Deryck Whibley SUM41 Telecaster
Loc # Description
1
Standard Tuners (set of 6)
2
Bone Nut (blank) (2)
3
Vintage String Guides (pack of 2)
4
Strap Buttons (2)
5
Pickguard (black)
5a
Pickguard Screws (24)
6
Duncan HB-102B Bridge pickup
7
500K Split Shaft Pot (Volume)
8
500K Split Shaft Pot (tone)
8a
Tone Knob (black)
8b
Tone Knob (black)
9
Output Jack (2 pack)
10
Jack Plate (chrome)
11
Bridge Assembly
Maple-
m/n 0301000xxx
Part Number
007-3867-000
099-4920-000
099-4912-000
099-4915-000
007-3872-000
099-4923-000
007-3871-000
006-2730-000
006-2731-000
007-3873-000
007-3874-000
007-2892-000
007-2894-000
006-9990-000
Last Revision Date: 5/28/2008
Page 1 of 2
Advertisement
Related Manuals for Squier Deryck Whibley SUM41 Telecaster
Summary of Contents for Squier Deryck Whibley SUM41 Telecaster
- Page 1 Deryck Whibley SUM41 Telecaster Loc # Description Standard Tuners (set of 6) Bone Nut (blank) (2) Vintage String Guides (pack of 2) Strap Buttons (2) Pickguard (black) Pickguard Screws (24) Duncan HB-102B Bridge pickup 500K Split Shaft Pot (Volume) 500K Split Shaft Pot (tone)
- Page 2 Wiring Diagram Last Revision Date: 5/28/2008 Page 2 of 2...
