Squier Mini Strat
Loc # Description
1
Standard Tuners (set of 6)
2
Bone Nut (blank) (2)
3
String Guide
4
Strap Buttons (2)
5
Pickguard Assembly (w/ controls)
5a
Volume/Tone Knobs (ea) (white) 005-5424-000
6
Output Jack
6a
Jack Plate (chrome)
10
Bridge Assembly
Rosewood- m/n 0310101xxx
Part Number
005-5404-000
099-4920-000
099-4910-000
099-4915-000
007-7506-000
007-2892-000
007-2893-000
006-2370-000
Last Revision Date: 9/19/2008
Page 1 of 2
Advertisement
Table of Contents
Related Manuals for Squier Affinity Mini Strat
Summary of Contents for Squier Affinity Mini Strat
- Page 1 Squier Mini Strat Rosewood- m/n 0310101xxx Loc # Description Standard Tuners (set of 6) Bone Nut (blank) (2) String Guide Strap Buttons (2) Pickguard Assembly (w/ controls) Volume/Tone Knobs (ea) (white) 005-5424-000 Output Jack Jack Plate (chrome) Bridge Assembly Part Number...
-
Page 2: Wiring Diagram
Wiring Diagram Last Revision Date: 9/19/2008 Page 2 of 2...
