SLC SmartOne S57019B Operation

SLC SmartOne ZB Wall RGBW Black
Important: Read All Instructions Prior to Installation
Function introduction
Click to turn on the paired
lighting devices
Press and hold down to
search and pair to ZigBee
network or factory reset the
dimmer switch
Brightness up button, press
and hold down to increase
light intensity
When controls RGB+CCT
light devices, keep short
pressing to turn on CCT
channels and get
25% ww+75% cw,
50% ww+50% cw,
75% ww+25% cw,
100% ww+0% cw,
0% ww+100% cw one by one.
Press and hold to adjust color
temperature smoothly.
When controls RGBW light
devices, keep short pressing
to turn on the 4th channel W
and get 25%, 50%, 75%,
100%, 0% intensity one by
one. Press and hold to adjust
W channel light intensity smoothly.
11 mm
Battery: CR2450
Before the first use, please open the battery
cover and remove the protective film
Click to turn off the paired
lighting devices
Brightness down button,
press and hold down to
decrease light intensity
RGB color button, click to
get R, G, B one by one,
press and hold down to
cycle RGB colors
Scene buttons, press and
hold down to save a scene,
click to recall the saved
Note: This switch
supports 1 group for
binding max. 30 lighting
devices.
Front side
71.20 mm
55.57 mm
Back side
S57019B

Product Data

Protocol
Operation Voltage
Transmission Frequency
Transmission Range (free field)
Protection Type
Dimming Range
Dimensions
ZigBee Clusters Supported by This Remote Are As Follows:
Input clusters:
• Basic • Power Configuration
Output clusters:
• Identify • Scenes • On/off
Safety & Warnings
• This device contains a button lithium battery that shall be stored and disposed properly.
• DO NOT expose the device to moisture.
• Do not ingest battery, Chemical Burn Hazard
• This product contains a coin / button cell battery. If the coin / button cell battery is swallowed,
it can cause severe internal burns in just 2 hours and can lead to death
• Keep new and used batteries away from children.
• If the battery compartment does not close securely, stop using the product and keep it away
from children.
• If you think batteries might have been swallowed or placed inside any part of the body, seek
immediate medical attention
Quick Start (Simplified operation compared to standard operations in the part "Operation")
Touchlink: Press and hold down both keys
for 3 seconds to start touchlink and link
light device.
Factory reset: click both buttons 3 times to
reset the remote (the remote should already
be paired to a gateway).
• ZigBee RGBW remote based on ZigBee 3.0
ZigBee 3.0
• Enables to pair ZigBee lighting devices via touchlink
3VDC (CR2450)
commissioning without coordinator
• Supports find and bind mode to pair with ZigBee lighting
2.4GHz
devices
30m
• Supports 1 group for binding max. 30 lighting devices
• 2.4 GHz global operation
IP20
• Long battery life mesh technology
0.1%-100%
• Transmission range up to 30m
• Compatible with universal ZigBee Gateway products
71.2x71.2x13.6mm
• Compatible with universal RGBW, RGB+CCT ZigBee
lighting devices
• Identify • Diagnostics
• Level control • Ota • Color control
Network pairing mode: click both buttons 3 times to
set the remote into network pairing mode (the remote
should not belong to any gateway network).
