b.
  • Page 109 Eden260 User Guide • If the replacement head was not factory calibrated, the following  warning screen appears.  Figure 7-52: “No factory data” warning screen If this happens:  a. Remove the head and replace it with another one (starting with step  11 on page 7‐28). b. In the wizard screen, select the check box to confirm that you have  Next installed another printing head, and click  c. Contact Objet customer support about the uncalibrated head. • If the vacuum test is not successful, the replacement head was not  sealed properly during installation, and the following warning screen  appears. Figure 7-53: Vacuum Leakage warning screen If this happens:  Next a. Click  b. Follow the instructions on the wizard screens to re‐install the head.
  • Page 110 Operating & Maintaining the Eden 3-D Printer Weight Calibration After the successful installation of a print head, the wizard begins the first  of two weight tests, in which each head prints a sample. This phase takes  about 25 minutes. Figure 7-54:High-quality-printing weight test progress screen 25. Carefully remove the samples for each head, keeping track of the head  that printed them.   Figure 7-55:Samples printed on the Eden build tray 26. Using the scale, weigh each sample and enter the weight (in grams) for  Next the corresponding head in the wizard screen. Then click  Figure 7-56:Weight Test data entry screen After the high‐quality‐printing weight test, the weight test begins for ...
  • Page 111: Replacing The Uv Lamps

    Eden260 User Guide The Eden printer calibrates itself based on the weight data you entered,  and the final wizard screen appears. Figure 7-57:Final Head Replacement screen After replacing printing heads, check the head alignment (see “Aligning the Printing Heads” on page 7-20). Replacing the The UV lamp used for curing models have a long, but limited, working life.  UV Lamps The Objet service engineer tests their effectiveness during regular  maintenance checks, and replaces them, if necessary. If, for any reason, you  need to replace a UV lamp, follow these instructions.  1. Make sure the Eden printer is in offline mode. Figure 7-58:Offline mode (red) The button at the bottom of the Eden computer interface should be red. ...
  • Page 112 Operating & Maintaining the Eden 3-D Printer 3. Disconnect the power connection to the UV lamp by pulling it up. Figure 7-59:Disconnecting power to the UV lamp Note: Do not disconnect the power connection to the cooling fans. 4. Loosen the screw securing the UV lamp cover  , and pull the cover  up  , then out  Figure 7-60:Removing the UV lamp cover 5. Pull the lamp reflector out of the print block. Figure 7-61:Removing the UV lamp reflector 7–36 DOC-00260 Rev.
  • Page 113 Eden260 User Guide 6. On the inside of the lamp reflector, a black strip covers part of the  reflector. Remove this strip by sliding it off. Figure 7-62:Removing the black strip from the old reflector 7. Discard the old reflector and lamp, but save the black strip so you can  install it in the new reflector. 8. Fasten the black strip to the inside of the new UV lamp reflector, on the  same side as it was in the old reflector. Figure 7-63:Fastening the black strip to the right UV lamp reflector Important: The black strip must always be on the side of the reflector opposite the print block.
  • Page 114 Operating & Maintaining the Eden 3-D Printer UV lamp UV lamp assembly assembly Black strip Black strip Figure 7-64:Printing block and UV lamp assembly, showing correct placement of black strip 10. Replace the lamp cover by inserting it into the slot on the bottom of the  housing, and tighten the securing screw on top. Figure 7-65:Replacing the lamp cover 11. Reconnect the power connection to the UV lamp. Figure 7-66:Connecting power to the UV lamp 7–38 DOC-00260 Rev.
  • Page 115: Replacing The Waste Container

    Eden260 User Guide Replacing the The waste container contains partially cured polymeric material produced  Waste during normal operation and maintenance of the Eden printer. For safety  Container and environmental reasons, this material is kept in a special leak‐proof,  disposable container.  The container has a capacity of about eight kilograms of waste material— usually enough for several months of printer use. The Eden software  displays a warning message when the container weighs 7.3 kilograms, and  stops the printer when it weighs 7.8 kilograms. Above 7.3 kilograms, the  software does not allow you to start a print job until you replace the waste  container. You can monitor the weight of the waste container in the  Maintenance screen of the Eden interface. To monitor the waste weight (and other indicators) in the Eden printer: In the main Eden interface screen, click the display toggle to view the  Eden printer indicators. Waste weight Figure 7-67: Eden printer interface, showing waste weight (red background indicates operator alert) The waste container consists of a sealed bag inside a cardboard box. You ...
  • Page 116 Operating & Maintaining the Eden 3-D Printer To replace the waste container: 1. Locate the waste compartment under the Eden printer (see figure 7‐1  on page 7‐2). 2. Remove the two screw‐knobs securing the waste compartment panel,  and remove the panel. Figure 7-68:Waste container under the printer 3. Carefully slide out the waste container, removing it from the printer. Figure 7-69:Waste container removed from the printer 4. Place the new waste container next to the full container. 5. Unscrew the cap securing the waste drain tube and connect it to the  new container. 6.
  • Page 117: Handling Printed Models

    Handling Printed Models Cooling Models After Printing..............2 Removing the Support Material..............2 Storing Models....................3 8–1 DOC-00260 Rev. A1...
  • Page 118: Cooling Models After Printing

    3. Place the models on a flat surface, and cover them with a cardboard  box or paper hood. This allows the models to cool slowly and evenly. 4. Let the models cool for several hours. Removing the Support Material After printed models have cooled, the support material must be removed.  This can be done by different methods, depending on the size of the model,  how delicate it is, the amount and location of the support material, and  other factors. Use the following methods as a guide, and adapt them (or a  combination of them) for finishing the models you are handling. Removing Excess Support Material by Hand While wearing protective gloves, break away excess support material on  the outside of the model. For delicate models, use a toothpick, pin or small  brush after dipping the model in water. Removing Support Material with Water Pressure For most models, the most efficient way to remove support material is by  using a high‐pressure water jet. One suitable system is the Objet WaterJet  cleaning unit, shown in figure 8‐1 on page 8‐3.  8–2 DOC-00260 Rev. A1...
  • Page 119: Storing Models

    Eden260 User Guide Figure 8-1: Objet WaterJet Cleaning Unit To clean a model using this device, you place it in the chamber, and you  manipulate it and the jet using the built‐in, waterproof sleeves. A pump  turns ordinary tap water into a high‐pressure jet, and a wiper keeps the  window clear. Use caution when cleaning delicate models with high-pressure water systems. Removing Support Material with Caustic Soda Soak models in a 2‐percent solution of caustic soda (sodium hydroxide) to  remove support material from difficult‐to‐reach areas and to give the  model a smooth, clean finish. The amount of time you soak the model in the  solution depends on how delicate it is and how much support material  needs to be removed, but it is typically between half‐an‐hour and several  hours. In any case, you should remove as much support material as  possible before the caustic soda treatment, and rinse the model thoroughly  (with a water jet) afterwards.  WARNING: Caustic soda may cause chemical burns, scarring and blindness.
  • Page 121: A Printer Elements

    Printer Elements The following diagram shows a schematic view of the elements that make up the Eden260  3‐D printer. A–1 DOC-00260 Rev. A1...
